LS Electric G7F Analog and Special Expansion Modules (Discontinued)

LS Electric G7F Analog and Special Expansion Modules (Discontinued)

Discontinued LS Electric G7F analog input/output, RTD and analog timer expansion modules for GLOFA-GM7U/GM7 and MASTER-K120S/K80S block PLCs, supplied as spare parts.

Key features

  • Analog input, output and combined input/output modules
  • RTD temperature input module (G7F-RD2A)
  • Analog timer module with 4 setting points (G7F-AT2A)
  • Slim versions for GM7U/K120S main units
  • Up to 3 special modules per system

Specifications

Module power DC 24 V external supply
Max. modules 3 special modules
Series GLOFA-GM7U / MASTER-K120S
Status Discontinued; spare-parts supply
Source LS Electric A016_GLOFA_GM_181227.pdf, p. 25, 56; A019_MK120S_K_0607.pdf, p. 29; A020_MASTER_K_____1910.pdf, p. 55
G7F-ADHA Function: Analog input/output | Channels: 2 in + 1 out | Form factor: Standard | Compatible with: GM7/GM7U/K80S/K120S
G7F-ADHB Function: Analog input/output | Channels: 2 in + 2 out | Form factor: Slim | Compatible with: GM7U/K120S only
G7F-ADHC Function: Analog input/output | Channels: 1 in + 1 out | Form factor: Standard | Compatible with: K120S only
G7F-AD2A Function: Analog input | Channels: 4 in | Form factor: Standard | Compatible with: GM7U/K120S; K80S V1.4+
G7F-AD2B Function: Analog input | Channels: 4 in | Form factor: Slim | Compatible with: GM7U/K120S only
G7F-DA2I Function: Analog current output | Channels: 4 out | Form factor: Standard | Compatible with: GM7/GM7U/K80S/K120S
G7F-DA2V Function: Analog voltage output | Channels: 4 out | Form factor: Slim | Compatible with: GM7U/K120S only
G7F-RD2A Function: RTD input | Channels: 4 in | Form factor: Slim | Compatible with: GM7U/K120S only
G7F-AT2A Function: Analog timer | Channels: 4 points | Form factor: Standard | Compatible with: GM7U/K120S; K80S V1.8+
PLC I/O ModulesLS Electric
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric G7F Analog and Special Expansion Modules (Discontinued)

Brand LS Electric·PLC I/O Modules

Available part numbers (9)

G7F-ADHA, G7F-ADHB, G7F-ADHC, G7F-AD2A, G7F-AD2B, G7F-DA2I, G7F-DA2V, G7F-RD2A, G7F-AT2A

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
G7F-ADHAFunction: Analog input/output | Channels: 2 in + 1 out | Form factor: Standard | Compatible with: GM7/GM7U/K80S/K120S
G7F-ADHBFunction: Analog input/output | Channels: 2 in + 2 out | Form factor: Slim | Compatible with: GM7U/K120S only
G7F-ADHCFunction: Analog input/output | Channels: 1 in + 1 out | Form factor: Standard | Compatible with: K120S only
G7F-AD2AFunction: Analog input | Channels: 4 in | Form factor: Standard | Compatible with: GM7U/K120S; K80S V1.4+
G7F-AD2BFunction: Analog input | Channels: 4 in | Form factor: Slim | Compatible with: GM7U/K120S only
G7F-DA2IFunction: Analog current output | Channels: 4 out | Form factor: Standard | Compatible with: GM7/GM7U/K80S/K120S
G7F-DA2VFunction: Analog voltage output | Channels: 4 out | Form factor: Slim | Compatible with: GM7U/K120S only
G7F-RD2AFunction: RTD input | Channels: 4 in | Form factor: Slim | Compatible with: GM7U/K120S only
G7F-AT2AFunction: Analog timer | Channels: 4 points | Form factor: Standard | Compatible with: GM7U/K120S; K80S V1.8+
