Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| KCT-02 | Poles: 2P | Width W1: 51 mm | Width W2: 66 mm | ||
| KCT-03 | Poles: 3P | Width W1: 65.5 mm | Width W2: 80.5 mm | ||
| KCT-04 | Poles: 4P | Width W1: 80 mm | Width W2: 95 mm | ||
| KCT-05 | Poles: 5P | Width W1: 94.5 mm | Width W2: 109.5 mm | ||
| KCT-06 | Poles: 6P | Width W1: 109 mm | Width W2: 124 mm | ||
| KCT-08 | Poles: 8P | Width W1: 138 mm | Width W2: 153 mm | ||
| KCT-10 | Poles: 10P | Width W1: 167 mm | Width W2: 182 mm | ||
| KCT-12 | Poles: 12P | Width W1: 196 mm | Width W2: 211 mm |
Need a different model, or a part not listed here? Send us your parts list →
