LS Electric Metasol MC Timer, Latch and Delay Release Units

LS Electric Metasol MC Timer, Latch and Delay Release Units

LS Electric Metasol contactor add-on units: UN pneumatic timer blocks, UT electronic timers, ML/AL mechanical latch units and AD delay release (undervoltage ride-through) units.

Key features

  • UN pneumatic timer blocks, on-delay (N) or off-delay (F), 1NO+1NC, ranges 0.1-3 s, 0.1-30 s, 10-180 s
  • UT electronic head-on timers, on- or off-delay, 1-30 s, AC/DC 24-48 V or AC 110-220 V
  • ML/AL mechanical latch units keep the contactor closed without coil power (DC operation max. 150 ops/h)
  • AD delay release units hold the contactor 1-7 s through momentary power failures (MC with DC coil)
  • Fit Metasol MC contactors 6a to 800a and MR auxiliary relays as listed

Specifications

Brand LS Electric Metasol
UN timer contacts 1NO+1NC, Ith 10 A, AC-15 A600 / DC-13 Q600
UN timer accuracy +/-50%; 2.5 million mechanical ops
UT timer accuracy +/-20% of setting
AD durability 5 million mechanical ops
Standards IEC 60947-5-1
Source LS Electric Metasol MS catalog C04001-37 (2026-09), p. 89-91
UN-1N Type: Pneumatic timer block | Function: On delay | Rating: 0.1-3 s | For: MC-6a to 100a, 9b to 22b, MR-4
UN-1F Type: Pneumatic timer block | Function: Off delay | Rating: 0.1-3 s | For: MC-6a to 100a, 9b to 22b, MR-4
UN-2N Type: Pneumatic timer block | Function: On delay | Rating: 0.1-30 s | For: MC-6a to 100a, 9b to 22b, MR-4
UN-2F Type: Pneumatic timer block | Function: Off delay | Rating: 0.1-30 s | For: MC-6a to 100a, 9b to 22b, MR-4
UN-3N Type: Pneumatic timer block | Function: On delay | Rating: 10-180 s | For: MC-6a to 100a, 9b to 22b, MR-4
UN-3F Type: Pneumatic timer block | Function: Off delay | Rating: 10-180 s | For: MC-6a to 100a, 9b to 22b, MR-4
UT-1N Type: Electronic timer | Function: On delay, 1-30 s | Rating: AC/DC 24-48 V | For: MC-6a to 150a, 9b to 22b, MR-4 to 8
UT-2N Type: Electronic timer | Function: On delay, 1-30 s | Rating: AC 110-220 V | For: MC-6a to 150a, 9b to 22b, MR-4 to 8
UT-1F Type: Electronic timer | Function: Off delay, 1-30 s | Rating: AC/DC 24-48 V | For: MC-6a to 150a, 9b to 22b, MR-4 to 8
UT-2F Type: Electronic timer | Function: Off delay, 1-30 s | Rating: AC 110-220 V | For: MC-6a to 150a, 9b to 22b, MR-4 to 8
ML-40/AC/DC24V Type: Mechanical latch unit ML-40 | Function: Mechanical latch | Rating: AC 24 V 50/60 Hz, DC 24 V | For: MC-6a to 40a, 9b to 22b, MR
ML-40/AC/DC48V Type: Mechanical latch unit ML-40 | Function: Mechanical latch | Rating: AC 48 V 50/60 Hz, DC 48 V | For: MC-6a to 40a, 9b to 22b, MR
ML-40/AC/DC100V Type: Mechanical latch unit ML-40 | Function: Mechanical latch | Rating: AC 100-127 V, DC 100-125 V | For: MC-6a to 40a, 9b to 22b, MR
ML-40/AC/DC200V Type: Mechanical latch unit ML-40 | Function: Mechanical latch | Rating: AC 200-240 V, DC 200-220 V | For: MC-6a to 40a, 9b to 22b, MR
ML-40/AC400V Type: Mechanical latch unit ML-40 | Function: Mechanical latch | Rating: AC 380-440 V 50/60 Hz | For: MC-6a to 40a, 9b to 22b, MR
ML-65/AC/DC24V Type: Mechanical latch unit ML-65 | Function: Mechanical latch | Rating: AC 24 V 50/60 Hz, DC 24 V | For: MC-50a, 65a
ML-65/AC/DC48V Type: Mechanical latch unit ML-65 | Function: Mechanical latch | Rating: AC 48 V 50/60 Hz, DC 48 V | For: MC-50a, 65a
ML-65/AC/DC100V Type: Mechanical latch unit ML-65 | Function: Mechanical latch | Rating: AC 100-127 V, DC 100-125 V | For: MC-50a, 65a
ML-65/AC/DC200V Type: Mechanical latch unit ML-65 | Function: Mechanical latch | Rating: AC 200-240 V, DC 200-220 V | For: MC-50a, 65a
ML-65/AC400V Type: Mechanical latch unit ML-65 | Function: Mechanical latch | Rating: AC 380-440 V 50/60 Hz | For: MC-50a, 65a
ML-150/AC/DC24V Type: Mechanical latch unit ML-150 | Function: Mechanical latch | Rating: AC 24 V 50/60 Hz, DC 24 V | For: MC-75a to 150a
ML-150/AC/DC48V Type: Mechanical latch unit ML-150 | Function: Mechanical latch | Rating: AC 48 V 50/60 Hz, DC 48 V | For: MC-75a to 150a
ML-150/AC/DC100V Type: Mechanical latch unit ML-150 | Function: Mechanical latch | Rating: AC 100-127 V, DC 100-125 V | For: MC-75a to 150a
ML-150/AC/DC200V Type: Mechanical latch unit ML-150 | Function: Mechanical latch | Rating: AC 200-240 V, DC 200-220 V | For: MC-75a to 150a
ML-150/AC400V Type: Mechanical latch unit ML-150 | Function: Mechanical latch | Rating: AC 380-440 V 50/60 Hz | For: MC-75a to 150a
AL-225/AC/DC100V Type: Mechanical latch unit AL-225 | Function: Mechanical latch | Rating: AC 100-127 V, DC 100-110 V | For: MC-185a, 225a
AL-225/AC/DC200V Type: Mechanical latch unit AL-225 | Function: Mechanical latch | Rating: AC 200-240 V, DC 200-220 V | For: MC-185a, 225a
AL-400/AC/DC100V Type: Mechanical latch unit AL-400 | Function: Mechanical latch | Rating: AC 100-127 V, DC 100-110 V | For: MC-265a to 400a
AL-400/AC/DC200V Type: Mechanical latch unit AL-400 | Function: Mechanical latch | Rating: AC 200-240 V, DC 200-220 V | For: MC-265a to 400a
AD-9/AC110V Type: Delay release unit AD-9 | Function: Delay release 1-7 s | Rating: AC 110 V (MC coil DC 110 V) | For: MC-6a to 18a, 9b to 22b
AD-9/AC220V Type: Delay release unit AD-9 | Function: Delay release 1-7 s | Rating: AC 220 V (MC coil DC 220 V) | For: MC-6a to 18a, 9b to 22b
AD-32/AC110V Type: Delay release unit AD-32 | Function: Delay release 1-7 s | Rating: AC 110 V (MC coil DC 110 V) | For: MC-32a, 40a
AD-32/AC220V Type: Delay release unit AD-32 | Function: Delay release 1-7 s | Rating: AC 220 V (MC coil DC 220 V) | For: MC-32a, 40a
AD-50/AC110V Type: Delay release unit AD-50 | Function: Delay release 1-7 s | Rating: AC 110 V (MC coil DC 110 V) | For: MC-50a to 100a
AD-50/AC220V Type: Delay release unit AD-50 | Function: Delay release 1-7 s | Rating: AC 220 V (MC coil DC 220 V) | For: MC-50a to 100a
AD-100 Type: Delay release unit AD-100 | Function: Delay release 1-7 s | Rating: AC 100-240 V (MC coil AC/DC) | For: MC-130a to 225a
AD-300 Type: Delay release unit AD-300 | Function: Delay release 1-7 s | Rating: AC 100-240 V (MC coil AC/DC) | For: MC-265a to 400a
AD-600/AC100-127V Type: Delay release unit AD-600 | Function: Delay release 1-7 s | Rating: AC 100-127 V (MC coil AC/DC) | For: MC-500a to 800a
AD-600/AC200-240V Type: Delay release unit AD-600 | Function: Delay release 1-7 s | Rating: AC 200-240 V (MC coil AC/DC) | For: MC-500a to 800a
AccessoriesLS Electric
39 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric Metasol MC Timer, Latch and Delay Release Units

Brand LS Electric·Accessories

Available part numbers (39)

UN-1N, UN-1F, UN-2N, UN-2F, UN-3N, UN-3F, UT-1N, UT-2N, UT-1F, UT-2F + 29 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UN-1NType: Pneumatic timer block | Function: On delay | Rating: 0.1-3 s | For: MC-6a to 100a, 9b to 22b, MR-4
UN-1FType: Pneumatic timer block | Function: Off delay | Rating: 0.1-3 s | For: MC-6a to 100a, 9b to 22b, MR-4
UN-2NType: Pneumatic timer block | Function: On delay | Rating: 0.1-30 s | For: MC-6a to 100a, 9b to 22b, MR-4
UN-2FType: Pneumatic timer block | Function: Off delay | Rating: 0.1-30 s | For: MC-6a to 100a, 9b to 22b, MR-4
UN-3NType: Pneumatic timer block | Function: On delay | Rating: 10-180 s | For: MC-6a to 100a, 9b to 22b, MR-4
UN-3FType: Pneumatic timer block | Function: Off delay | Rating: 10-180 s | For: MC-6a to 100a, 9b to 22b, MR-4
UT-1NType: Electronic timer | Function: On delay, 1-30 s | Rating: AC/DC 24-48 V | For: MC-6a to 150a, 9b to 22b, MR-4 to 8
UT-2NType: Electronic timer | Function: On delay, 1-30 s | Rating: AC 110-220 V | For: MC-6a to 150a, 9b to 22b, MR-4 to 8
UT-1FType: Electronic timer | Function: Off delay, 1-30 s | Rating: AC/DC 24-48 V | For: MC-6a to 150a, 9b to 22b, MR-4 to 8
UT-2FType: Electronic timer | Function: Off delay, 1-30 s | Rating: AC 110-220 V | For: MC-6a to 150a, 9b to 22b, MR-4 to 8
ML-40/AC/DC24VType: Mechanical latch unit ML-40 | Function: Mechanical latch | Rating: AC 24 V 50/60 Hz, DC 24 V | For: MC-6a to 40a, 9b to 22b, MR
ML-40/AC/DC48VType: Mechanical latch unit ML-40 | Function: Mechanical latch | Rating: AC 48 V 50/60 Hz, DC 48 V | For: MC-6a to 40a, 9b to 22b, MR
ML-40/AC/DC100VType: Mechanical latch unit ML-40 | Function: Mechanical latch | Rating: AC 100-127 V, DC 100-125 V | For: MC-6a to 40a, 9b to 22b, MR
ML-40/AC/DC200VType: Mechanical latch unit ML-40 | Function: Mechanical latch | Rating: AC 200-240 V, DC 200-220 V | For: MC-6a to 40a, 9b to 22b, MR
ML-40/AC400VType: Mechanical latch unit ML-40 | Function: Mechanical latch | Rating: AC 380-440 V 50/60 Hz | For: MC-6a to 40a, 9b to 22b, MR
ML-65/AC/DC24VType: Mechanical latch unit ML-65 | Function: Mechanical latch | Rating: AC 24 V 50/60 Hz, DC 24 V | For: MC-50a, 65a
ML-65/AC/DC48VType: Mechanical latch unit ML-65 | Function: Mechanical latch | Rating: AC 48 V 50/60 Hz, DC 48 V | For: MC-50a, 65a
ML-65/AC/DC100VType: Mechanical latch unit ML-65 | Function: Mechanical latch | Rating: AC 100-127 V, DC 100-125 V | For: MC-50a, 65a
ML-65/AC/DC200VType: Mechanical latch unit ML-65 | Function: Mechanical latch | Rating: AC 200-240 V, DC 200-220 V | For: MC-50a, 65a
ML-65/AC400VType: Mechanical latch unit ML-65 | Function: Mechanical latch | Rating: AC 380-440 V 50/60 Hz | For: MC-50a, 65a
ML-150/AC/DC24VType: Mechanical latch unit ML-150 | Function: Mechanical latch | Rating: AC 24 V 50/60 Hz, DC 24 V | For: MC-75a to 150a
ML-150/AC/DC48VType: Mechanical latch unit ML-150 | Function: Mechanical latch | Rating: AC 48 V 50/60 Hz, DC 48 V | For: MC-75a to 150a
ML-150/AC/DC100VType: Mechanical latch unit ML-150 | Function: Mechanical latch | Rating: AC 100-127 V, DC 100-125 V | For: MC-75a to 150a
ML-150/AC/DC200VType: Mechanical latch unit ML-150 | Function: Mechanical latch | Rating: AC 200-240 V, DC 200-220 V | For: MC-75a to 150a
ML-150/AC400VType: Mechanical latch unit ML-150 | Function: Mechanical latch | Rating: AC 380-440 V 50/60 Hz | For: MC-75a to 150a
AL-225/AC/DC100VType: Mechanical latch unit AL-225 | Function: Mechanical latch | Rating: AC 100-127 V, DC 100-110 V | For: MC-185a, 225a
AL-225/AC/DC200VType: Mechanical latch unit AL-225 | Function: Mechanical latch | Rating: AC 200-240 V, DC 200-220 V | For: MC-185a, 225a
AL-400/AC/DC100VType: Mechanical latch unit AL-400 | Function: Mechanical latch | Rating: AC 100-127 V, DC 100-110 V | For: MC-265a to 400a
AL-400/AC/DC200VType: Mechanical latch unit AL-400 | Function: Mechanical latch | Rating: AC 200-240 V, DC 200-220 V | For: MC-265a to 400a
AD-9/AC110VType: Delay release unit AD-9 | Function: Delay release 1-7 s | Rating: AC 110 V (MC coil DC 110 V) | For: MC-6a to 18a, 9b to 22b
AD-9/AC220VType: Delay release unit AD-9 | Function: Delay release 1-7 s | Rating: AC 220 V (MC coil DC 220 V) | For: MC-6a to 18a, 9b to 22b
AD-32/AC110VType: Delay release unit AD-32 | Function: Delay release 1-7 s | Rating: AC 110 V (MC coil DC 110 V) | For: MC-32a, 40a
AD-32/AC220VType: Delay release unit AD-32 | Function: Delay release 1-7 s | Rating: AC 220 V (MC coil DC 220 V) | For: MC-32a, 40a
AD-50/AC110VType: Delay release unit AD-50 | Function: Delay release 1-7 s | Rating: AC 110 V (MC coil DC 110 V) | For: MC-50a to 100a
AD-50/AC220VType: Delay release unit AD-50 | Function: Delay release 1-7 s | Rating: AC 220 V (MC coil DC 220 V) | For: MC-50a to 100a
AD-100Type: Delay release unit AD-100 | Function: Delay release 1-7 s | Rating: AC 100-240 V (MC coil AC/DC) | For: MC-130a to 225a
AD-300Type: Delay release unit AD-300 | Function: Delay release 1-7 s | Rating: AC 100-240 V (MC coil AC/DC) | For: MC-265a to 400a
AD-600/AC100-127VType: Delay release unit AD-600 | Function: Delay release 1-7 s | Rating: AC 100-127 V (MC coil AC/DC) | For: MC-500a to 800a
AD-600/AC200-240VType: Delay release unit AD-600 | Function: Delay release 1-7 s | Rating: AC 200-240 V (MC coil AC/DC) | For: MC-500a to 800a
