Kyongbo Electric Power Factor Transducer TA / TV-P and TDA / TDV-P

Kyongbo Electric Power Factor Transducer TA / TV-P and TDA / TDV-P

Power factor transducer converting power factor (lead 0.5 - 1 - lag 0.5) into a proportional DC current or voltage signal, in balanced analog and unbalanced digital types.

Key features

  • High accuracy
  • Quick response time
  • Low output ripple
  • Input and output fully insulated
  • Readily accessible span and zero adjustment
  • Order-made input, output, aux. power and frequency available

Specifications

Auxiliary Power AC 110 / 220 V
Frequency 50 or 60 Hz
Mounting DIN rail, ABS case
Accuracy 0.5% of span
Ripple 0.5% P-P of span
Input Range cos phi lead 0.5 - 1 - lag 0.5
TA-1P1 Circuit: 1P2W | Output Mode: DC current | Output: 0-0.5-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TA-1P2 Circuit: 1P2W | Output Mode: DC current | Output: 4-12-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TA-1P3 Circuit: 1P2W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TA-2P1 Circuit: 1P3W | Output Mode: DC current | Output: 0-0.5-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-2P2 Circuit: 1P3W | Output Mode: DC current | Output: 4-12-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-2P3 Circuit: 1P3W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-3P1 Circuit: 3P3W | Output Mode: DC current | Output: 0-0.5-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-3P2 Circuit: 3P3W | Output Mode: DC current | Output: 4-12-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-3P3 Circuit: 3P3W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-4P1 Circuit: 3P4W | Output Mode: DC current | Output: 0-0.5-1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TA-4P2 Circuit: 3P4W | Output Mode: DC current | Output: 4-12-20 mA | Load: < 500 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TA-4P3 Circuit: 3P4W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TV-1P1 Circuit: 1P2W | Output Mode: DC voltage | Output: 0-0.5-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TV-1P2 Circuit: 1P2W | Output Mode: DC voltage | Output: 1-3-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TV-1P3 Circuit: 1P2W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TV-2P1 Circuit: 1P3W | Output Mode: DC voltage | Output: 0-0.5-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-2P2 Circuit: 1P3W | Output Mode: DC voltage | Output: 1-3-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-2P3 Circuit: 1P3W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-3P1 Circuit: 3P3W | Output Mode: DC voltage | Output: 0-0.5-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-3P2 Circuit: 3P3W | Output Mode: DC voltage | Output: 1-3-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-3P3 Circuit: 3P3W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-4P1 Circuit: 3P4W | Output Mode: DC voltage | Output: 0-0.5-1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TV-4P2 Circuit: 3P4W | Output Mode: DC voltage | Output: 1-3-5 V | Load: > 1 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TV-4P3 Circuit: 3P4W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TDA-4P1 Circuit: 3P4W | Output Mode: DC current | Output: 0-0.5-1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
TDA-4P2 Circuit: 3P4W | Output Mode: DC current | Output: 4-12-20 mA | Load: < 500 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
TDA-4P3 Circuit: 3P4W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
TDV-4P1 Circuit: 3P4W | Output Mode: DC voltage | Output: 0-0.5-1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
TDV-4P2 Circuit: 3P4W | Output Mode: DC voltage | Output: 1-3-5 V | Load: > 1 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
TDV-4P3 Circuit: 3P4W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
Power TransducersKyongbo Electric
30 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Kyongbo Electric Power Factor Transducer TA / TV-P and TDA / TDV-P

Brand Kyongbo Electric·Power Transducers

Available part numbers (30)

TA-1P1, TA-1P2, TA-1P3, TA-2P1, TA-2P2, TA-2P3, TA-3P1, TA-3P2, TA-3P3, TA-4P1 + 20 more — see full table ↓

How to order

Send the Kyongbo Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
TA-1P1Circuit: 1P2W | Output Mode: DC current | Output: 0-0.5-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TA-1P2Circuit: 1P2W | Output Mode: DC current | Output: 4-12-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TA-1P3Circuit: 1P2W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TA-2P1Circuit: 1P3W | Output Mode: DC current | Output: 0-0.5-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-2P2Circuit: 1P3W | Output Mode: DC current | Output: 4-12-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-2P3Circuit: 1P3W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-3P1Circuit: 3P3W | Output Mode: DC current | Output: 0-0.5-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-3P2Circuit: 3P3W | Output Mode: DC current | Output: 4-12-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-3P3Circuit: 3P3W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TA-4P1Circuit: 3P4W | Output Mode: DC current | Output: 0-0.5-1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TA-4P2Circuit: 3P4W | Output Mode: DC current | Output: 4-12-20 mA | Load: < 500 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TA-4P3Circuit: 3P4W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TV-1P1Circuit: 1P2W | Output Mode: DC voltage | Output: 0-0.5-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TV-1P2Circuit: 1P2W | Output Mode: DC voltage | Output: 1-3-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TV-1P3Circuit: 1P2W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 700 g | Case: TL
TV-2P1Circuit: 1P3W | Output Mode: DC voltage | Output: 0-0.5-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-2P2Circuit: 1P3W | Output Mode: DC voltage | Output: 1-3-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-2P3Circuit: 1P3W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-3P1Circuit: 3P3W | Output Mode: DC voltage | Output: 0-0.5-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-3P2Circuit: 3P3W | Output Mode: DC voltage | Output: 1-3-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-3P3Circuit: 3P3W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 850 g | Case: TL
TV-4P1Circuit: 3P4W | Output Mode: DC voltage | Output: 0-0.5-1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TV-4P2Circuit: 3P4W | Output Mode: DC voltage | Output: 1-3-5 V | Load: > 1 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TV-4P3Circuit: 3P4W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Balanced (analog) | Weight: approx. 760 g | Case: TL
TDA-4P1Circuit: 3P4W | Output Mode: DC current | Output: 0-0.5-1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
TDA-4P2Circuit: 3P4W | Output Mode: DC current | Output: 4-12-20 mA | Load: < 500 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
TDA-4P3Circuit: 3P4W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
TDV-4P1Circuit: 3P4W | Output Mode: DC voltage | Output: 0-0.5-1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
TDV-4P2Circuit: 3P4W | Output Mode: DC voltage | Output: 1-3-5 V | Load: > 1 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
TDV-4P3Circuit: 3P4W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Type: Unbalanced (digital) | Response Time: 2.0 s | Weight: approx. 910 g | Case: TL
