Apex Dynamics Lubrication Distributors (SPL, PD, PDT Progressive)

Apex Dynamics distributors split the LUG lubricator output to multiple lubrication points: SPL/SPLS block distributors with 2-4 outlets, PD and PDT progressive flow distributors with 5-14 outlets, and the PSS-01 proximity sensor set.

Key features

SPL-<tube><0 grease/1 oil><outlets> in aluminum alloy, SPLS in stainless steel; 6 or 8 mm tube versions
PD-05 to PD-14 progressive distributors deliver 0.15 ml per outlet per cycle, max. 100 bar
PDT-07/09/11 (CNC version): outlet 4 delivers 0.3 ml (2 strokes) for higher-demand points
Suffix S = with proximity sensor that signals each completed pumping cycle (LED)
Inlet M10 x 1.0; progressive distributors take 4 and 6 mm in-line or right-angle connectors
Block distributors: max. 8 bar pressure difference between outlets, one distributor per outlet

Specifications

Inlet / outlet thread	M10 x 1.0
Temperature range	+10 to +60 C
Progressive distributor pressure	Max. 100 bar
Block distributor size	L1 60 mm, W 20 mm, 2 x 5.5 mm mounting holes
Progressive distributor length L	72.5-130.5 mm (PD), 87-116 mm (PDT)
Proximity sensor	PNP, NO, 10-30 V DC, 150 mA max., IP67
Source	APEX Dynamics Smart Lubrication System catalog, p. 10-11; CNC edition p. 9

SPL-602		Type: Distributor, tube 6 mm \| Outlets: 2 \| Lubricant: Grease \| Material: Aluminum alloy \| Sensor: None
SPLS-602		Type: Distributor, tube 6 mm \| Outlets: 2 \| Lubricant: Grease \| Material: Stainless steel \| Sensor: None
SPL-612		Type: Distributor, tube 6 mm \| Outlets: 2 \| Lubricant: Oil \| Material: Aluminum alloy \| Sensor: None
SPLS-612		Type: Distributor, tube 6 mm \| Outlets: 2 \| Lubricant: Oil \| Material: Stainless steel \| Sensor: None
SPL-603		Type: Distributor, tube 6 mm \| Outlets: 3 \| Lubricant: Grease \| Material: Aluminum alloy \| Sensor: None
SPLS-603		Type: Distributor, tube 6 mm \| Outlets: 3 \| Lubricant: Grease \| Material: Stainless steel \| Sensor: None
SPL-613		Type: Distributor, tube 6 mm \| Outlets: 3 \| Lubricant: Oil \| Material: Aluminum alloy \| Sensor: None
SPLS-613		Type: Distributor, tube 6 mm \| Outlets: 3 \| Lubricant: Oil \| Material: Stainless steel \| Sensor: None
SPL-604		Type: Distributor, tube 6 mm \| Outlets: 4 \| Lubricant: Grease \| Material: Aluminum alloy \| Sensor: None
SPLS-604		Type: Distributor, tube 6 mm \| Outlets: 4 \| Lubricant: Grease \| Material: Stainless steel \| Sensor: None
SPL-614		Type: Distributor, tube 6 mm \| Outlets: 4 \| Lubricant: Oil \| Material: Aluminum alloy \| Sensor: None
SPLS-614		Type: Distributor, tube 6 mm \| Outlets: 4 \| Lubricant: Oil \| Material: Stainless steel \| Sensor: None
SPL-802		Type: Distributor, tube 8 mm \| Outlets: 2 \| Lubricant: Grease \| Material: Aluminum alloy \| Sensor: None
SPLS-802		Type: Distributor, tube 8 mm \| Outlets: 2 \| Lubricant: Grease \| Material: Stainless steel \| Sensor: None
SPL-812		Type: Distributor, tube 8 mm \| Outlets: 2 \| Lubricant: Oil \| Material: Aluminum alloy \| Sensor: None
SPLS-812		Type: Distributor, tube 8 mm \| Outlets: 2 \| Lubricant: Oil \| Material: Stainless steel \| Sensor: None
SPL-803		Type: Distributor, tube 8 mm \| Outlets: 3 \| Lubricant: Grease \| Material: Aluminum alloy \| Sensor: None
SPLS-803		Type: Distributor, tube 8 mm \| Outlets: 3 \| Lubricant: Grease \| Material: Stainless steel \| Sensor: None
SPL-813		Type: Distributor, tube 8 mm \| Outlets: 3 \| Lubricant: Oil \| Material: Aluminum alloy \| Sensor: None
SPLS-813		Type: Distributor, tube 8 mm \| Outlets: 3 \| Lubricant: Oil \| Material: Stainless steel \| Sensor: None
SPL-804		Type: Distributor, tube 8 mm \| Outlets: 4 \| Lubricant: Grease \| Material: Aluminum alloy \| Sensor: None
SPLS-804		Type: Distributor, tube 8 mm \| Outlets: 4 \| Lubricant: Grease \| Material: Stainless steel \| Sensor: None
SPL-814		Type: Distributor, tube 8 mm \| Outlets: 4 \| Lubricant: Oil \| Material: Aluminum alloy \| Sensor: None
SPLS-814		Type: Distributor, tube 8 mm \| Outlets: 4 \| Lubricant: Oil \| Material: Stainless steel \| Sensor: None
PD-05		Type: Progressive, 0.15 ml/stroke \| Outlets: 5 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PD-05S		Type: Progressive, 0.15 ml/stroke \| Outlets: 5 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PD-06		Type: Progressive, 0.15 ml/stroke \| Outlets: 6 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PD-06S		Type: Progressive, 0.15 ml/stroke \| Outlets: 6 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PD-07		Type: Progressive, 0.15 ml/stroke \| Outlets: 7 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PD-07S		Type: Progressive, 0.15 ml/stroke \| Outlets: 7 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PD-08		Type: Progressive, 0.15 ml/stroke \| Outlets: 8 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PD-08S		Type: Progressive, 0.15 ml/stroke \| Outlets: 8 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PD-09		Type: Progressive, 0.15 ml/stroke \| Outlets: 9 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PD-09S		Type: Progressive, 0.15 ml/stroke \| Outlets: 9 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PD-10		Type: Progressive, 0.15 ml/stroke \| Outlets: 10 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PD-10S		Type: Progressive, 0.15 ml/stroke \| Outlets: 10 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PD-11		Type: Progressive, 0.15 ml/stroke \| Outlets: 11 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PD-11S		Type: Progressive, 0.15 ml/stroke \| Outlets: 11 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PD-12		Type: Progressive, 0.15 ml/stroke \| Outlets: 12 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PD-12S		Type: Progressive, 0.15 ml/stroke \| Outlets: 12 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PD-13		Type: Progressive, 0.15 ml/stroke \| Outlets: 13 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PD-13S		Type: Progressive, 0.15 ml/stroke \| Outlets: 13 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PD-14		Type: Progressive, 0.15 ml/stroke \| Outlets: 14 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PD-14S		Type: Progressive, 0.15 ml/stroke \| Outlets: 14 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PDT-07		Type: Progressive, outlet 4 = 2X 0.3 ml \| Outlets: 7 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PDT-07S		Type: Progressive, outlet 4 = 2X 0.3 ml \| Outlets: 7 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PDT-09		Type: Progressive, outlet 4 = 2X 0.3 ml \| Outlets: 9 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PDT-09S		Type: Progressive, outlet 4 = 2X 0.3 ml \| Outlets: 9 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PDT-11		Type: Progressive, outlet 4 = 2X 0.3 ml \| Outlets: 11 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: None
PDT-11S		Type: Progressive, outlet 4 = 2X 0.3 ml \| Outlets: 11 \| Lubricant: Grease NLGI 1-2 \| Material: Standard \| Sensor: Proximity sensor PNP
PSS-01		Type: Proximity sensor set \| Outlets: - \| Lubricant: - \| Material: 10-30 V DC, 150 mA, IP67 \| Sensor: PNP NO with LED
