Korloy Ceramic Turning Insert CPGN

Korloy Ceramic Turning Insert CPGN

80° rhombic ceramic turning insert (ISO CPGN), positive 11° clearance, without hole, for hardened steel, cast iron and heat-resistant alloys.

Key features

  • Grades offered: CAT10, CW40, CW80
  • Al2O3+TiC(N) mixed ceramic grades for hardened steel and cast iron
  • SiC whisker-reinforced grades for nickel- and cobalt-based alloys

Specifications

Material class Ceramic
Units mm
CPGN090304 CW40 ASA: CPGN 321 | IC (mm): 9.52 | S (mm): 3.18 | RE (mm): 0.4 | Grade: CW40 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
CPGN090304 CW80 ASA: CPGN 321 | IC (mm): 9.52 | S (mm): 3.18 | RE (mm): 0.4 | Grade: CW80 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
CPGN090308 CW40 ASA: CPGN 322 | IC (mm): 9.52 | S (mm): 3.18 | RE (mm): 0.8 | Grade: CW40 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
CPGN090308 CW80 ASA: CPGN 322 | IC (mm): 9.52 | S (mm): 3.18 | RE (mm): 0.8 | Grade: CW80 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
CPGN120408 CAT10 ASA: CPGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CAT10 | Material: Al2O3+TiC | Stock: Yes (from material)
CPGN120408 CW40 ASA: CPGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CW40 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
CPGN120408 CW80 ASA: CPGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CW80 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
Turning InsertsKorloy
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Korloy Ceramic Turning Insert CPGN

Brand Korloy·Turning Inserts

Available part numbers (7)

CPGN090304 CW40, CPGN090304 CW80, CPGN090308 CW40, CPGN090308 CW80, CPGN120408 CAT10, CPGN120408 CW40, CPGN120408 CW80

How to order

Send the Korloy part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CPGN090304 CW40ASA: CPGN 321 | IC (mm): 9.52 | S (mm): 3.18 | RE (mm): 0.4 | Grade: CW40 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
CPGN090304 CW80ASA: CPGN 321 | IC (mm): 9.52 | S (mm): 3.18 | RE (mm): 0.4 | Grade: CW80 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
CPGN090308 CW40ASA: CPGN 322 | IC (mm): 9.52 | S (mm): 3.18 | RE (mm): 0.8 | Grade: CW40 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
CPGN090308 CW80ASA: CPGN 322 | IC (mm): 9.52 | S (mm): 3.18 | RE (mm): 0.8 | Grade: CW80 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
CPGN120408 CAT10ASA: CPGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CAT10 | Material: Al2O3+TiC | Stock: Yes (from material)
CPGN120408 CW40ASA: CPGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CW40 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
CPGN120408 CW80ASA: CPGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CW80 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
