LS Electric Susol DC MCCB PV Busbar, Heat Sink and Cover Kits

LS Electric Susol DC MCCB PV Busbar, Heat Sink and Cover Kits

LS Electric order-coded short busbars, heat sinks, terminal covers and rear barriers for Susol PV/DC MCCB TD100-TS800 and TSD250.

Key features

  • Short busbar plus heat sink kits restore full rated current on PV combiner installations
  • Busbar-only kits for 3P; order two sets for 4P breakers
  • Terminal cover and rear barrier kits for 4P DC breakers
  • TSD250 dedicated kit with busbars, heat sinks, line/load terminal covers and barriers
  • Load-side terminal cover on TSD requires 90% current derating

Specifications

Brand LS Electric
Series Susol MCCB PV / DC
Product group Connection and insulation accessories
Busbar thickness 5t (TD/TS100-250), 6t (TS400-800)
Supply Optional, ordered separately
Source LS Electric DC Component for Renewable Energy catalog C19941-05 (2022-06), p. 14-15, 21
83261171072 Item: Short busbar + heat sink (1 each) | Applies to: TD100, TD160 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261172072 Item: Short busbar + heat sink (1 each) | Applies to: TS100, TS160, TS250 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261173075 Item: Short busbar + heat sink (1 each) | Applies to: TS400, TS630 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261174075 Item: Short busbar + heat sink (1 each) | Applies to: TS800 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261171073 Item: Short busbar (1 pc, 3P basis) | Applies to: TD100, TD160 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261172073 Item: Short busbar (1 pc, 3P basis) | Applies to: TS100, TS160, TS250 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261173076 Item: Short busbar (1 pc, 3P basis) | Applies to: TS400, TS630 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261174076 Item: Short busbar (1 pc, 3P basis) | Applies to: TS800 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261171071 Item: Terminal cover 2 + rear barrier 2 | Applies to: TD100, TD160 | Order quantity: 4P only | Catalog page: 14
83261172071 Item: Terminal cover 2 + rear barrier 2 | Applies to: TS100, TS160, TS250 | Order quantity: 4P only | Catalog page: 14
83261173074 Item: Terminal cover 2 + rear barrier 2 | Applies to: TS400, TS630 | Order quantity: 4P only | Catalog page: 14
83261174074 Item: Terminal cover 2 + rear barrier 2 | Applies to: TS800 | Order quantity: 4P only | Catalog page: 14
83261172171 Item: Busbar 2, heat sink 2, covers, barriers | Applies to: TSD250 | Order quantity: Per breaker | Catalog page: 21
AccessoriesLS Electric
13 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric Susol DC MCCB PV Busbar, Heat Sink and Cover Kits

Brand LS Electric·Accessories

Available part numbers (13)

83261171072, 83261172072, 83261173075, 83261174075, 83261171073, 83261172073, 83261173076, 83261174076, 83261171071, 83261172071 + 3 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
83261171072Item: Short busbar + heat sink (1 each) | Applies to: TD100, TD160 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261172072Item: Short busbar + heat sink (1 each) | Applies to: TS100, TS160, TS250 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261173075Item: Short busbar + heat sink (1 each) | Applies to: TS400, TS630 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261174075Item: Short busbar + heat sink (1 each) | Applies to: TS800 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261171073Item: Short busbar (1 pc, 3P basis) | Applies to: TD100, TD160 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261172073Item: Short busbar (1 pc, 3P basis) | Applies to: TS100, TS160, TS250 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261173076Item: Short busbar (1 pc, 3P basis) | Applies to: TS400, TS630 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261174076Item: Short busbar (1 pc, 3P basis) | Applies to: TS800 | Order quantity: 3P 1 set, 4P 2 sets | Catalog page: 14
83261171071Item: Terminal cover 2 + rear barrier 2 | Applies to: TD100, TD160 | Order quantity: 4P only | Catalog page: 14
83261172071Item: Terminal cover 2 + rear barrier 2 | Applies to: TS100, TS160, TS250 | Order quantity: 4P only | Catalog page: 14
83261173074Item: Terminal cover 2 + rear barrier 2 | Applies to: TS400, TS630 | Order quantity: 4P only | Catalog page: 14
83261174074Item: Terminal cover 2 + rear barrier 2 | Applies to: TS800 | Order quantity: 4P only | Catalog page: 14
83261172171Item: Busbar 2, heat sink 2, covers, barriers | Applies to: TSD250 | Order quantity: Per breaker | Catalog page: 21
