Kyongbo Electric AC Voltage Transducer TA / TV-V

Kyongbo Electric AC Voltage Transducer TA / TV-V

AC voltage transducer converting AC voltage to a proportional DC current or voltage signal for remote metering and control systems.

Key features

  • High accuracy
  • Quick response time
  • Low output ripple
  • Input and output fully insulated
  • Readily accessible span and zero adjustment
  • Order-made input, output, aux. power and frequency available

Specifications

Auxiliary Power AC 110 / 220 V
Frequency 50 / 60 Hz
Mounting DIN rail, ABS case
Accuracy 0.2% of span
Ripple 0.5% P-P of span
Response Time 0.4 s (0-99%)
TA-1V1 Circuit: 1P2W | Output Mode: DC current | Output: 0-1 mA | Load: < 10 kOhm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 480 g | Case: TS
TA-1V2 Circuit: 1P2W | Output Mode: DC current | Output: 4-20 mA | Load: < 500 Ohm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 480 g | Case: TS
TA-3V1 Circuit: 3P3W | Output Mode: DC current | Output: 0-1 mA | Load: < 10 kOhm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 860 g | Case: TL
TA-3V2 Circuit: 3P3W | Output Mode: DC current | Output: 4-20 mA | Load: < 500 Ohm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 860 g | Case: TL
TA-4V1 Circuit: 3P4W | Output Mode: DC current | Output: 0-1 mA | Load: < 10 kOhm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 860 g | Case: TL
TA-4V2 Circuit: 3P4W | Output Mode: DC current | Output: 4-20 mA | Load: < 500 Ohm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 860 g | Case: TL
TV-1V1 Circuit: 1P2W | Output Mode: DC voltage | Output: 0-1 V | Load: > 200 Ohm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 480 g | Case: TS
TV-1V2 Circuit: 1P2W | Output Mode: DC voltage | Output: 1-5 V | Load: > 1 kOhm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 480 g | Case: TS
TV-3V1 Circuit: 3P3W | Output Mode: DC voltage | Output: 0-1 V | Load: > 200 Ohm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 860 g | Case: TL
TV-3V2 Circuit: 3P3W | Output Mode: DC voltage | Output: 1-5 V | Load: > 1 kOhm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 860 g | Case: TL
TV-4V1 Circuit: 3P4W | Output Mode: DC voltage | Output: 0-1 V | Load: > 200 Ohm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 860 g | Case: TL
TV-4V2 Circuit: 3P4W | Output Mode: DC voltage | Output: 1-5 V | Load: > 1 kOhm | Rated Input: AC 150 V or 300 V | Burden: 1.0 VA/phase | Weight: approx. 860 g | Case: TL
TA-1V1T Circuit: 1P2W | Output Mode: DC current | Output: 0-1 mA | Load: < 10 kOhm | Rated Input: AC 150 V or 300 V | Sensing: True RMS (crest factor 1:1 to 3:1) | Burden: 1.0 VA | Weight: approx. 480 g | Case: TS
TA-1V2T Circuit: 1P2W | Output Mode: DC current | Output: 4-20 mA | Load: < 500 Ohm | Rated Input: AC 150 V or 300 V | Sensing: True RMS (crest factor 1:1 to 3:1) | Burden: 1.0 VA | Weight: approx. 480 g | Case: TS
TV-1V1T Circuit: 1P2W | Output Mode: DC voltage | Output: 0-1 V | Load: > 200 Ohm | Rated Input: AC 150 V or 300 V | Sensing: True RMS (crest factor 1:1 to 3:1) | Burden: 1.0 VA | Weight: approx. 480 g | Case: TS
TV-1V2T Circuit: 1P2W | Output Mode: DC voltage | Output: 1-5 V | Load: > 1 kOhm | Rated Input: AC 150 V or 300 V | Sensing: True RMS (crest factor 1:1 to 3:1) | Burden: 1.0 VA | Weight: approx. 480 g | Case: TS
