LS Electric Metasol ACB Cradle for Draw-out Breakers (630-6300AF)

LS Electric Metasol ACB Cradle for Draw-out Breakers (630-6300AF)

LS Electric Metasol ACB cradles (AL type) that house draw-out AN/AS breakers and DN/DS switch-disconnectors in the switchboard.

Key features

  • Cradles for AN-D/E and AS-D/E/F/G frames from 630 to 6300AF, 3-pole and 4-pole
  • Busbar connection: horizontal, vertical, mixed top/bottom or front (flat) type
  • Optional safety shutter (F) and arc cover (S) built into the order code
  • Three draw-out positions: CONNECTED, TEST, DISCONNECTED
  • Ordering code e.g. AL-N16D3-JHEN; position switches and cradle accessories ordered separately

Specifications

Product Cradle for draw-out Metasol ACB
Frames D, E, F, G (630-6300AF)
Restrictions AS-20D, AS-40E vertical busbar only; front (flat) type not for 20D, 40E, F, G
Front-type terminal Ordered separately
Source LS Electric Metasol ACB catalog C06091-28 (2026.07), p. 16
AL-N16D3-JHEN For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-JHES For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-JHFN For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-JHFS For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-JVEN For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-JVES For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-JVFN For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-JVFS For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-JMEN For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-JMES For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-JMFN For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-JMFS For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-JNEN For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-JNES For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-JNFN For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-JNFS For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-JPEN For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-JPES For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-JPFN For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-JPFS For breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-AHEN For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-AHES For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-AHFN For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-AHFS For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-AVEN For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-AVES For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-AVFN For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-AVFS For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-AMEN For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-AMES For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-AMFN For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-AMFS For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-ANEN For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-ANES For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-ANFN For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-ANFS For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-APEN For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-APES For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-APFN For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-APFS For breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-JHEN For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-JHES For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-JHFN For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-JHFS For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-JVEN For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-JVES For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-JVFN For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-JVFS For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-JMEN For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-JMES For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-JMFN For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-JMFS For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-JNEN For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-JNES For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-JNFN For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-JNFS For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-JPEN For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-JPES For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-JPFN For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-JPFS For breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-AHEN For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-AHES For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-AHFN For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-AHFS For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-AVEN For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-AVES For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-AVFN For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-AVFS For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-AMEN For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-AMES For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-AMFN For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-AMFS For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-ANEN For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-ANES For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-ANFN For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-ANFS For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-APEN For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-APES For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-APFN For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-APFS For breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-JHEN For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-JHES For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-JHFN For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-JHFS For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-JVEN For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-JVES For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-JVFN For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-JVFS For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-JMEN For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-JMES For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-JMFN For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-JMFS For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-JNEN For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-JNES For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-JNFN For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-JNFS For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-JPEN For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-JPES For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-JPFN For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-JPFS For breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-AHEN For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-AHES For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-AHFN For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-AHFS For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-AVEN For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-AVES For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-AVFN For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-AVFS For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-AMEN For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-AMES For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-AMFN For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-AMFS For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-ANEN For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-ANES For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-ANFN For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-ANFS For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-APEN For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-APES For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-APFN For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-APFS For breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-JHEN For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-JHES For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-JHFN For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-JHFS For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-JVEN For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-JVES For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-JVFN For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-JVFS For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-JMEN For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-JMES For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-JMFN For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-JMFS For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-JNEN For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-JNES For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-JNFN For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-JNFS For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-JPEN For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-JPES For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-JPFN For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-JPFS For breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-AHEN For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-AHES For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-AHFN For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-AHFS For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-AVEN For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-AVES For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-AVFN For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-AVFS For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-AMEN For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-AMES For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-AMFN For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-AMFS For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-ANEN For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-ANES For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-ANFN For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-ANFS For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-APEN For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-APES For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-APFN For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-APFS For breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S20D3-JVEN For breaker: AS-20D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S20D3-JVES For breaker: AS-20D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S20D3-JVFN For breaker: AS-20D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S20D3-JVFS For breaker: AS-20D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S20D3-AVEN For breaker: AS-20D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S20D3-AVES For breaker: AS-20D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S20D3-AVFN For breaker: AS-20D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S20D3-AVFS For breaker: AS-20D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S20D4-JVEN For breaker: AS-20D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S20D4-JVES For breaker: AS-20D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S20D4-JVFN For breaker: AS-20D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S20D4-JVFS For breaker: AS-20D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S20D4-AVEN For breaker: AS-20D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S20D4-AVES For breaker: AS-20D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S20D4-AVFN For breaker: AS-20D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S20D4-AVFS For breaker: AS-20D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-JHEN For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-JHES For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-JHFN For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-JHFS For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-JVEN For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-JVES For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-JVFN For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-JVFS For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-JMEN For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-JMES For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-JMFN For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-JMFS For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-JNEN For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-JNES For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-JNFN For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-JNFS For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-JPEN For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-JPES For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-JPFN For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-JPFS For breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-AHEN For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-AHES For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-AHFN For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-AHFS For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-AVEN For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-AVES For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-AVFN For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-AVFS For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-AMEN For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-AMES For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-AMFN For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-AMFS For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-ANEN For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-ANES For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-ANFN For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-ANFS For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-APEN For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-APES For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-APFN For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-APFS For breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-JHEN For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-JHES For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-JHFN For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-JHFS For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-JVEN For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-JVES For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-JVFN For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-JVFS For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-JMEN For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-JMES For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-JMFN For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-JMFS For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-JNEN For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-JNES For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-JNFN For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-JNFS For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-JPEN For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-JPES For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-JPFN For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-JPFS For breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-AHEN For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-AHES For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-AHFN For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-AHFS For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-AVEN For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-AVES For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-AVFN For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-AVFS For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-AMEN For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-AMES For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-AMFN For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-AMFS For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-ANEN For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-ANES For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-ANFN For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-ANFS For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-APEN For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-APES For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-APFN For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-APFS For breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-JHEN For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-JHES For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-JHFN For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-JHFS For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-JVEN For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-JVES For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-JVFN For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-JVFS For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-JMEN For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-JMES For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-JMFN For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-JMFS For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-JNEN For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-JNES For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-JNFN For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-JNFS For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-JPEN For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-JPES For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-JPFN For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-JPFS For breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-AHEN For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-AHES For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-AHFN For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-AHFS For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-AVEN For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-AVES For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-AVFN For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-AVFS For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-AMEN For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-AMES For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-AMFN For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-AMFS For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-ANEN For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-ANES For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-ANFN For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-ANFS For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-APEN For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-APES For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-APFN For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-APFS For breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-JHEN For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-JHES For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-JHFN For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-JHFS For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-JVEN For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-JVES For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-JVFN For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-JVFS For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-JMEN For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-JMES For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-JMFN For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-JMFS For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-JNEN For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-JNES For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-JNFN For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-JNFS For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-JPEN For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-JPES For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-JPFN For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-JPFS For breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-AHEN For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-AHES For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-AHFN For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-AHFS For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-AVEN For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-AVES For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-AVFN For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-AVFS For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-AMEN For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-AMES For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-AMFN For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-AMFS For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-ANEN For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-ANES For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-ANFN For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-ANFS For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-APEN For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-APES For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-APFN For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-APFS For breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-JHEN For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-JHES For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-JHFN For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-JHFS For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-JVEN For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-JVES For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-JVFN For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-JVFS For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-JMEN For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-JMES For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-JMFN For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-JMFS For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-JNEN For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-JNES For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-JNFN For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-JNFS For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-JPEN For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-JPES For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-JPFN For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-JPFS For breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-AHEN For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-AHES For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-AHFN For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-AHFS For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-AVEN For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-AVES For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-AVFN For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-AVFS For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-AMEN For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-AMES For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-AMFN For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-AMFS For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-ANEN For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-ANES For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-ANFN For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-ANFS For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-APEN For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-APES For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-APFN For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-APFS For breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-JHEN For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-JHES For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-JHFN For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-JHFS For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-JVEN For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-JVES For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-JVFN For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-JVFS For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-JMEN For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-JMES For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-JMFN For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-JMFS For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-JNEN For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-JNES For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-JNFN For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-JNFS For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-JPEN For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-JPES For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-JPFN For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-JPFS For breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-AHEN For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-AHES For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-AHFN For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-AHFS For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-AVEN For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-AVES For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-AVFN For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-AVFS For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-AMEN For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-AMES For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-AMFN For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-AMFS For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-ANEN For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-ANES For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-ANFN For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-ANFS For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-APEN For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-APES For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-APFN For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-APFS For breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-JHEN For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-JHES For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-JHFN For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-JHFS For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-JVEN For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-JVES For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-JVFN For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-JVFS For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-JMEN For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-JMES For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-JMFN For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-JMFS For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-JNEN For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-JNES For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-JNFN For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-JNFS For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-JPEN For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-JPES For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-JPFN For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-JPFS For breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-AHEN For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-AHES For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-AHFN For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-AHFS For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-AVEN For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-AVES For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-AVFN For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-AVFS For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-AMEN For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-AMES For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-AMFN For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-AMFS For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-ANEN For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-ANES For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-ANFN For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-ANFS For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-APEN For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-APES For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-APFN For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-APFS For breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-JHEN For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-JHES For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-JHFN For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-JHFS For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-JVEN For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-JVES For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-JVFN For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-JVFS For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-JMEN For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-JMES For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-JMFN For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-JMFS For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-JNEN For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-JNES For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-JNFN For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-JNFS For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-JPEN For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-JPES For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-JPFN For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-JPFS For breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-AHEN For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-AHES For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-AHFN For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-AHFS For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-AVEN For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-AVES For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-AVFN For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-AVFS For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-AMEN For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-AMES For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-AMFN For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-AMFS For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-ANEN For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-ANES For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-ANFN For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-ANFS For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-APEN For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-APES For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-APFN For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-APFS For breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S40E3-JVEN For breaker: AS-40E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S40E3-JVES For breaker: AS-40E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S40E3-JVFN For breaker: AS-40E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S40E3-JVFS For breaker: AS-40E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S40E3-AVEN For breaker: AS-40E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S40E3-AVES For breaker: AS-40E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S40E3-AVFN For breaker: AS-40E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S40E3-AVFS For breaker: AS-40E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S40E4-JVEN For breaker: AS-40E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S40E4-JVES For breaker: AS-40E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S40E4-JVFN For breaker: AS-40E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S40E4-JVFS For breaker: AS-40E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S40E4-AVEN For breaker: AS-40E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S40E4-AVES For breaker: AS-40E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S40E4-AVFN For breaker: AS-40E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S40E4-AVFS For breaker: AS-40E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-JHEN For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-JHES For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-JHFN For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-JHFS For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-JVEN For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-JVES For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-JVFN For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-JVFS For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-JMEN For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-JMES For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-JMFN For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-JMFS For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-JNEN For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-JNES For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-JNFN For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-JNFS For breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-AHEN For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-AHES For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-AHFN For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-AHFS For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-AVEN For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-AVES For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-AVFN For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-AVFS For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-AMEN For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-AMES For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-AMFN For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-AMFS For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-ANEN For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-ANES For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-ANFN For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-ANFS For breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-JHEN For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-JHES For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-JHFN For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-JHFS For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-JVEN For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-JVES For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-JVFN For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-JVFS For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-JMEN For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-JMES For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-JMFN For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-JMFS For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-JNEN For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-JNES For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-JNFN For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-JNFS For breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-AHEN For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-AHES For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-AHFN For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-AHFS For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-AVEN For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-AVES For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-AVFN For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-AVFS For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-AMEN For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-AMES For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-AMFN For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-AMFS For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-ANEN For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-ANES For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-ANFN For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-ANFS For breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-JHEN For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-JHES For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-JHFN For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-JHFS For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-JVEN For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-JVES For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-JVFN For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-JVFS For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-JMEN For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-JMES For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-JMFN For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-JMFS For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-JNEN For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-JNES For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-JNFN For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-JNFS For breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-AHEN For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-AHES For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-AHFN For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-AHFS For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-AVEN For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-AVES For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-AVFN For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-AVFS For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-AMEN For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-AMES For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-AMFN For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-AMFS For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-ANEN For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-ANES For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-ANFN For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-ANFS For breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-JHEN For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-JHES For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-JHFN For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-JHFS For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-JVEN For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-JVES For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-JVFN For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-JVFS For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-JMEN For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-JMES For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-JMFN For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-JMFS For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-JNEN For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-JNES For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-JNFN For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-JNFS For breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-AHEN For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-AHES For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-AHFN For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-AHFS For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-AVEN For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-AVES For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-AVFN For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-AVFS For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-AMEN For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-AMES For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-AMFN For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-AMFS For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-ANEN For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-ANES For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-ANFN For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-ANFS For breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-JHEN For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-JHES For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-JHFN For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-JHFS For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-JVEN For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-JVES For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-JVFN For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-JVFS For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-JMEN For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-JMES For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-JMFN For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-JMFS For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-JNEN For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-JNES For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-JNFN For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-JNFS For breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-AHEN For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-AHES For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-AHFN For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-AHFS For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-AVEN For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-AVES For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-AVFN For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-AVFS For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-AMEN For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-AMES For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-AMFN For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-AMFS For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-ANEN For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-ANES For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-ANFN For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-ANFS For breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-JHEN For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-JHES For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-JHFN For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-JHFS For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-JVEN For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-JVES For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-JVFN For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-JVFS For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-JMEN For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-JMES For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-JMFN For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-JMFS For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-JNEN For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-JNES For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-JNFN For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-JNFS For breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-AHEN For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-AHES For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-AHFN For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-AHFS For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-AVEN For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-AVES For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-AVFN For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-AVFS For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-AMEN For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-AMES For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-AMFN For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-AMFS For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-ANEN For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-ANES For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-ANFN For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-ANFS For breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AccessoriesLS Electric
704 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric Metasol ACB Cradle for Draw-out Breakers (630-6300AF)

Brand LS Electric·Accessories

Available part numbers (704)

AL-N16D3-JHEN, AL-N16D3-JHES, AL-N16D3-JHFN, AL-N16D3-JHFS, AL-N16D3-JVEN, AL-N16D3-JVES, AL-N16D3-JVFN, AL-N16D3-JVFS, AL-N16D3-JMEN, AL-N16D3-JMES + 694 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AL-N16D3-JHENFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-JHESFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-JHFNFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-JHFSFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-JVENFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-JVESFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-JVFNFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-JVFSFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-JMENFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-JMESFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-JMFNFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-JMFSFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-JNENFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-JNESFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-JNFNFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-JNFSFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-JPENFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-JPESFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-JPFNFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-JPFSFor breaker: AN-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-AHENFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-AHESFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-AHFNFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-AHFSFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-AVENFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-AVESFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-AVFNFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-AVFSFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-AMENFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-AMESFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-AMFNFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-AMFSFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-ANENFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-ANESFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-ANFNFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-ANFSFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D3-APENFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D3-APESFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D3-APFNFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D3-APFSFor breaker: AN-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-JHENFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-JHESFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-JHFNFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-JHFSFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-JVENFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-JVESFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-JVFNFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-JVFSFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-JMENFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-JMESFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-JMFNFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-JMFSFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-JNENFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-JNESFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-JNFNFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-JNFSFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-JPENFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-JPESFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-JPFNFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-JPFSFor breaker: AN-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-AHENFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-AHESFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-AHFNFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-AHFSFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-AVENFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-AVESFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-AVFNFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-AVFSFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-AMENFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-AMESFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-AMFNFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-AMFSFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-ANENFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-ANESFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-ANFNFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-ANFSFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N16D4-APENFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N16D4-APESFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N16D4-APFNFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N16D4-APFSFor breaker: AN-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-JHENFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-JHESFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-JHFNFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-JHFSFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-JVENFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-JVESFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-JVFNFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-JVFSFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-JMENFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-JMESFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-JMFNFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-JMFSFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-JNENFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-JNESFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-JNFNFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-JNFSFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-JPENFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-JPESFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-JPFNFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-JPFSFor breaker: AS-06~16D | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-AHENFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-AHESFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-AHFNFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-AHFSFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-AVENFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-AVESFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-AVFNFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-AVFSFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-AMENFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-AMESFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-AMFNFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-AMFSFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-ANENFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-ANESFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-ANFNFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-ANFSFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D3-APENFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D3-APESFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D3-APFNFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D3-APFSFor breaker: AS-06~16D | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-JHENFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-JHESFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-JHFNFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-JHFSFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-JVENFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-JVESFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-JVFNFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-JVFSFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-JMENFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-JMESFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-JMFNFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-JMFSFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-JNENFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-JNESFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-JNFNFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-JNFSFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-JPENFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-JPESFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-JPFNFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-JPFSFor breaker: AS-06~16D | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-AHENFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-AHESFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-AHFNFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-AHFSFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-AVENFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-AVESFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-AVFNFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-AVFSFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-AMENFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-AMESFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-AMFNFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-AMFSFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-ANENFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-ANESFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-ANFNFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-ANFSFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S16D4-APENFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S16D4-APESFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S16D4-APFNFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S16D4-APFSFor breaker: AS-06~16D | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S20D3-JVENFor breaker: AS-20D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S20D3-JVESFor breaker: AS-20D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S20D3-JVFNFor breaker: AS-20D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S20D3-JVFSFor breaker: AS-20D | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S20D3-AVENFor breaker: AS-20D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S20D3-AVESFor breaker: AS-20D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S20D3-AVFNFor breaker: AS-20D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S20D3-AVFSFor breaker: AS-20D | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S20D4-JVENFor breaker: AS-20D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S20D4-JVESFor breaker: AS-20D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S20D4-JVFNFor breaker: AS-20D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S20D4-JVFSFor breaker: AS-20D | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S20D4-AVENFor breaker: AS-20D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S20D4-AVESFor breaker: AS-20D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S20D4-AVFNFor breaker: AS-20D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S20D4-AVFSFor breaker: AS-20D | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-JHENFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-JHESFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-JHFNFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-JHFSFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-JVENFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-JVESFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-JVFNFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-JVFSFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-JMENFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-JMESFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-JMFNFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-JMFSFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-JNENFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-JNESFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-JNFNFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-JNFSFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-JPENFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-JPESFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-JPFNFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-JPFSFor breaker: AN-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-AHENFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-AHESFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-AHFNFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-AHFSFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-AVENFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-AVESFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-AVFNFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-AVFSFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-AMENFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-AMESFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-AMFNFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-AMFSFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-ANENFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-ANESFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-ANFNFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-ANFSFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E3-APENFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E3-APESFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E3-APFNFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E3-APFSFor breaker: AN-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-JHENFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-JHESFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-JHFNFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-JHFSFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-JVENFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-JVESFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-JVFNFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-JVFSFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-JMENFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-JMESFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-JMFNFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-JMFSFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-JNENFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-JNESFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-JNFNFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-JNFSFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-JPENFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-JPESFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-JPFNFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-JPFSFor breaker: AN-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-AHENFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-AHESFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-AHFNFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-AHFSFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-AVENFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-AVESFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-AVFNFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-AVFSFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-AMENFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-AMESFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-AMFNFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-AMFSFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-ANENFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-ANESFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-ANFNFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-ANFSFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N25E4-APENFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N25E4-APESFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N25E4-APFNFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N25E4-APFSFor breaker: AN-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-JHENFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-JHESFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-JHFNFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-JHFSFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-JVENFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-JVESFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-JVFNFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-JVFSFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-JMENFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-JMESFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-JMFNFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-JMFSFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-JNENFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-JNESFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-JNFNFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-JNFSFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-JPENFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-JPESFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-JPFNFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-JPFSFor breaker: AN-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-AHENFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-AHESFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-AHFNFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-AHFSFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-AVENFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-AVESFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-AVFNFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-AVFSFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-AMENFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-AMESFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-AMFNFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-AMFSFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-ANENFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-ANESFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-ANFNFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-ANFSFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E3-APENFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E3-APESFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E3-APFNFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E3-APFSFor breaker: AN-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-JHENFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-JHESFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-JHFNFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-JHFSFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-JVENFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-JVESFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-JVFNFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-JVFSFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-JMENFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-JMESFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-JMFNFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-JMFSFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-JNENFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-JNESFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-JNFNFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-JNFSFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-JPENFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-JPESFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-JPFNFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-JPFSFor breaker: AN-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-AHENFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-AHESFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-AHFNFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-AHFSFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-AVENFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-AVESFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-AVFNFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-AVFSFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-AMENFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-AMESFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-AMFNFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-AMFSFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-ANENFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-ANESFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-ANFNFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-ANFSFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-N32E4-APENFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-N32E4-APESFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-N32E4-APFNFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-N32E4-APFSFor breaker: AN-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-JHENFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-JHESFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-JHFNFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-JHFSFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-JVENFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-JVESFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-JVFNFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-JVFSFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-JMENFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-JMESFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-JMFNFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-JMFSFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-JNENFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-JNESFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-JNFNFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-JNFSFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-JPENFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-JPESFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-JPFNFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-JPFSFor breaker: AS-20~25E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-AHENFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-AHESFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-AHFNFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-AHFSFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-AVENFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-AVESFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-AVFNFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-AVFSFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-AMENFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-AMESFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-AMFNFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-AMFSFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-ANENFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-ANESFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-ANFNFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-ANFSFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E3-APENFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E3-APESFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E3-APFNFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E3-APFSFor breaker: AS-20~25E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-JHENFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-JHESFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-JHFNFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-JHFSFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-JVENFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-JVESFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-JVFNFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-JVFSFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-JMENFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-JMESFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-JMFNFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-JMFSFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-JNENFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-JNESFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-JNFNFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-JNFSFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-JPENFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-JPESFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-JPFNFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-JPFSFor breaker: AS-20~25E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-AHENFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-AHESFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-AHFNFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-AHFSFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-AVENFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-AVESFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-AVFNFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-AVFSFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-AMENFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-AMESFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-AMFNFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-AMFSFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-ANENFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-ANESFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-ANFNFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-ANFSFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S25E4-APENFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S25E4-APESFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S25E4-APFNFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S25E4-APFSFor breaker: AS-20~25E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-JHENFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-JHESFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-JHFNFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-JHFSFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-JVENFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-JVESFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-JVFNFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-JVFSFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-JMENFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-JMESFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-JMFNFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-JMFSFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-JNENFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-JNESFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-JNFNFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-JNFSFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-JPENFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-JPESFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-JPFNFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-JPFSFor breaker: AS-32E | Poles: 3P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-AHENFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-AHESFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-AHFNFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-AHFSFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-AVENFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-AVESFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-AVFNFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-AVFSFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-AMENFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-AMESFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-AMFNFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-AMFSFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-ANENFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-ANESFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-ANFNFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-ANFSFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E3-APENFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E3-APESFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E3-APFNFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E3-APFSFor breaker: AS-32E | Poles: 3P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-JHENFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-JHESFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-JHFNFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-JHFSFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-JVENFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-JVESFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-JVFNFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-JVFSFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-JMENFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-JMESFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-JMFNFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-JMFSFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-JNENFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-JNESFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-JNFNFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-JNFSFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-JPENFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-JPESFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-JPFNFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-JPFSFor breaker: AS-32E | Poles: 4P | Connection: Manual (J) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-AHENFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-AHESFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-AHFNFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-AHFSFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-AVENFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-AVESFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-AVFNFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-AVFSFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-AMENFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-AMESFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-AMFNFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-AMFSFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-ANENFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-ANESFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-ANFNFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-ANFSFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S32E4-APENFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S32E4-APESFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S32E4-APFNFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S32E4-APFSFor breaker: AS-32E | Poles: 4P | Connection: Auto (A) | Busbar: Front (flat) (P) | Safety shutter: With (F) | Arc cover: With (S)
AL-S40E3-JVENFor breaker: AS-40E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S40E3-JVESFor breaker: AS-40E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S40E3-JVFNFor breaker: AS-40E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S40E3-JVFSFor breaker: AS-40E | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S40E3-AVENFor breaker: AS-40E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S40E3-AVESFor breaker: AS-40E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S40E3-AVFNFor breaker: AS-40E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S40E3-AVFSFor breaker: AS-40E | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S40E4-JVENFor breaker: AS-40E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S40E4-JVESFor breaker: AS-40E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S40E4-JVFNFor breaker: AS-40E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S40E4-JVFSFor breaker: AS-40E | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S40E4-AVENFor breaker: AS-40E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S40E4-AVESFor breaker: AS-40E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S40E4-AVFNFor breaker: AS-40E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S40E4-AVFSFor breaker: AS-40E | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-JHENFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-JHESFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-JHFNFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-JHFSFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-JVENFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-JVESFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-JVFNFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-JVFSFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-JMENFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-JMESFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-JMFNFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-JMFSFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-JNENFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-JNESFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-JNFNFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-JNFSFor breaker: AS-40~50F | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-AHENFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-AHESFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-AHFNFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-AHFSFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-AVENFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-AVESFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-AVFNFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-AVFSFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-AMENFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-AMESFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-AMFNFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-AMFSFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F3-ANENFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F3-ANESFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F3-ANFNFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F3-ANFSFor breaker: AS-40~50F | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-JHENFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-JHESFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-JHFNFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-JHFSFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-JVENFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-JVESFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-JVFNFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-JVFSFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-JMENFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-JMESFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-JMFNFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-JMFSFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-JNENFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-JNESFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-JNFNFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-JNFSFor breaker: AS-40~50F | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-AHENFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-AHESFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-AHFNFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-AHFSFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-AVENFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-AVESFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-AVFNFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-AVFSFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-AMENFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-AMESFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-AMFNFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-AMFSFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50F4-ANENFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50F4-ANESFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50F4-ANFNFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50F4-ANFSFor breaker: AS-40~50F | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-JHENFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-JHESFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-JHFNFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-JHFSFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-JVENFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-JVESFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-JVFNFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-JVFSFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-JMENFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-JMESFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-JMFNFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-JMFSFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-JNENFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-JNESFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-JNFNFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-JNFSFor breaker: AS-40~50G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-AHENFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-AHESFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-AHFNFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-AHFSFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-AVENFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-AVESFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-AVFNFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-AVFSFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-AMENFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-AMESFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-AMFNFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-AMFSFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G3-ANENFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G3-ANESFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G3-ANFNFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G3-ANFSFor breaker: AS-40~50G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-JHENFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-JHESFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-JHFNFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-JHFSFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-JVENFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-JVESFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-JVFNFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-JVFSFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-JMENFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-JMESFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-JMFNFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-JMFSFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-JNENFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-JNESFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-JNFNFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-JNFSFor breaker: AS-40~50G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-AHENFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-AHESFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-AHFNFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-AHFSFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-AVENFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-AVESFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-AVFNFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-AVFSFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-AMENFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-AMESFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-AMFNFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-AMFSFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S50G4-ANENFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S50G4-ANESFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S50G4-ANFNFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S50G4-ANFSFor breaker: AS-40~50G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-JHENFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-JHESFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-JHFNFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-JHFSFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-JVENFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-JVESFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-JVFNFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-JVFSFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-JMENFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-JMESFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-JMFNFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-JMFSFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-JNENFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-JNESFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-JNFNFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-JNFSFor breaker: AS-63G | Poles: 3P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-AHENFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-AHESFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-AHFNFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-AHFSFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-AVENFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-AVESFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-AVFNFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-AVFSFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-AMENFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-AMESFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-AMFNFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-AMFSFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G3-ANENFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G3-ANESFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G3-ANFNFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G3-ANFSFor breaker: AS-63G | Poles: 3P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-JHENFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-JHESFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-JHFNFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-JHFSFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-JVENFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-JVESFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-JVFNFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-JVFSFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-JMENFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-JMESFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-JMFNFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-JMFSFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-JNENFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-JNESFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-JNFNFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-JNFSFor breaker: AS-63G | Poles: 4P | Connection: Manual (J) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-AHENFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-AHESFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-AHFNFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-AHFSFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Horizontal (H) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-AVENFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-AVESFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-AVFNFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-AVFSFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Vertical (V) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-AMENFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-AMESFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-AMFNFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-AMFSFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top horizontal, bottom vertical (M) | Safety shutter: With (F) | Arc cover: With (S)
AL-S63G4-ANENFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: Without (N)
AL-S63G4-ANESFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: Without (E) | Arc cover: With (S)
AL-S63G4-ANFNFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: Without (N)
AL-S63G4-ANFSFor breaker: AS-63G | Poles: 4P | Connection: Auto (A) | Busbar: Top vertical, bottom horizontal (N) | Safety shutter: With (F) | Arc cover: With (S)

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Circuit Breakers & Contactors →
