Aryung ASA Flow Unit Proportional Valve

Aryung ASA Flow Unit Proportional Valve

Proportional flow unit (metering jet) assembled directly at the lubrication point on the machine.

Key features

  • Oil is delivered in proportion to the classification number - the higher the number, the larger the proportional amount
  • The flow direction is marked on the body and a built-in check valve prevents reverse flow
  • Check the oil flow direction carefully before installation

Specifications

Working pressure 0.15 ~ 2.0 MPa
Viscosity 20 ~ 500 cSt
Aryung ASA Flow Unit Proportional Valve reference 2
ASA-03 Code No.: 03 | Flow rate: 1.2 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-02 Code No.: 02 | Flow rate: 2.5 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-0 Code No.: 0 | Flow rate: 5 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-1 Code No.: 1 | Flow rate: 10 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-2 Code No.: 2 | Flow rate: 20 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-3 Code No.: 3 | Flow rate: 40 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-4 Code No.: 4 | Flow rate: 80 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-5 Code No.: 5 | Flow rate: 160 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
Lubrication DistributorsAryung
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Aryung ASA Flow Unit Proportional Valve

Brand Aryung·Lubrication Distributors

Available part numbers (8)

ASA-03, ASA-02, ASA-0, ASA-1, ASA-2, ASA-3, ASA-4, ASA-5

How to order

Send the Aryung part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
Aryung ASA Flow Unit Proportional Valve reference 2
0 selected
RFQ List (0)
Product codeSpec
ASA-03Code No.: 03 | Flow rate: 1.2 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-02Code No.: 02 | Flow rate: 2.5 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-0Code No.: 0 | Flow rate: 5 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-1Code No.: 1 | Flow rate: 10 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-2Code No.: 2 | Flow rate: 20 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-3Code No.: 3 | Flow rate: 40 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-4Code No.: 4 | Flow rate: 80 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
ASA-5Code No.: 5 | Flow rate: 160 % | Working pressure: 0.15 ~ 2.0 MPa | Viscosity: 20 ~ 500 cSt
