Kyongbo Electric var Transducer TA / TV-R

Kyongbo Electric var Transducer TA / TV-R

var transducer converting reactive power of 1-phase or 3-phase AC circuits into a proportional DC current or voltage signal.

Key features

  • High accuracy
  • Quick response time
  • Low output ripple
  • Input and output fully insulated
  • Readily accessible span and zero adjustment
  • Order-made input, output, aux. power and frequency available

Specifications

Auxiliary Power AC 110 / 220 V
Frequency 50 / 60 Hz
Mounting DIN rail, ABS case
Accuracy 0.2% of span
Ripple 0.5% P-P of span
Response Time 0.4 s (0-99%)
Burden Current 1.0 VA/phase, voltage 0.5 VA/phase
TA-1R1 Circuit: 1P2W | Output Mode: DC current | Output: 0-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 700 g | Case: TL
TA-1R2 Circuit: 1P2W | Output Mode: DC current | Output: 4-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 700 g | Case: TL
TA-1R3 Circuit: 1P2W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 700 g | Case: TL
TA-2R1 Circuit: 1P3W | Output Mode: DC current | Output: 0-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TA-2R2 Circuit: 1P3W | Output Mode: DC current | Output: 4-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TA-2R3 Circuit: 1P3W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TA-3R1 Circuit: 3P3W | Output Mode: DC current | Output: 0-1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TA-3R2 Circuit: 3P3W | Output Mode: DC current | Output: 4-20 mA | Load: < 500 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TA-3R3 Circuit: 3P3W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TA-4R1 Circuit: 3P4W | Output Mode: DC current | Output: 0-1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Weight: approx. 1030 g | Case: TL
TA-4R2 Circuit: 3P4W | Output Mode: DC current | Output: 4-20 mA | Load: < 500 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Weight: approx. 1030 g | Case: TL
TA-4R3 Circuit: 3P4W | Output Mode: DC current | Output: -1-0-+1 mA | Load: < 10 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Weight: approx. 1030 g | Case: TL
TV-1R1 Circuit: 1P2W | Output Mode: DC voltage | Output: 0-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 700 g | Case: TL
TV-1R2 Circuit: 1P2W | Output Mode: DC voltage | Output: 1-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 700 g | Case: TL
TV-1R3 Circuit: 1P2W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 700 g | Case: TL
TV-2R1 Circuit: 1P3W | Output Mode: DC voltage | Output: 0-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TV-2R2 Circuit: 1P3W | Output Mode: DC voltage | Output: 1-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TV-2R3 Circuit: 1P3W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TV-3R1 Circuit: 3P3W | Output Mode: DC voltage | Output: 0-1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TV-3R2 Circuit: 3P3W | Output Mode: DC voltage | Output: 1-5 V | Load: > 1 kOhm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TV-3R3 Circuit: 3P3W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 110 V or 220 V | Rated Current: 5 A or 1 A | Weight: approx. 850 g | Case: TL
TV-4R1 Circuit: 3P4W | Output Mode: DC voltage | Output: 0-1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Weight: approx. 1030 g | Case: TL
TV-4R2 Circuit: 3P4W | Output Mode: DC voltage | Output: 1-5 V | Load: > 1 kOhm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Weight: approx. 1030 g | Case: TL
TV-4R3 Circuit: 3P4W | Output Mode: DC voltage | Output: -1-0-+1 V | Load: > 200 Ohm | Rated Voltage: 190/sqrt3 V | Rated Current: 5 A or 1 A | Weight: approx. 1030 g | Case: TL
Power TransducersKyongbo Electric
24 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
