LS Electric GMC-D 2/3-Pole Definite Purpose Contactor (20-25 A)

LS Electric GMC-D 2/3-Pole Definite Purpose Contactor (20-25 A)

LS Electric GMC-20D2/D3 and GMC-25D2/D3 definite purpose contactors rated 20 A and 25 A, in 2-pole (2a), 3-pole 2a1b and 3-pole (3a) versions for HVAC, refrigeration and heating loads.

Key features

  • 2-pole 2NO, 3-pole 2NO+1NC or 3-pole 3NO contact configurations
  • AC-3 ratings 20 A and 25 A at 200-220 V; AC-4 ratings 18 A and 20 A
  • NC contact (2a1b) rated AC-15 6 A at 120 V
  • Compact, lightweight design with operation indicator
  • AC 60 Hz coil, 24/48/110/220 V

Specifications

Rated insulation voltage AC 690 V / DC 250 V
Coil frequency 60 Hz
Coil consumption 72 VA inrush / 9 VA sealed, 3 W
Pick-up / drop-out 83% or less / 20% or more of Uc
Operating time ON 30 ms / OFF 20 ms
Source LS Electric Metasol MS catalog C04001-37 (2026-09), p. 84
GMC-20D2/AC24V Model: GMC-20D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-20D2/AC48V Model: GMC-20D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-20D2/AC110V Model: GMC-20D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-20D2/AC220V Model: GMC-20D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 220 V 60 Hz
GMC-20D2/2a1b/AC24V Model: GMC-20D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-20D2/2a1b/AC48V Model: GMC-20D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-20D2/2a1b/AC110V Model: GMC-20D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-20D2/2a1b/AC220V Model: GMC-20D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 220 V 60 Hz
GMC-20D3/AC24V Model: GMC-20D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-20D3/AC48V Model: GMC-20D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-20D3/AC110V Model: GMC-20D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-20D3/AC220V Model: GMC-20D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 220 V 60 Hz
GMC-25D2/AC24V Model: GMC-25D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-25D2/AC48V Model: GMC-25D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-25D2/AC110V Model: GMC-25D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-25D2/AC220V Model: GMC-25D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 220 V 60 Hz
GMC-25D2/2a1b/AC24V Model: GMC-25D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-25D2/2a1b/AC48V Model: GMC-25D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-25D2/2a1b/AC110V Model: GMC-25D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-25D2/2a1b/AC220V Model: GMC-25D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 220 V 60 Hz
GMC-25D3/AC24V Model: GMC-25D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-25D3/AC48V Model: GMC-25D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-25D3/AC110V Model: GMC-25D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-25D3/AC220V Model: GMC-25D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 220 V 60 Hz
Magnetic ContactorsLS Electric
24 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric GMC-D 2/3-Pole Definite Purpose Contactor (20-25 A)

Brand LS Electric·Magnetic Contactors

Available part numbers (24)

GMC-20D2/AC24V, GMC-20D2/AC48V, GMC-20D2/AC110V, GMC-20D2/AC220V, GMC-20D2/2a1b/AC24V, GMC-20D2/2a1b/AC48V, GMC-20D2/2a1b/AC110V, GMC-20D2/2a1b/AC220V, GMC-20D3/AC24V, GMC-20D3/AC48V + 14 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GMC-20D2/AC24VModel: GMC-20D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-20D2/AC48VModel: GMC-20D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-20D2/AC110VModel: GMC-20D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-20D2/AC220VModel: GMC-20D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 220 V 60 Hz
GMC-20D2/2a1b/AC24VModel: GMC-20D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-20D2/2a1b/AC48VModel: GMC-20D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-20D2/2a1b/AC110VModel: GMC-20D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-20D2/2a1b/AC220VModel: GMC-20D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 220 V 60 Hz
GMC-20D3/AC24VModel: GMC-20D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-20D3/AC48VModel: GMC-20D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-20D3/AC110VModel: GMC-20D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-20D3/AC220VModel: GMC-20D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 20 A at 200-220V | Coil voltage: AC 220 V 60 Hz
GMC-25D2/AC24VModel: GMC-25D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-25D2/AC48VModel: GMC-25D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-25D2/AC110VModel: GMC-25D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-25D2/AC220VModel: GMC-25D2 | Poles: 2 | Contacts: 2NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 220 V 60 Hz
GMC-25D2/2a1b/AC24VModel: GMC-25D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-25D2/2a1b/AC48VModel: GMC-25D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-25D2/2a1b/AC110VModel: GMC-25D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-25D2/2a1b/AC220VModel: GMC-25D2 | Poles: 3 | Contacts: 2NO+1NC | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 220 V 60 Hz
GMC-25D3/AC24VModel: GMC-25D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 24 V 60 Hz
GMC-25D3/AC48VModel: GMC-25D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 48 V 60 Hz
GMC-25D3/AC110VModel: GMC-25D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 110 V 60 Hz
GMC-25D3/AC220VModel: GMC-25D3 | Poles: 3 | Contacts: 3NO | AC-3 rated current: 25 A at 200-220V | Coil voltage: AC 220 V 60 Hz
