Fuji Electric NEO SC Series Magnetic Contactors (SC-N1 to SC-N16)

Fuji Electric NEO SC Series Magnetic Contactors (SC-N1 to SC-N16)

NEO SC series magnetic contactors, frames N1 to N16, for motors from 5.5 kW to 200 kW at 200-240 V (AC-3).

Key features

  • Frames SC-N1 to SC-N16 (up to 800 A AC-3)
  • Ambient temperature range extended to 55 C (catalogue)
  • Coil voltage and auxiliary contact arrangement specified when ordering (default 2a2b where applicable)
  • Reversing, DC-operated, mechanical-latch and other variants (see type designation)
  • Head-on and side-on auxiliary contact units, surge suppressors and interlock units

Specifications

Series NEO SC
Poles 3 main poles
Ordering Type + coil voltage + aux contacts (e.g. SC-N8 200V 4A4B)
Product code note [coil][aux] = coil and aux contact codes
Rated utilization AC-3 values per JIS C 8201-4-1 / JEM 1038
Source Fuji Electric New SC / NEO SC contactor catalogue, p. 20-23
SC-N1 Product code: SC25BAA-[coil][aux] | AC-3 200-240V: 5.5kW/26A | AC-3 380-440V: 11kW/25A | Thermal current: 50 A
SC-N2 Product code: SC35BAA-[coil][aux] | AC-3 200-240V: 7.5kW/35A | AC-3 380-440V: 15kW/32A | Thermal current: 60 A
SC-N2S Product code: SC50BAA-[coil][aux] | AC-3 200-240V: 11kW/50A | AC-3 380-440V: 22kW/48A | Thermal current: 80 A
SC-N3 Product code: SC65BAA-[coil][aux] | AC-3 200-240V: 15kW/65A | AC-3 380-440V: 30kW/65A | Thermal current: 100 A
SC-N4 Product code: SC80BAA-[coil][aux] | AC-3 200-240V: 18.5kW/80A | AC-3 380-440V: 37kW/80A | Thermal current: 135 A
SC-N5A Product code: SC93CAA-[coil][aux] | AC-3 200-240V: 22kW/93A | AC-3 380-440V: 45kW/90A | Thermal current: 150 A
SC-N6 Product code: SC1CBAA-[coil][aux] | AC-3 200-240V: 30kW/125A | AC-3 380-440V: 55kW/110A | Thermal current: 150 A
SC-N7 Product code: SC1FBAA-[coil][aux] | AC-3 200-240V: 37kW/152A | AC-3 380-440V: 75kW/150A | Thermal current: 200 A
SC-N8 Product code: SC1JBAA-[coil][aux] | AC-3 200-240V: 45kW/180A | AC-3 380-440V: 90kW/180A | Thermal current: 260 A
SC-N10 Product code: SC2CBAA-[coil][aux] | AC-3 200-240V: 55kW/220A | AC-3 380-440V: 110kW/220A | Thermal current: 260 A
SC-N11 Product code: SC3ABAA-[coil][aux] | AC-3 200-240V: 75kW/300A | AC-3 380-440V: 150kW/300A | Thermal current: 350 A
SC-N12 Product code: SC4ABAA-[coil][aux] | AC-3 200-240V: 110kW/400A | AC-3 380-440V: 200kW/400A | Thermal current: 450 A
SC-N14 Product code: SC6ABAA-[coil][aux] | AC-3 200-240V: 150kW/600A | AC-3 380-440V: 300kW/600A | Thermal current: 660 A
SC-N16 Product code: SC8ABAA-[coil][aux] | AC-3 200-240V: 200kW/800A | AC-3 380-440V: 400kW/800A | Thermal current: 800 A
Magnetic ContactorsFuji Electric
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Fuji Electric NEO SC Series Magnetic Contactors (SC-N1 to SC-N16)

Brand Fuji Electric·Magnetic Contactors

Available part numbers (14)

SC-N1, SC-N2, SC-N2S, SC-N3, SC-N4, SC-N5A, SC-N6, SC-N7, SC-N8, SC-N10 + 4 more — see full table ↓

How to order

Send the Fuji Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SC-N1Product code: SC25BAA-[coil][aux] | AC-3 200-240V: 5.5kW/26A | AC-3 380-440V: 11kW/25A | Thermal current: 50 A
SC-N2Product code: SC35BAA-[coil][aux] | AC-3 200-240V: 7.5kW/35A | AC-3 380-440V: 15kW/32A | Thermal current: 60 A
SC-N2SProduct code: SC50BAA-[coil][aux] | AC-3 200-240V: 11kW/50A | AC-3 380-440V: 22kW/48A | Thermal current: 80 A
SC-N3Product code: SC65BAA-[coil][aux] | AC-3 200-240V: 15kW/65A | AC-3 380-440V: 30kW/65A | Thermal current: 100 A
SC-N4Product code: SC80BAA-[coil][aux] | AC-3 200-240V: 18.5kW/80A | AC-3 380-440V: 37kW/80A | Thermal current: 135 A
SC-N5AProduct code: SC93CAA-[coil][aux] | AC-3 200-240V: 22kW/93A | AC-3 380-440V: 45kW/90A | Thermal current: 150 A
SC-N6Product code: SC1CBAA-[coil][aux] | AC-3 200-240V: 30kW/125A | AC-3 380-440V: 55kW/110A | Thermal current: 150 A
SC-N7Product code: SC1FBAA-[coil][aux] | AC-3 200-240V: 37kW/152A | AC-3 380-440V: 75kW/150A | Thermal current: 200 A
SC-N8Product code: SC1JBAA-[coil][aux] | AC-3 200-240V: 45kW/180A | AC-3 380-440V: 90kW/180A | Thermal current: 260 A
SC-N10Product code: SC2CBAA-[coil][aux] | AC-3 200-240V: 55kW/220A | AC-3 380-440V: 110kW/220A | Thermal current: 260 A
SC-N11Product code: SC3ABAA-[coil][aux] | AC-3 200-240V: 75kW/300A | AC-3 380-440V: 150kW/300A | Thermal current: 350 A
SC-N12Product code: SC4ABAA-[coil][aux] | AC-3 200-240V: 110kW/400A | AC-3 380-440V: 200kW/400A | Thermal current: 450 A
SC-N14Product code: SC6ABAA-[coil][aux] | AC-3 200-240V: 150kW/600A | AC-3 380-440V: 300kW/600A | Thermal current: 660 A
SC-N16Product code: SC8ABAA-[coil][aux] | AC-3 200-240V: 200kW/800A | AC-3 380-440V: 400kW/800A | Thermal current: 800 A
