LS Electric Metasol MCCB/ELCB External Accessories (30-1200AF)

LS Electric Metasol MCCB/ELCB External Accessories (30-1200AF)

External accessories for LS Electric Metasol MCCBs and ELCBs: rotary handles, terminal covers, insulation barriers, rear terminals, mechanical interlocks, plug-in bases and motor operators.

Key features

  • Rotary handles: N-handle (direct, door interlock), D-handle (with key-lock DHK version) and E-handle (extended)
  • Terminal covers (IP20) in short and long types, opaque or transparent (/T), by frame and pole count
  • Insulation barriers, round and bar type rear connection terminals
  • Mechanical interlocks MI-13 to MI-84 for main/standby source changeover
  • Plug-in bases (normal, panelboard single/double row, line-only) and motor operators MOP-M1 to M6

Specifications

Compatible series Metasol ABE/ABN/ABS/ABH/ABL MCCB, EBN/EBS/EBH/EBL ELCB
Frame range 30-1200AF
Terminal cover protection IP20
Motor operator life M1-M3 10,000, M4 4,000, M5/M6 2,500 operations
Note ELCB: rotary handle prevents sensitivity setting and test button operation
Source LS Electric Metasol MCCB/ELCB catalog C01031-34 (2025-01), p. 7-9 to 7-27, 5-2 to 5-22
N-30c Type: Rotary handle, direct (N-handle) | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 2P/3P/4P | Detail: Door interlocked, padlockable Off
N-40c Type: Rotary handle, direct (N-handle) | For: 125AF and ABH/EBH50c | Poles: 2P/3P/4P | Detail: Door interlocked, padlockable Off
N-50c Type: Rotary handle, direct (N-handle) | For: 250AF | Poles: 2P/3P/4P | Detail: Door interlocked, padlockable Off
N-70 Type: Rotary handle, direct (N-handle) | For: 400AF | Poles: 2P/3P/4P | Detail: Door interlocked, padlockable Off
N-80 Type: Rotary handle, direct (N-handle) | For: 630/800AF | Poles: 2P/3P/4P | Detail: Door interlocked, padlockable Off
DH100 Type: Rotary handle, direct (D-handle) | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 3P/4P | Detail: Breaker-mounted, trip button access
DH125 Type: Rotary handle, direct (D-handle) | For: 125AF and ABH/EBH50c | Poles: 3P/4P | Detail: Breaker-mounted, trip button access
DH250 Type: Rotary handle, direct (D-handle) | For: 250AF | Poles: 3P/4P | Detail: Breaker-mounted, trip button access
DHK100 Type: Rotary handle, direct (D-handle) | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 3P/4P | Detail: With built-in key lock
DHK125 Type: Rotary handle, direct (D-handle) | For: 125AF and ABH/EBH50c | Poles: 3P/4P | Detail: With built-in key lock
DHK250 Type: Rotary handle, direct (D-handle) | For: 250AF | Poles: 3P/4P | Detail: With built-in key lock
EH100 Type: Rotary handle, extended (E-handle) | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 2P/3P/4P | Detail: Door-mounted handle with shaft
EH125 Type: Rotary handle, extended (E-handle) | For: 125AF and ABH/EBH50c | Poles: 2P/3P/4P | Detail: Door-mounted handle with shaft
EH250 Type: Rotary handle, extended (E-handle) | For: 250AF | Poles: 2P/3P/4P | Detail: Door-mounted handle with shaft
E-70U Type: Rotary handle, extended (E-handle) | For: 400AF | Poles: 2P/3P/4P | Detail: Door-mounted handle with shaft
E-80U Type: Rotary handle, extended (E-handle) | For: 630/800AF | Poles: 2P/3P/4P | Detail: Door-mounted handle with shaft
TCS12 Type: Terminal cover, short | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 2P | Detail: Standard (opaque), IP20
TCS/T-12 Type: Terminal cover, short | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 2P | Detail: Transparent, IP20
TCL12 Type: Terminal cover, long | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 2P | Detail: Standard (opaque), IP20
TCL/T-12 Type: Terminal cover, long | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 2P | Detail: Transparent, IP20
TCS13 Type: Terminal cover, short | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 3P | Detail: Standard (opaque), IP20
TCS/T-13 Type: Terminal cover, short | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 3P | Detail: Transparent, IP20
TCL13 Type: Terminal cover, long | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 3P | Detail: Standard (opaque), IP20
TCL/T-13 Type: Terminal cover, long | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 3P | Detail: Transparent, IP20
TCS14 Type: Terminal cover, short | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 4P | Detail: Standard (opaque), IP20
TCS/T-14 Type: Terminal cover, short | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 4P | Detail: Transparent, IP20
TCL14 Type: Terminal cover, long | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 4P | Detail: Standard (opaque), IP20
TCL/T-14 Type: Terminal cover, long | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: 4P | Detail: Transparent, IP20
TCS22 Type: Terminal cover, short | For: 125AF and ABH/EBH50c | Poles: 2P | Detail: Standard (opaque), IP20
TCS/T-22 Type: Terminal cover, short | For: 125AF and ABH/EBH50c | Poles: 2P | Detail: Transparent, IP20
TCL22 Type: Terminal cover, long | For: 125AF and ABH/EBH50c | Poles: 2P | Detail: Standard (opaque), IP20
TCL/T-22 Type: Terminal cover, long | For: 125AF and ABH/EBH50c | Poles: 2P | Detail: Transparent, IP20
TCS23 Type: Terminal cover, short | For: 125AF and ABH/EBH50c | Poles: 3P | Detail: Standard (opaque), IP20
TCS/T-23 Type: Terminal cover, short | For: 125AF and ABH/EBH50c | Poles: 3P | Detail: Transparent, IP20
TCL23 Type: Terminal cover, long | For: 125AF and ABH/EBH50c | Poles: 3P | Detail: Standard (opaque), IP20
TCL/T-23 Type: Terminal cover, long | For: 125AF and ABH/EBH50c | Poles: 3P | Detail: Transparent, IP20
TCS24 Type: Terminal cover, short | For: 125AF and ABH/EBH50c | Poles: 4P | Detail: Standard (opaque), IP20
TCS/T-24 Type: Terminal cover, short | For: 125AF and ABH/EBH50c | Poles: 4P | Detail: Transparent, IP20
TCL24 Type: Terminal cover, long | For: 125AF and ABH/EBH50c | Poles: 4P | Detail: Standard (opaque), IP20
TCL/T-24 Type: Terminal cover, long | For: 125AF and ABH/EBH50c | Poles: 4P | Detail: Transparent, IP20
TCS33 Type: Terminal cover, short | For: 250AF | Poles: 2P/3P | Detail: Standard (opaque), IP20
TCS/T-33 Type: Terminal cover, short | For: 250AF | Poles: 2P/3P | Detail: Transparent, IP20
TCL33 Type: Terminal cover, long | For: 250AF | Poles: 2P/3P | Detail: Standard (opaque), IP20
TCL/T-33 Type: Terminal cover, long | For: 250AF | Poles: 2P/3P | Detail: Transparent, IP20
TCS34 Type: Terminal cover, short | For: 250AF | Poles: 4P | Detail: Standard (opaque), IP20
TCS/T-34 Type: Terminal cover, short | For: 250AF | Poles: 4P | Detail: Transparent, IP20
TCL34 Type: Terminal cover, long | For: 250AF | Poles: 4P | Detail: Standard (opaque), IP20
TCL/T-34 Type: Terminal cover, long | For: 250AF | Poles: 4P | Detail: Transparent, IP20
TBS22 Type: Terminal cover, short | For: 30AF ABE30b | Poles: 2P | Detail: Standard (opaque), IP20
TBS23 Type: Terminal cover, short | For: 30AF ABE30b | Poles: 3P | Detail: Standard (opaque), IP20
T1-43A Type: Terminal cover, long | For: 400AF | Poles: 2P/3P | Detail: Acrylic, standard
T1/T-43A Type: Terminal cover, long | For: 400AF | Poles: 2P/3P | Detail: Transparent, for N-handle
T1-44A Type: Terminal cover, long | For: 400AF | Poles: 4P | Detail: Acrylic, standard
T1-63A Type: Terminal cover, long | For: 630/800AF | Poles: 2P/3P | Detail: Acrylic, standard
T1/T-63A Type: Terminal cover, long | For: 630/800AF | Poles: 2P/3P | Detail: Transparent, for N-handle
T1-64A Type: Terminal cover, long | For: 630/800AF | Poles: 4P | Detail: Acrylic, standard
B-03B Type: Insulation barrier | For: 30AF ABE30b | Poles: All | Detail: Line side supplied as standard
IB-13 Type: Insulation barrier | For: 30-100AF (ABN/EBN, ABS/EBS 30-60c) | Poles: All | Detail: Line side supplied as standard
IB-23 Type: Insulation barrier | For: 125AF, 250AF, ABH/EBH50c | Poles: All | Detail: Line side supplied as standard
B-43B Type: Insulation barrier | For: 400AF | Poles: All | Detail: Line side supplied as standard
B-33C Type: Insulation barrier | For: 630/800AF | Poles: All | Detail: Line side supplied as standard
RTR1-52 Type: Rear connection terminal | For: ABN/EBN 30c-50c | Poles: 2P | Detail: Round type
RTR1-53 Type: Rear connection terminal | For: ABN/EBN 30c-50c | Poles: 3P | Detail: Round type
RTR1-54 Type: Rear connection terminal | For: ABN/EBN 30c-50c | Poles: 4P | Detail: Round type
RTR1-102 Type: Rear connection terminal | For: ABN/EBN 60c-100c | Poles: 2P | Detail: Round type
RTR1-103 Type: Rear connection terminal | For: ABN/EBN 60c-100c | Poles: 3P | Detail: Round type
RTR1-104 Type: Rear connection terminal | For: ABN/EBN 60c-100c | Poles: 4P | Detail: Round type
RTR2-102 Type: Rear connection terminal | For: ABH/EBH125c | Poles: 2P | Detail: Round type
RTR2-103 Type: Rear connection terminal | For: ABH/EBH125c | Poles: 3P | Detail: Round type
RTR2-104 Type: Rear connection terminal | For: ABH/EBH125c | Poles: 4P | Detail: Round type
RTR3-202 Type: Rear connection terminal | For: ABH/EBH250c | Poles: 2P | Detail: Round type
RTR3-203 Type: Rear connection terminal | For: ABH/EBH250c | Poles: 3P | Detail: Round type
RTR3-204 Type: Rear connection terminal | For: ABH/EBH250c | Poles: 4P | Detail: Round type
RTB1-102 Type: Rear connection terminal | For: ABN/EBN 30c-100c | Poles: 2P | Detail: Bar (flat) type
RTB1-103 Type: Rear connection terminal | For: ABN/EBN 30c-100c | Poles: 3P | Detail: Bar (flat) type
RTB1-104 Type: Rear connection terminal | For: ABN/EBN 30c-100c | Poles: 4P | Detail: Bar (flat) type
RTB2-102 Type: Rear connection terminal | For: ABH/EBH125c | Poles: 2P | Detail: Bar (flat) type
RTB2-103 Type: Rear connection terminal | For: ABH/EBH125c | Poles: 3P | Detail: Bar (flat) type
RTB2-104 Type: Rear connection terminal | For: ABH/EBH125c | Poles: 4P | Detail: Bar (flat) type
RTB3-202 Type: Rear connection terminal | For: ABH/EBH250c | Poles: 2P | Detail: Bar (flat) type
RTB3-203 Type: Rear connection terminal | For: ABH/EBH250c | Poles: 3P | Detail: Bar (flat) type
RTB3-204 Type: Rear connection terminal | For: ABH/EBH250c | Poles: 4P | Detail: Bar (flat) type
MI-13 Type: Mechanical interlock | For: 100AF (ABN/ABS/EBN/EBS 30-100c) | Poles: 3P | Detail: Interlocks two breakers side by side
MI-14 Type: Mechanical interlock | For: 100AF (ABN/ABS/EBN/EBS 30-100c) | Poles: 4P | Detail: Interlocks two breakers side by side
MI-23 Type: Mechanical interlock | For: 125AF and ABH/EBH50c | Poles: 3P | Detail: Interlocks two breakers side by side
MI-24 Type: Mechanical interlock | For: 125AF and ABH/EBH50c | Poles: 4P | Detail: Interlocks two breakers side by side
MI-33 Type: Mechanical interlock | For: 250AF | Poles: 3P | Detail: Interlocks two breakers side by side
MI-34 Type: Mechanical interlock | For: 250AF | Poles: 4P | Detail: Interlocks two breakers side by side
MI-43 Type: Mechanical interlock | For: 400AF | Poles: 3P | Detail: Interlocks two breakers side by side
MI-44 Type: Mechanical interlock | For: 400AF | Poles: 4P | Detail: Interlocks two breakers side by side
MI-83 Type: Mechanical interlock | For: 630/800AF (N/S/L) | Poles: 3P | Detail: Interlocks two breakers side by side
MI-84 Type: Mechanical interlock | For: 630/800AF (N/S/L) | Poles: 4P | Detail: Interlocks two breakers side by side
PB-A3-FR Type: Plug-in base | For: ABN100c | Poles: 3P | Detail: Normal type
PB-A3-1DB Type: Plug-in base | For: ABN100c | Poles: 3P | Detail: Single-row panelboard type
PB-A3-2DB Type: Plug-in base | For: ABN100c | Poles: 3P | Detail: Double-row panelboard type
PB-A3-FRL Type: Plug-in base | For: ABN100c | Poles: 3P | Detail: Line-side only type
PB-C3-FR Type: Plug-in base | For: ABH125c | Poles: 3P | Detail: Normal type
PB-C3-1DB Type: Plug-in base | For: ABH125c | Poles: 3P | Detail: Single-row panelboard type
PB-C3-2DB Type: Plug-in base | For: ABH125c | Poles: 3P | Detail: Double-row panelboard type
PB-C3-FRL Type: Plug-in base | For: ABH125c | Poles: 3P | Detail: Line-side only type
PB-D3-FR Type: Plug-in base | For: ABH250c | Poles: 3P | Detail: Normal type
PB-I3-FR Type: Plug-in base | For: 400AF | Poles: 3P | Detail: Normal type
PB-I3-FRL Type: Plug-in base | For: 400AF | Poles: 3P | Detail: Line-side only type
PB-J3-FR Type: Plug-in base | For: 630/800AF | Poles: 3P | Detail: Normal type
MOP-M1 Type: Motor operator | For: 50-100AF (ABN/ABS 30-100c) | Poles: 3P/4P | Detail: DC24V, AC/DC110V, AC230V/DC220V
MOP-M2 Type: Motor operator | For: 125AF and ABH53c/54c | Poles: 3P/4P | Detail: DC24V, AC/DC110V, AC230V/DC220V
MOP-M3 Type: Motor operator | For: 250AF | Poles: 2P/3P/4P | Detail: DC24V, AC/DC110V, AC230V/DC220V
MOP-M4 Type: Motor operator | For: 400AF | Poles: 2P/3P/4P | Detail: DC24V, AC/DC110V, AC230V/DC220V
MOP-M5 Type: Motor operator | For: 630/800AF | Poles: 2P/3P/4P | Detail: DC24V, AC/DC110V, AC230V/DC220V
MOP-M6 Type: Motor operator | For: 1000/1200AF | Poles: 3P/4P | Detail: AC230V/DC220V
