Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| CFLNN6060U44-A | a (mm): 14 | H (mm): 60 | W (mm): 60 | L (mm): 350 | l1 (mm): 80 | Insert: F10537 | Clamp & clamp screw: UH25 | Shim: SHF10 | Shim screw: BM510 | Wrench: LW6 | ||
| CFLNN5050T32-A | a (mm): 12 | H (mm): 50 | W (mm): 50 | L (mm): 300 | l1 (mm): 75 | Insert: F13941 | Clamp & clamp screw: UH25 | Shim: SHF13 | Shim screw: BM510 | Wrench: LW6 | ||
| CFLNN4040R25-A | a (mm): 7 | H (mm): 40 | W (mm): 40 | L (mm): 200 | l1 (mm): 40 | Insert: F250723 | Clamp & clamp screw: UH4 | Shim: SHF25 | Shim screw: BM510 | Wrench: LW4 |
Need a different model, or a part not listed here? Send us your parts list →
