Kyongbo Electric DC Isolating Transducer TA / TV-D

Kyongbo Electric DC Isolating Transducer TA / TV-D

DC isolating transducer converting a DC current or voltage signal into an isolated DC current or voltage output.

Key features

  • High accuracy
  • Quick response time
  • Low output ripple
  • Input and output fully insulated
  • Readily accessible span and zero adjustment
  • Order-made input, output, aux. power and frequency available

Specifications

Accuracy 0.2% of span
Response Time 0.4 s (0-99%)
Burden 0.5 VA
Auxiliary Power AC 110 / 220 V
Weight approx. 780 g
Case TL
TA-DA1 Output Mode: DC current | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: 0-1 mA | Load: < 10 kOhm
TA-DA2 Output Mode: DC current | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: 4-20 mA | Load: < 500 Ohm
TA-DA3 Output Mode: DC current | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: -1-0-+1 mA | Load: < 5 kOhm
TA-DV1 Output Mode: DC current | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: 0-1 mA | Load: < 10 kOhm
TA-DV2 Output Mode: DC current | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: 4-20 mA | Load: < 500 Ohm
TA-DV3 Output Mode: DC current | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: -1-0-+1 mA | Load: < 5 kOhm
TV-DA1 Output Mode: DC voltage | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: 0-1 V | Load: > 200 Ohm
TV-DA2 Output Mode: DC voltage | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: 1-5 V | Load: > 1 kOhm
TV-DA3 Output Mode: DC voltage | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: -1-0-+1 V | Load: > 200 Ohm
TV-DV1 Output Mode: DC voltage | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: 0-1 V | Load: > 200 Ohm
TV-DV2 Output Mode: DC voltage | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: 1-5 V | Load: > 1 kOhm
TV-DV3 Output Mode: DC voltage | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: -1-0-+1 V | Load: > 200 Ohm
Power TransducersKyongbo Electric
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Kyongbo Electric DC Isolating Transducer TA / TV-D

Brand Kyongbo Electric·Power Transducers

Available part numbers (12)

TA-DA1, TA-DA2, TA-DA3, TA-DV1, TA-DV2, TA-DV3, TV-DA1, TV-DA2, TV-DA3, TV-DV1 + 2 more — see full table ↓

How to order

Send the Kyongbo Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TA-DA1Output Mode: DC current | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: 0-1 mA | Load: < 10 kOhm
TA-DA2Output Mode: DC current | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: 4-20 mA | Load: < 500 Ohm
TA-DA3Output Mode: DC current | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: -1-0-+1 mA | Load: < 5 kOhm
TA-DV1Output Mode: DC current | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: 0-1 mA | Load: < 10 kOhm
TA-DV2Output Mode: DC current | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: 4-20 mA | Load: < 500 Ohm
TA-DV3Output Mode: DC current | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: -1-0-+1 mA | Load: < 5 kOhm
TV-DA1Output Mode: DC voltage | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: 0-1 V | Load: > 200 Ohm
TV-DA2Output Mode: DC voltage | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: 1-5 V | Load: > 1 kOhm
TV-DA3Output Mode: DC voltage | Rated Input: DC 0-1 mA or 4-20 mA | Input Resistance: < 10 kOhm or < 500 Ohm | Output: -1-0-+1 V | Load: > 200 Ohm
TV-DV1Output Mode: DC voltage | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: 0-1 V | Load: > 200 Ohm
TV-DV2Output Mode: DC voltage | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: 1-5 V | Load: > 1 kOhm
TV-DV3Output Mode: DC voltage | Rated Input: DC 0-1 V or 1-5 V | Input Resistance: > 200 Ohm or > 1 kOhm | Output: -1-0-+1 V | Load: > 200 Ohm
