LS Electric Susol ACB Cradles AL (630-6300AF)

LS Electric Susol ACB Cradles AL (630-6300AF)

LS Electric Susol AL draw-out cradles for AH, AV, AW and DH air circuit breakers, 630 to 6300AF.

Key features

  • Cradle sized by frame group; one cradle serves all ratings of the group (use MIP to prevent mis-insertion)
  • Manual or automatic control-circuit connection
  • Busbar connection horizontal, vertical, mixed or front
  • Optional safety shutter; arc cover supplied as standard
  • AV and AW ACBs use the AH-type cradle

Specifications

Series Susol ACB
Mounting Draw-out cradle
Pole options 3P / 4P
Front-type busbar Terminal kit ordered separately
Restriction H20D and H40E vertical busbar only
Source LS Electric Susol ACB catalog C06061-23 (2025-11), p. 16
AL-H16D3-JHEN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-JHES For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-JHFN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-JHFS For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H16D3-JVEN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-JVES For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-JVFN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-JVFS For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H16D3-JMEN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H16D3-JMES For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H16D3-JMFN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H16D3-JMFS For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H16D3-JNEN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H16D3-JNES For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H16D3-JNFN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H16D3-JNFS For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H16D3-JPEN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-JPES For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-JPFN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-JPFS For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H16D3-AHEN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-AHES For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-AHFN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-AHFS For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H16D3-AVEN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-AVES For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-AVFN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-AVFS For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H16D3-AMEN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H16D3-AMES For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H16D3-AMFN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H16D3-AMFS For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H16D3-ANEN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H16D3-ANES For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H16D3-ANFN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H16D3-ANFS For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H16D3-APEN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-APES For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-APFN For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-APFS For body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-JHEN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-JHES For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-JHFN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-JHFS For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-JVEN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-JVES For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-JVFN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-JVFS For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-JMEN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H16D4-JMES For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H16D4-JMFN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H16D4-JMFS For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H16D4-JNEN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H16D4-JNES For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H16D4-JNFN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H16D4-JNFS For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H16D4-JPEN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-JPES For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-JPFN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-JPFS For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-AHEN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-AHES For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-AHFN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-AHFS For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-AVEN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-AVES For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-AVFN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-AVFS For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-AMEN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H16D4-AMES For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H16D4-AMFN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H16D4-AMFS For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H16D4-ANEN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H16D4-ANES For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H16D4-ANFN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H16D4-ANFS For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H16D4-APEN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-APES For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-APFN For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-APFS For body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H20D3-JVEN For body: AH/AV/AW-20D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H20D3-JVES For body: AH/AV/AW-20D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H20D3-JVFN For body: AH/AV/AW-20D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H20D3-JVFS For body: AH/AV/AW-20D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H20D3-AVEN For body: AH/AV/AW-20D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H20D3-AVES For body: AH/AV/AW-20D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H20D3-AVFN For body: AH/AV/AW-20D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H20D3-AVFS For body: AH/AV/AW-20D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H20D4-JVEN For body: AH/AV/AW-20D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H20D4-JVES For body: AH/AV/AW-20D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H20D4-JVFN For body: AH/AV/AW-20D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H20D4-JVFS For body: AH/AV/AW-20D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H20D4-AVEN For body: AH/AV/AW-20D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H20D4-AVES For body: AH/AV/AW-20D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H20D4-AVFN For body: AH/AV/AW-20D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H20D4-AVFS For body: AH/AV/AW-20D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-JHEN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-JHES For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-JHFN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-JHFS For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-JVEN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-JVES For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-JVFN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-JVFS For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-JMEN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H32E3-JMES For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H32E3-JMFN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H32E3-JMFS For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H32E3-JNEN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H32E3-JNES For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H32E3-JNFN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H32E3-JNFS For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H32E3-JPEN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-JPES For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-JPFN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-JPFS For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-AHEN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-AHES For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-AHFN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-AHFS For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-AVEN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-AVES For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-AVFN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-AVFS For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-AMEN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H32E3-AMES For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H32E3-AMFN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H32E3-AMFS For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H32E3-ANEN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H32E3-ANES For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H32E3-ANFN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H32E3-ANFS For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H32E3-APEN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-APES For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-APFN For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-APFS For body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-JHEN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-JHES For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-JHFN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-JHFS For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-JVEN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-JVES For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-JVFN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-JVFS For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-JMEN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H32E4-JMES For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H32E4-JMFN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H32E4-JMFS For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H32E4-JNEN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H32E4-JNES For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H32E4-JNFN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H32E4-JNFS For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H32E4-JPEN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-JPES For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-JPFN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-JPFS For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-AHEN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-AHES For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-AHFN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-AHFS For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-AVEN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-AVES For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-AVFN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-AVFS For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-AMEN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H32E4-AMES For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H32E4-AMFN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H32E4-AMFS For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H32E4-ANEN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H32E4-ANES For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H32E4-ANFN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H32E4-ANFS For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H32E4-APEN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-APES For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-APFN For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-APFS For body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H40E3-JVEN For body: AH/AV/AW-40E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H40E3-JVES For body: AH/AV/AW-40E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H40E3-JVFN For body: AH/AV/AW-40E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H40E3-JVFS For body: AH/AV/AW-40E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H40E3-AVEN For body: AH/AV/AW-40E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H40E3-AVES For body: AH/AV/AW-40E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H40E3-AVFN For body: AH/AV/AW-40E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H40E3-AVFS For body: AH/AV/AW-40E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H40E4-JVEN For body: AH/AV/AW-40E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H40E4-JVES For body: AH/AV/AW-40E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H40E4-JVFN For body: AH/AV/AW-40E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H40E4-JVFS For body: AH/AV/AW-40E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H40E4-AVEN For body: AH/AV/AW-40E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H40E4-AVES For body: AH/AV/AW-40E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H40E4-AVFN For body: AH/AV/AW-40E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H40E4-AVFS For body: AH/AV/AW-40E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H50G3-JHEN For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G3-JHES For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G3-JHFN For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G3-JHFS For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H50G3-JVEN For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G3-JVES For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G3-JVFN For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G3-JVFS For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H50G3-AHEN For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G3-AHES For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G3-AHFN For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G3-AHFS For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H50G3-AVEN For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G3-AVES For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G3-AVFN For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G3-AVFS For body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H50G4-JHEN For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G4-JHES For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G4-JHFN For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G4-JHFS For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H50G4-JVEN For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G4-JVES For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G4-JVFN For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G4-JVFS For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H50G4-AHEN For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G4-AHES For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G4-AHFN For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G4-AHFS For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H50G4-AVEN For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G4-AVES For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G4-AVFN For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G4-AVFS For body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H63G3-JHEN For body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G3-JHES For body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G3-JHFN For body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G3-JHFS For body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H63G3-JVEN For body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G3-JVES For body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G3-JVFN For body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G3-JVFS For body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H63G3-AHEN For body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G3-AHES For body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G3-AHFN For body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G3-AHFS For body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H63G3-AVEN For body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G3-AVES For body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G3-AVFN For body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G3-AVFS For body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H63G4-JHEN For body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G4-JHES For body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G4-JHFN For body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G4-JHFS For body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H63G4-JVEN For body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G4-JVES For body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G4-JVFN For body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G4-JVFS For body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H63G4-AHEN For body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G4-AHES For body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G4-AHFN For body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G4-AHFS For body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H63G4-AVEN For body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G4-AVES For body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G4-AVFN For body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G4-AVFS For body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AccessoriesLS Electric
256 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric Susol ACB Cradles AL (630-6300AF)

Brand LS Electric·Accessories

Available part numbers (256)

AL-H16D3-JHEN, AL-H16D3-JHES, AL-H16D3-JHFN, AL-H16D3-JHFS, AL-H16D3-JVEN, AL-H16D3-JVES, AL-H16D3-JVFN, AL-H16D3-JVFS, AL-H16D3-JMEN, AL-H16D3-JMES + 246 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AL-H16D3-JHENFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-JHESFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-JHFNFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-JHFSFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H16D3-JVENFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-JVESFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-JVFNFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-JVFSFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H16D3-JMENFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H16D3-JMESFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H16D3-JMFNFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H16D3-JMFSFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H16D3-JNENFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H16D3-JNESFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H16D3-JNFNFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H16D3-JNFSFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H16D3-JPENFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-JPESFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-JPFNFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-JPFSFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H16D3-AHENFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-AHESFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-AHFNFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-AHFSFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H16D3-AVENFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-AVESFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-AVFNFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-AVFSFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H16D3-AMENFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H16D3-AMESFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H16D3-AMFNFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H16D3-AMFSFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H16D3-ANENFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H16D3-ANESFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H16D3-ANFNFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H16D3-ANFSFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H16D3-APENFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D3-APESFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D3-APFNFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D3-APFSFor body: AH/AV/AW-06D to 16D | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-JHENFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-JHESFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-JHFNFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-JHFSFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-JVENFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-JVESFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-JVFNFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-JVFSFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-JMENFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H16D4-JMESFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H16D4-JMFNFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H16D4-JMFSFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H16D4-JNENFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H16D4-JNESFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H16D4-JNFNFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H16D4-JNFSFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H16D4-JPENFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-JPESFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-JPFNFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-JPFSFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-AHENFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-AHESFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-AHFNFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-AHFSFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-AVENFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-AVESFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-AVFNFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-AVFSFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H16D4-AMENFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H16D4-AMESFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H16D4-AMFNFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H16D4-AMFSFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H16D4-ANENFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H16D4-ANESFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H16D4-ANFNFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H16D4-ANFSFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H16D4-APENFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H16D4-APESFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H16D4-APFNFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H16D4-APFSFor body: AH/AV/AW-06D to 16D | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H20D3-JVENFor body: AH/AV/AW-20D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H20D3-JVESFor body: AH/AV/AW-20D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H20D3-JVFNFor body: AH/AV/AW-20D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H20D3-JVFSFor body: AH/AV/AW-20D | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H20D3-AVENFor body: AH/AV/AW-20D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H20D3-AVESFor body: AH/AV/AW-20D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H20D3-AVFNFor body: AH/AV/AW-20D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H20D3-AVFSFor body: AH/AV/AW-20D | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H20D4-JVENFor body: AH/AV/AW-20D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H20D4-JVESFor body: AH/AV/AW-20D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H20D4-JVFNFor body: AH/AV/AW-20D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H20D4-JVFSFor body: AH/AV/AW-20D | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H20D4-AVENFor body: AH/AV/AW-20D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H20D4-AVESFor body: AH/AV/AW-20D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H20D4-AVFNFor body: AH/AV/AW-20D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H20D4-AVFSFor body: AH/AV/AW-20D | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-JHENFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-JHESFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-JHFNFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-JHFSFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-JVENFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-JVESFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-JVFNFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-JVFSFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-JMENFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H32E3-JMESFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H32E3-JMFNFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H32E3-JMFSFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H32E3-JNENFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H32E3-JNESFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H32E3-JNFNFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H32E3-JNFSFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H32E3-JPENFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-JPESFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-JPFNFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-JPFSFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-AHENFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-AHESFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-AHFNFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-AHFSFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-AVENFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-AVESFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-AVFNFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-AVFSFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H32E3-AMENFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H32E3-AMESFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H32E3-AMFNFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H32E3-AMFSFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H32E3-ANENFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H32E3-ANESFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H32E3-ANFNFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H32E3-ANFSFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H32E3-APENFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E3-APESFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E3-APFNFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E3-APFSFor body: AH/AV/AW-06E to 32E | Poles: 3P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-JHENFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-JHESFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-JHFNFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-JHFSFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-JVENFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-JVESFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-JVFNFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-JVFSFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-JMENFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H32E4-JMESFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H32E4-JMFNFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H32E4-JMFSFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H32E4-JNENFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H32E4-JNESFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H32E4-JNFNFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H32E4-JNFSFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H32E4-JPENFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-JPESFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-JPFNFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-JPFSFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Manual | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-AHENFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-AHESFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-AHFNFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-AHFSFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-AVENFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-AVESFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-AVFNFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-AVFSFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H32E4-AMENFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: Without
AL-H32E4-AMESFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: Without | Arc cover: With
AL-H32E4-AMFNFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: Without
AL-H32E4-AMFSFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top horiz. / bottom vert. | Safety shutter: With | Arc cover: With
AL-H32E4-ANENFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: Without
AL-H32E4-ANESFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: Without | Arc cover: With
AL-H32E4-ANFNFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: Without
AL-H32E4-ANFSFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: top vert. / bottom horiz. | Safety shutter: With | Arc cover: With
AL-H32E4-APENFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: Without
AL-H32E4-APESFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: Without | Arc cover: With
AL-H32E4-APFNFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: Without
AL-H32E4-APFSFor body: AH/AV/AW-06E to 32E | Poles: 4P | Connection: Automatic | Busbar: front (flat) top/bottom | Safety shutter: With | Arc cover: With
AL-H40E3-JVENFor body: AH/AV/AW-40E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H40E3-JVESFor body: AH/AV/AW-40E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H40E3-JVFNFor body: AH/AV/AW-40E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H40E3-JVFSFor body: AH/AV/AW-40E | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H40E3-AVENFor body: AH/AV/AW-40E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H40E3-AVESFor body: AH/AV/AW-40E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H40E3-AVFNFor body: AH/AV/AW-40E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H40E3-AVFSFor body: AH/AV/AW-40E | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H40E4-JVENFor body: AH/AV/AW-40E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H40E4-JVESFor body: AH/AV/AW-40E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H40E4-JVFNFor body: AH/AV/AW-40E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H40E4-JVFSFor body: AH/AV/AW-40E | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H40E4-AVENFor body: AH/AV/AW-40E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H40E4-AVESFor body: AH/AV/AW-40E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H40E4-AVFNFor body: AH/AV/AW-40E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H40E4-AVFSFor body: AH/AV/AW-40E | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H50G3-JHENFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G3-JHESFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G3-JHFNFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G3-JHFSFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H50G3-JVENFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G3-JVESFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G3-JVFNFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G3-JVFSFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H50G3-AHENFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G3-AHESFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G3-AHFNFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G3-AHFSFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H50G3-AVENFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G3-AVESFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G3-AVFNFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G3-AVFSFor body: AH/AV/AW-40G, 50G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H50G4-JHENFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G4-JHESFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G4-JHFNFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G4-JHFSFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H50G4-JVENFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G4-JVESFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G4-JVFNFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G4-JVFSFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H50G4-AHENFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G4-AHESFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G4-AHFNFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G4-AHFSFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H50G4-AVENFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H50G4-AVESFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H50G4-AVFNFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H50G4-AVFSFor body: AH/AV/AW-40G, 50G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H63G3-JHENFor body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G3-JHESFor body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G3-JHFNFor body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G3-JHFSFor body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H63G3-JVENFor body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G3-JVESFor body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G3-JVFNFor body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G3-JVFSFor body: AH/AV/AW-63G | Poles: 3P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H63G3-AHENFor body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G3-AHESFor body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G3-AHFNFor body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G3-AHFSFor body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H63G3-AVENFor body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G3-AVESFor body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G3-AVFNFor body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G3-AVFSFor body: AH/AV/AW-63G | Poles: 3P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H63G4-JHENFor body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G4-JHESFor body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G4-JHFNFor body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G4-JHFSFor body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H63G4-JVENFor body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G4-JVESFor body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G4-JVFNFor body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G4-JVFSFor body: AH/AV/AW-63G | Poles: 4P | Connection: Manual | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With
AL-H63G4-AHENFor body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G4-AHESFor body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G4-AHFNFor body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G4-AHFSFor body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: horizontal top/bottom | Safety shutter: With | Arc cover: With
AL-H63G4-AVENFor body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: Without
AL-H63G4-AVESFor body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: Without | Arc cover: With
AL-H63G4-AVFNFor body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: Without
AL-H63G4-AVFSFor body: AH/AV/AW-63G | Poles: 4P | Connection: Automatic | Busbar: vertical top/bottom | Safety shutter: With | Arc cover: With

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Circuit Breakers & Contactors →
