Apex Dynamics AUX Tightening Shafts for PU Lubrication Pinions

Apex Dynamics AUX Tightening Shafts for PU Lubrication Pinions

Apex Dynamics AUX tightening shafts mount the PU lubrication pinion and feed lubricant from the tube connection into the foam pinion, in right-angle (-1) and in-line (-2) versions for modules 1 to 12.

Key features

  • Order code AUX-<module>-1 right-angle or AUX-<module>-2 in-line
  • One shaft size covers modules 2 and 2.5; Pt 5, Pt 10 and Pt 13.33 pinions use the m1.5, m3 and m4 shafts
  • Right-angle version: lateral G 1/8" lubricant port, M8 thread, hex SW24 (SW30 for m12)
  • In-line version: axial M10 (m1-4) or M16 (m5-12) connection
  • Shaft diameter d1 matches PU pinion bore: 12, 20 or 25 mm

Specifications

Function Mounting and lubricant feed for PU lubrication pinion
Versions Right-angle (-1), In-line (-2)
Module range 1 to 12, Pt 5 / Pt 10 / Pt 13.33
Shaft length l1 30 mm (right-angle, in-line m1-4), 49 mm (in-line m5-12)
Mating pinion Apex Dynamics PU lubrication pinion
Source APEX Dynamics Smart Lubrication System catalog, p. 9
AUX-01-1 Type: Right-angle | For module: 1 | Length L: 46.4 mm | Shaft d1 x b: 12 x 15 mm | Connection: M8, port G 1/8", SW24
AUX-01-2 Type: In-line | For module: 1 | Length L: 56 mm | Shaft d1 x b: 12 x 15 mm | Connection: Hole M6, M10, SW17
AUX-1J-1 Type: Right-angle | For module: 1.5 / 1.591 (Pt 5) | Length L: 51.4 mm | Shaft d1 x b: 12 x 20 mm | Connection: M8, port G 1/8", SW24
AUX-1J-2 Type: In-line | For module: 1.5 / 1.591 (Pt 5) | Length L: 61 mm | Shaft d1 x b: 12 x 20 mm | Connection: Hole M6, M10, SW17
AUX-02-1 Type: Right-angle | For module: 2 / 2.5 | Length L: 56.4 mm | Shaft d1 x b: 12 x 25 mm | Connection: M8, port G 1/8", SW24
AUX-02-2 Type: In-line | For module: 2 / 2.5 | Length L: 66 mm | Shaft d1 x b: 12 x 25 mm | Connection: Hole M6, M10, SW17
AUX-03-1 Type: Right-angle | For module: 3 / 3.183 (Pt 10) | Length L: 61.4 mm | Shaft d1 x b: 12 x 30 mm | Connection: M8, port G 1/8", SW24
AUX-03-2 Type: In-line | For module: 3 / 3.183 (Pt 10) | Length L: 71 mm | Shaft d1 x b: 12 x 30 mm | Connection: Hole M6, M10, SW17
AUX-04-1 Type: Right-angle | For module: 4 / 4.244 (Pt 13.33) | Length L: 71.4 mm | Shaft d1 x b: 12 x 40 mm | Connection: M8, port G 1/8", SW24
AUX-04-2 Type: In-line | For module: 4 / 4.244 (Pt 13.33) | Length L: 81 mm | Shaft d1 x b: 12 x 40 mm | Connection: Hole M6, M10, SW17
AUX-05-1 Type: Right-angle | For module: 5 | Length L: 81.4 mm | Shaft d1 x b: 20 x 50 mm | Connection: M8, port G 1/8", SW24
AUX-05-2 Type: In-line | For module: 5 | Length L: 116 mm | Shaft d1 x b: 20 x 50 mm | Connection: Hole G 1/8", M16, SW24
AUX-06-1 Type: Right-angle | For module: 6 | Length L: 91.4 mm | Shaft d1 x b: 20 x 60 mm | Connection: M8, port G 1/8", SW24
AUX-06-2 Type: In-line | For module: 6 | Length L: 126 mm | Shaft d1 x b: 20 x 60 mm | Connection: Hole G 1/8", M16, SW24
AUX-08-1 Type: Right-angle | For module: 8 | Length L: 111.4 mm | Shaft d1 x b: 20 x 80 mm | Connection: M8, port G 1/8", SW24
AUX-08-2 Type: In-line | For module: 8 | Length L: 146 mm | Shaft d1 x b: 20 x 80 mm | Connection: Hole G 1/8", M16, SW24
AUX-10-1 Type: Right-angle | For module: 10 | Length L: 131.4 mm | Shaft d1 x b: 20 x 100 mm | Connection: M8, port G 1/8", SW24
AUX-10-2 Type: In-line | For module: 10 | Length L: 166 mm | Shaft d1 x b: 20 x 100 mm | Connection: Hole G 1/8", M16, SW24
AUX-12-1 Type: Right-angle | For module: 12 | Length L: 152 mm | Shaft d1 x b: 25 x 120 mm | Connection: M8, port G 1/8", SW30
AUX-12-2 Type: In-line | For module: 12 | Length L: 186.6 mm | Shaft d1 x b: 25 x 120 mm | Connection: Hole G 1/8", M16, SW30
Lubrication SystemsApex Dynamics
20 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Apex Dynamics AUX Tightening Shafts for PU Lubrication Pinions

Brand Apex Dynamics·Lubrication Systems

Available part numbers (20)

AUX-01-1, AUX-01-2, AUX-1J-1, AUX-1J-2, AUX-02-1, AUX-02-2, AUX-03-1, AUX-03-2, AUX-04-1, AUX-04-2 + 10 more — see full table ↓
