GR Electronics MX Series Compact Inverters (100-750W, AC220V)

GR Electronics MX Series Compact Inverters (100-750W, AC220V)

The GR Electronics MX series are compact panel-mount inverters that run small three-phase induction motors from a single-phase AC220V supply. A front dial and LED display set the frequency, with forward/reverse, multi-speed and relay-status terminals for simple machine control.

Key features

  • Single-phase AC220V 50/60Hz input, three-phase sine-wave PWM output
  • Output frequency 1.0-120 Hz with front speed dial and 4-digit LED display
  • Forward, reverse and multi-speed (P1) run inputs
  • Run and error transistor outputs (CN1) for status or brake relay control
  • Adjustable acceleration/deceleration, torque boost, braking level and PWM frequency
  • Panel-cut mounting with built-in cooling fan

Specifications

Input power AC220V, 50/60Hz
Output 3-phase sine-wave PWM
Output frequency 1.0-120 Hz
Inputs Fx (forward), Rx (reverse), P1 (multi-speed), CM
Outputs Run, Err (transistor), CM1 common
Accel/decel time 0.5-10.0 s
Max frequency setting 20.0-120.0 Hz
PWM frequency 1-6 kHz (F-10)
Front size 60 x 100 mm (MX-3000A/6000A), 72 x 100 mm (MX-9000A)
Source GR Electronics MX-3000A/6000A/9000A instruction sheets
MX-1500A Rated output: 100W | Input: 1-phase AC220V | Freq: 1.0-120 Hz
MX-3000A Rated output: 200W | Input: 1-phase AC220V | Freq: 1.0-120 Hz | Depth: 89.2 mm
MX-6000A Rated output: 400W | Input: 1-phase AC220V | Freq: 1.0-120 Hz | Depth: 101.2 mm
MX-9000A Rated output: 750W | Input: 1-phase AC220V | Freq: 1.0-120 Hz | Depth: 113.2 mm
InvertersGR Electronics
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GR Electronics MX Series Compact Inverters (100-750W, AC220V)

Brand GR Electronics·Inverters

Available part numbers (4)

MX-1500A, MX-3000A, MX-6000A, MX-9000A

How to order

Send the GR Electronics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MX-1500ARated output: 100W | Input: 1-phase AC220V | Freq: 1.0-120 Hz
MX-3000ARated output: 200W | Input: 1-phase AC220V | Freq: 1.0-120 Hz | Depth: 89.2 mm
MX-6000ARated output: 400W | Input: 1-phase AC220V | Freq: 1.0-120 Hz | Depth: 101.2 mm
MX-9000ARated output: 750W | Input: 1-phase AC220V | Freq: 1.0-120 Hz | Depth: 113.2 mm
