LS Electric Metasol ACB DN/DS Switch-Disconnector (630-4000AF)

LS Electric Metasol ACB DN/DS Switch-Disconnector (630-4000AF)

LS Electric Metasol DN and DS air switch-disconnectors (non-automatic ACB without trip relay), 630-4000AF, for load switching and isolation in low-voltage switchboards.

Key features

  • Built on the Metasol ACB D and E frames; no trip relay or CT (rated current code 00, trip relay 000)
  • DN up to 3200AF, DS up to 4000AF; Icm 105-187 kA peak per IEC 60947-3
  • Draw-out (cradle ordered separately) or fixed type, 3-pole or 4-pole
  • Ordering code e.g. DS-16D3-00J 000; motor, coil, aux contact and option tokens are added per order
  • Accepts the Metasol ACB accessory range (motor charge, closing/shunt coil, UVT, interlocks)

Specifications

Rated operational voltage (Ue) AC 690 V, 50/60 Hz
Rated insulation voltage (Ui) AC 1000 V
Rated impulse withstand voltage (Uimp) 12 kV
Rated making current (Icm) DN-D 105 kA, DN-E/DS-D 143 kA, DS-E 187 kA
Rated current 630-4000 A (= frame)
Mechanical / electrical life D 20,000 / 5,000; E 15,000 / 5,000
Standards IEC 60947-3
Source LS Electric Metasol ACB catalog C06091-28 (2026.07), p. 14, 20-21
DN-06D3-00J000 Model: DN-06D, 630AF | Icw 1 s: 50 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DN-06D3-00H000 Model: DN-06D, 630AF | Icw 1 s: 50 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DN-06D4-00J000 Model: DN-06D, 630AF | Icw 1 s: 50 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DN-06D4-00H000 Model: DN-06D, 630AF | Icw 1 s: 50 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DN-08D3-00J000 Model: DN-08D, 800AF | Icw 1 s: 50 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DN-08D3-00H000 Model: DN-08D, 800AF | Icw 1 s: 50 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DN-08D4-00J000 Model: DN-08D, 800AF | Icw 1 s: 50 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DN-08D4-00H000 Model: DN-08D, 800AF | Icw 1 s: 50 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DN-10D3-00J000 Model: DN-10D, 1000AF | Icw 1 s: 50 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DN-10D3-00H000 Model: DN-10D, 1000AF | Icw 1 s: 50 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DN-10D4-00J000 Model: DN-10D, 1000AF | Icw 1 s: 50 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DN-10D4-00H000 Model: DN-10D, 1000AF | Icw 1 s: 50 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DN-13D3-00J000 Model: DN-13D, 1250AF | Icw 1 s: 50 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DN-13D3-00H000 Model: DN-13D, 1250AF | Icw 1 s: 50 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DN-13D4-00J000 Model: DN-13D, 1250AF | Icw 1 s: 50 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DN-13D4-00H000 Model: DN-13D, 1250AF | Icw 1 s: 50 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DN-16D3-00J000 Model: DN-16D, 1600AF | Icw 1 s: 50 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DN-16D3-00H000 Model: DN-16D, 1600AF | Icw 1 s: 50 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DN-16D4-00J000 Model: DN-16D, 1600AF | Icw 1 s: 50 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DN-16D4-00H000 Model: DN-16D, 1600AF | Icw 1 s: 50 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DN-20E3-00J000 Model: DN-20E, 2000AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DN-20E3-00H000 Model: DN-20E, 2000AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DN-20E4-00J000 Model: DN-20E, 2000AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DN-20E4-00H000 Model: DN-20E, 2000AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DN-25E3-00J000 Model: DN-25E, 2500AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DN-25E3-00H000 Model: DN-25E, 2500AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DN-25E4-00J000 Model: DN-25E, 2500AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DN-25E4-00H000 Model: DN-25E, 2500AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DN-32E3-00J000 Model: DN-32E, 3200AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DN-32E3-00H000 Model: DN-32E, 3200AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DN-32E4-00J000 Model: DN-32E, 3200AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DN-32E4-00H000 Model: DN-32E, 3200AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DS-06D3-00J000 Model: DS-06D, 630AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DS-06D3-00H000 Model: DS-06D, 630AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DS-06D4-00J000 Model: DS-06D, 630AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DS-06D4-00H000 Model: DS-06D, 630AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DS-08D3-00J000 Model: DS-08D, 800AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DS-08D3-00H000 Model: DS-08D, 800AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DS-08D4-00J000 Model: DS-08D, 800AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DS-08D4-00H000 Model: DS-08D, 800AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DS-10D3-00J000 Model: DS-10D, 1000AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DS-10D3-00H000 Model: DS-10D, 1000AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DS-10D4-00J000 Model: DS-10D, 1000AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DS-10D4-00H000 Model: DS-10D, 1000AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DS-13D3-00J000 Model: DS-13D, 1250AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DS-13D3-00H000 Model: DS-13D, 1250AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DS-13D4-00J000 Model: DS-13D, 1250AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DS-13D4-00H000 Model: DS-13D, 1250AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DS-16D3-00J000 Model: DS-16D, 1600AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DS-16D3-00H000 Model: DS-16D, 1600AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DS-16D4-00J000 Model: DS-16D, 1600AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DS-16D4-00H000 Model: DS-16D, 1600AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DS-20D3-00J000 Model: DS-20D, 2000AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DS-20D3-00V000 Model: DS-20D, 2000AF | Icw 1 s: 65 kA | Poles: 3P | Mounting: Fixed, vertical busbar (V)
DS-20D4-00J000 Model: DS-20D, 2000AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DS-20D4-00V000 Model: DS-20D, 2000AF | Icw 1 s: 65 kA | Poles: 4P | Mounting: Fixed, vertical busbar (V)
DS-20E3-00J000 Model: DS-20E, 2000AF | Icw 1 s: 85 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DS-20E3-00H000 Model: DS-20E, 2000AF | Icw 1 s: 85 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DS-20E4-00J000 Model: DS-20E, 2000AF | Icw 1 s: 85 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DS-20E4-00H000 Model: DS-20E, 2000AF | Icw 1 s: 85 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DS-25E3-00J000 Model: DS-25E, 2500AF | Icw 1 s: 85 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DS-25E3-00H000 Model: DS-25E, 2500AF | Icw 1 s: 85 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DS-25E4-00J000 Model: DS-25E, 2500AF | Icw 1 s: 85 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DS-25E4-00H000 Model: DS-25E, 2500AF | Icw 1 s: 85 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DS-32E3-00J000 Model: DS-32E, 3200AF | Icw 1 s: 85 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DS-32E3-00H000 Model: DS-32E, 3200AF | Icw 1 s: 85 kA | Poles: 3P | Mounting: Fixed, horizontal busbar (H)
DS-32E4-00J000 Model: DS-32E, 3200AF | Icw 1 s: 85 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DS-32E4-00H000 Model: DS-32E, 3200AF | Icw 1 s: 85 kA | Poles: 4P | Mounting: Fixed, horizontal busbar (H)
DS-40E3-00J000 Model: DS-40E, 4000AF | Icw 1 s: 85 kA | Poles: 3P | Mounting: Draw-out, manual connection (J)
DS-40E3-00V000 Model: DS-40E, 4000AF | Icw 1 s: 85 kA | Poles: 3P | Mounting: Fixed, vertical busbar (V)
DS-40E4-00J000 Model: DS-40E, 4000AF | Icw 1 s: 85 kA | Poles: 4P | Mounting: Draw-out, manual connection (J)
DS-40E4-00V000 Model: DS-40E, 4000AF | Icw 1 s: 85 kA | Poles: 4P | Mounting: Fixed, vertical busbar (V)
