LS Electric GLOFA-GM6/K200S CPU, Power and Bases (Discontinued)

Discontinued LS Electric GLOFA-GM6 and MASTER-K200S modular PLC CPU modules, power supplies, base boards and dummy modules (discontinued January 2019), supplied as spare parts.

Key features

Small modular PLC with up to 384 I/O points
GM6 CPU with 68 KB memory (IEC LD/IL/SFC, GMWIN); K200S CPU with 7k steps (KGLWIN)
CPU A/B/C types with RS-232C or RS-422, PID, RTC and high-speed counter options
Free-voltage AC, AC 220 V or DC 12/24 V power supplies; B/PDFB types required for analog modules
4, 6, 8 or 12 slot base boards (no expansion base)

Specifications

Max. I/O	384 points
Processing speed	0.5 us/step
Shared hardware	Power, bases and I/O common to GM6 and K200S
Discontinued	January 2019
Status	Spare-parts supply
Source	LS Electric A016_GLOFA_GM_181227.pdf, p. 55; A020_MASTER_K_____1910.pdf, p. 56

GM6-CPUA		Module: CPU \| Series: GLOFA-GM6 \| Specification: 68 KB memory; RS-232C
GM6-CPUB		Module: CPU \| Series: GLOFA-GM6 \| Specification: 68 KB memory; RS-422, PID, RTC
GM6-CPUC		Module: CPU \| Series: GLOFA-GM6 \| Specification: 68 KB memory; RS-232C, PID, HSC, RTC
K3P-07AS		Module: CPU \| Series: MASTER-K200S \| Specification: 7k steps; RS-232C
K3P-07BS		Module: CPU \| Series: MASTER-K200S \| Specification: 7k steps; RS-422, PID, RTC
K3P-07CS		Module: CPU \| Series: MASTER-K200S \| Specification: 7k steps; RS-232C, PID, HSC, RTC
GM6-PAFA		Module: Power supply \| Series: GM6/K200S \| Specification: AC free volt; 5V 2A, 24V 0.3A
GM6-PAFB		Module: Power supply \| Series: GM6/K200S \| Specification: AC free volt; 5V 2A, +/-15V (analog)
GM6-PAFC		Module: Power supply \| Series: GM6/K200S \| Specification: AC free volt; 5V 3.5A, 24V 0.3A
GM6-PA2A		Module: Power supply \| Series: GM6/K200S \| Specification: AC 220 V; 5V 6A
GM6-PDFA		Module: Power supply \| Series: GM6/K200S \| Specification: DC 12/24 V; 5V 2A
GM6-PDFB		Module: Power supply \| Series: GM6/K200S \| Specification: DC 12/24 V; 5V 3A, +/-15V (analog)
GM6-B04M		Module: Base \| Series: GM6/K200S \| Specification: 4 I/O slots, no expansion
GM6-B06M		Module: Base \| Series: GM6/K200S \| Specification: 6 I/O slots, no expansion
GM6-B08M		Module: Base \| Series: GM6/K200S \| Specification: 8 I/O slots, no expansion
GM6-B12M		Module: Base \| Series: GM6/K200S \| Specification: 12 I/O slots, no expansion
GM6-DMMA		Module: Dummy module \| Series: GM6/K200S \| Specification: Dust cover for empty slot

PLCsLS Electric

17 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric GLOFA-GM6/K200S CPU, Power and Bases (Discontinued)

Brand LS Electric·PLCs

Available part numbers (17)

GM6-CPUA, GM6-CPUB, GM6-CPUC, K3P-07AS, K3P-07BS, K3P-07CS, GM6-PAFA, GM6-PAFB, GM6-PAFC, GM6-PA2A + 7 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
