LS Electric Metasol ACB Cradle Accessories (Item Codes)

LS Electric Metasol ACB Cradle Accessories (Item Codes)

Separately ordered cradle accessories for LS Electric Metasol draw-out air circuit breakers, listed by LS item code.

Key features

  • Cell switches (4C left/right, 8C left, with or without cover) and rotary mechanism operated cell switch (MOC)
  • Door interlocks (standard and catch type), racking interlocks, safety shutter lock and miss-insertion prevention
  • Body supporters for D/E/F/G frames, 3P and 4P; interphase barriers 100 / 140 mm
  • UVT time delay controllers from AC/DC 100-130 V to AC 380-480 V, incl. 5 s delay version
  • Push-in or screw control terminal modules, long draw in/out handles, TRIO temperature monitoring

Specifications

Applicable cradles Metasol AL cradle, D/E/F/G frames
Ordering By LS item code
Supply Separately ordered (not part of cradle code)
Source LS Electric Metasol ACB catalog C06091-28 (2026.07), p. 143-146
62503460401 Item: Shorting b contact (SBC) | Version: Cradle, marine type
64723460501 Item: Door frame (DF) | Version: Draw-out
64723460502 Item: Door frame (DF) | Version: Fixed
84113460501 Item: Miss-insertion prevention (MIP) | Version: 630-6300 A, D/E/F/G
56763460411 Item: Safety shutter lock (STL) | Version: D/E/F/G, 2 pcs
72313460659 Item: Mechanism operated cell switch (MOC) | Version: Rotary, 200-6300 A
72313460501 Item: Cell switch (CEL) | Version: 4C, left
72313460621 Item: Cell switch (CEL) | Version: 4C, left, with cover
72313460537 Item: Cell switch (CEL) | Version: 4C, right
72313460620 Item: Cell switch (CEL) | Version: 8C, left
72313460623 Item: Cell switch (CEL) | Version: 8C, left, with cover
56123460504 Item: Door interlock (DI) | Version: Standard, D/E/F/G
56123460513 Item: Door interlock (DI) | Version: Catch type, left
56123460512 Item: Door interlock (DI) | Version: Catch type, right
72313461501 Item: Body supporter (BSP) | Version: D frame 3P
72313462501 Item: Body supporter (BSP) | Version: D frame 4P
72313463501 Item: Body supporter (BSP) | Version: E frame 3P
72313464501 Item: Body supporter (BSP) | Version: E frame 4P
72313465501 Item: Body supporter (BSP) | Version: F frame 3P
72313465502 Item: Body supporter (BSP) | Version: F frame 4P
72313465503 Item: Body supporter (BSP) | Version: G frame 3P
72313465504 Item: Body supporter (BSP) | Version: G frame 4P
52773460272 Item: UVT time delay controller (UDC) | Version: AC/DC 100-130 V
52773460273 Item: UVT time delay controller (UDC) | Version: AC/DC 200-250 V
52773460280 Item: UVT time delay controller (UDC) | Version: AC/DC 200-250 V, 5 s delay
52773460271 Item: UVT time delay controller (UDC) | Version: DC 48-60 V / AC 48 V
52773460274 Item: UVT time delay controller (UDC) | Version: AC 380-480 V
67213460011 Item: Interphase barrier (IB) | Version: 100 mm, 3 pcs
67213460013 Item: Interphase barrier (IB) | Version: 140 mm long, 3 pcs
56123460501 Item: Racking interlock (RI) | Version: Type 1
56123460521 Item: Racking interlock (RI) | Version: Type 2
55223460402 Item: Draw in/out handle, long | Version: Cradle D/E/F/G
55223460404 Item: Draw in/out handle, long | Version: Cradle D/E/F/G, T-type
72313460660 Item: Control terminal module | Version: Push-in
72313460661 Item: Control terminal module | Version: Screw
72313460500 Item: TRIO temperature monitoring unit | Version: New TRIO, Smart LV
72313460280 Item: TRIO temperature sensor | Version: Contact type
02410001 Item: SMPS power supply | Version: IPM6P, AC/DC 240 V to DC 24 V 36 W
AccessoriesLS Electric
38 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric Metasol ACB Cradle Accessories (Item Codes)

Brand LS Electric·Accessories

Available part numbers (38)

62503460401, 64723460501, 64723460502, 84113460501, 56763460411, 72313460659, 72313460501, 72313460621, 72313460537, 72313460620 + 28 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
62503460401Item: Shorting b contact (SBC) | Version: Cradle, marine type
64723460501Item: Door frame (DF) | Version: Draw-out
64723460502Item: Door frame (DF) | Version: Fixed
84113460501Item: Miss-insertion prevention (MIP) | Version: 630-6300 A, D/E/F/G
56763460411Item: Safety shutter lock (STL) | Version: D/E/F/G, 2 pcs
72313460659Item: Mechanism operated cell switch (MOC) | Version: Rotary, 200-6300 A
72313460501Item: Cell switch (CEL) | Version: 4C, left
72313460621Item: Cell switch (CEL) | Version: 4C, left, with cover
72313460537Item: Cell switch (CEL) | Version: 4C, right
72313460620Item: Cell switch (CEL) | Version: 8C, left
72313460623Item: Cell switch (CEL) | Version: 8C, left, with cover
56123460504Item: Door interlock (DI) | Version: Standard, D/E/F/G
56123460513Item: Door interlock (DI) | Version: Catch type, left
56123460512Item: Door interlock (DI) | Version: Catch type, right
72313461501Item: Body supporter (BSP) | Version: D frame 3P
72313462501Item: Body supporter (BSP) | Version: D frame 4P
72313463501Item: Body supporter (BSP) | Version: E frame 3P
72313464501Item: Body supporter (BSP) | Version: E frame 4P
72313465501Item: Body supporter (BSP) | Version: F frame 3P
72313465502Item: Body supporter (BSP) | Version: F frame 4P
72313465503Item: Body supporter (BSP) | Version: G frame 3P
72313465504Item: Body supporter (BSP) | Version: G frame 4P
52773460272Item: UVT time delay controller (UDC) | Version: AC/DC 100-130 V
52773460273Item: UVT time delay controller (UDC) | Version: AC/DC 200-250 V
52773460280Item: UVT time delay controller (UDC) | Version: AC/DC 200-250 V, 5 s delay
52773460271Item: UVT time delay controller (UDC) | Version: DC 48-60 V / AC 48 V
52773460274Item: UVT time delay controller (UDC) | Version: AC 380-480 V
67213460011Item: Interphase barrier (IB) | Version: 100 mm, 3 pcs
67213460013Item: Interphase barrier (IB) | Version: 140 mm long, 3 pcs
56123460501Item: Racking interlock (RI) | Version: Type 1
56123460521Item: Racking interlock (RI) | Version: Type 2
55223460402Item: Draw in/out handle, long | Version: Cradle D/E/F/G
55223460404Item: Draw in/out handle, long | Version: Cradle D/E/F/G, T-type
72313460660Item: Control terminal module | Version: Push-in
72313460661Item: Control terminal module | Version: Screw
72313460500Item: TRIO temperature monitoring unit | Version: New TRIO, Smart LV
72313460280Item: TRIO temperature sensor | Version: Contact type
02410001Item: SMPS power supply | Version: IPM6P, AC/DC 240 V to DC 24 V 36 W
