Korloy Ceramic Turning Insert ENGN

Korloy Ceramic Turning Insert ENGN

75° rhombic ceramic turning insert (ISO ENGN), negative (0° clearance), without hole, for hardened steel, cast iron and heat-resistant alloys.

Key features

  • Grades offered: CAT10, CAT20, CAT30, CAT50, CAT90, CA20, CA30, CSN20, CSN30, CSN40, CSN80, CW40, CW80
  • Al2O3+TiC(N) mixed ceramic grades for hardened steel and cast iron
  • Al2O3+ZrO2 grades for finishing and semi-finishing cast iron and steel
  • Si3N4 grades for roughing and high-speed machining of cast iron
  • SiAlON grades for heat-resistant and nickel-based alloys
  • SiC whisker-reinforced grades for nickel- and cobalt-based alloys

Specifications

Material class Ceramic
Units mm
ENGN130408 CAT30 ASA: ENGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130408 CSN20 ASA: ENGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CSN20 | Material: Si3N4 | Stock: Yes (from material)
ENGN130408 CSN40 ASA: ENGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CSN40 | Material: Si3N4 | Stock: Yes (from material)
ENGN130412 CAT30 ASA: ENGN 433 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 1.2 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130412 CSN20 ASA: ENGN 433 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 1.2 | Grade: CSN20 | Material: Si3N4 | Stock: Yes (from material)
ENGN130412 CSN40 ASA: ENGN 433 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 1.2 | Grade: CSN40 | Material: Si3N4 | Stock: Yes (from material)
ENGN130704 CAT10 ASA: ENGN 451 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.4 | Grade: CAT10 | Material: Al2O3+TiC | Stock: Yes (from material)
ENGN130704 CAT30 ASA: ENGN 451 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.4 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130708 CAT10 ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CAT10 | Material: Al2O3+TiC | Stock: Yes (from material)
ENGN130708 CAT30 ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130708 CAT50 ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CAT50 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130708 CAT90 ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CAT90 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130708 CA20 ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CA20 | Material: Al2O3+ZrO2 | Stock: Yes (from material)
ENGN130708 CA30 ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CA30 | Material: Al2O3+ZrO2 | Stock: Yes (from material)
ENGN130708 CSN20 ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CSN20 | Material: Si3N4 | Stock: Yes (from material)
ENGN130708 CSN30 ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CSN30 | Material: Si3N4 | Stock: Yes (from material)
ENGN130708 CSN40 ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CSN40 | Material: Si3N4 | Stock: Yes (from material)
ENGN130712 CAT10 ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CAT10 | Material: Al2O3+TiC | Stock: Yes (from material)
ENGN130712 CAT30 ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130712 CAT50 ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CAT50 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130712 CAT90 ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CAT90 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130712 CSN20 ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CSN20 | Material: Si3N4 | Stock: Yes (from material)
ENGN130712 CSN30 ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CSN30 | Material: Si3N4 | Stock: Yes (from material)
ENGN130712 CSN40 ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CSN40 | Material: Si3N4 | Stock: Yes (from material)
ENGN130712 CSN80 ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CSN80 | Material: SiAlON | Stock: Yes (from material)
ENGN130712 CW40 ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CW40 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
ENGN130712 CW80 ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CW80 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
ENGN130716 CAT10 ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CAT10 | Material: Al2O3+TiC | Stock: Yes (from material)
ENGN130716 CAT20 ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CAT20 | Material: TiC+Al2O3 | Stock: Yes (from material)
ENGN130716 CAT30 ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130716 CSN20 ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CSN20 | Material: Si3N4 | Stock: Yes (from material)
ENGN130716 CSN30 ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CSN30 | Material: Si3N4 | Stock: Yes (from material)
ENGN130716 CSN40 ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CSN40 | Material: Si3N4 | Stock: Yes (from material)
Turning InsertsKorloy
33 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Korloy Ceramic Turning Insert ENGN

Brand Korloy·Turning Inserts

Available part numbers (33)

ENGN130408 CAT30, ENGN130408 CSN20, ENGN130408 CSN40, ENGN130412 CAT30, ENGN130412 CSN20, ENGN130412 CSN40, ENGN130704 CAT10, ENGN130704 CAT30, ENGN130708 CAT10, ENGN130708 CAT30 + 23 more — see full table ↓

How to order

Send the Korloy part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ENGN130408 CAT30ASA: ENGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130408 CSN20ASA: ENGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CSN20 | Material: Si3N4 | Stock: Yes (from material)
ENGN130408 CSN40ASA: ENGN 432 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 0.8 | Grade: CSN40 | Material: Si3N4 | Stock: Yes (from material)
ENGN130412 CAT30ASA: ENGN 433 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 1.2 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130412 CSN20ASA: ENGN 433 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 1.2 | Grade: CSN20 | Material: Si3N4 | Stock: Yes (from material)
ENGN130412 CSN40ASA: ENGN 433 | IC (mm): 12.70 | S (mm): 4.76 | RE (mm): 1.2 | Grade: CSN40 | Material: Si3N4 | Stock: Yes (from material)
ENGN130704 CAT10ASA: ENGN 451 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.4 | Grade: CAT10 | Material: Al2O3+TiC | Stock: Yes (from material)
ENGN130704 CAT30ASA: ENGN 451 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.4 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130708 CAT10ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CAT10 | Material: Al2O3+TiC | Stock: Yes (from material)
ENGN130708 CAT30ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130708 CAT50ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CAT50 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130708 CAT90ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CAT90 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130708 CA20ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CA20 | Material: Al2O3+ZrO2 | Stock: Yes (from material)
ENGN130708 CA30ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CA30 | Material: Al2O3+ZrO2 | Stock: Yes (from material)
ENGN130708 CSN20ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CSN20 | Material: Si3N4 | Stock: Yes (from material)
ENGN130708 CSN30ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CSN30 | Material: Si3N4 | Stock: Yes (from material)
ENGN130708 CSN40ASA: ENGN 452 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 0.8 | Grade: CSN40 | Material: Si3N4 | Stock: Yes (from material)
ENGN130712 CAT10ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CAT10 | Material: Al2O3+TiC | Stock: Yes (from material)
ENGN130712 CAT30ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130712 CAT50ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CAT50 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130712 CAT90ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CAT90 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130712 CSN20ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CSN20 | Material: Si3N4 | Stock: Yes (from material)
ENGN130712 CSN30ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CSN30 | Material: Si3N4 | Stock: Yes (from material)
ENGN130712 CSN40ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CSN40 | Material: Si3N4 | Stock: Yes (from material)
ENGN130712 CSN80ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CSN80 | Material: SiAlON | Stock: Yes (from material)
ENGN130712 CW40ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CW40 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
ENGN130712 CW80ASA: ENGN 453 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.2 | Grade: CW80 | Material: Al2O3+SiC whisker | Stock: Yes (from material)
ENGN130716 CAT10ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CAT10 | Material: Al2O3+TiC | Stock: Yes (from material)
ENGN130716 CAT20ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CAT20 | Material: TiC+Al2O3 | Stock: Yes (from material)
ENGN130716 CAT30ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CAT30 | Material: Al2O3+TiCN | Stock: Yes (from material)
ENGN130716 CSN20ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CSN20 | Material: Si3N4 | Stock: Yes (from material)
ENGN130716 CSN30ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CSN30 | Material: Si3N4 | Stock: Yes (from material)
ENGN130716 CSN40ASA: ENGN 454 | IC (mm): 12.70 | S (mm): 7.94 | RE (mm): 1.6 | Grade: CSN40 | Material: Si3N4 | Stock: Yes (from material)
