LS Electric Susol UL MCCB Lugs, Terminals, Barriers and Covers

LS Electric Susol UL MCCB Lugs, Terminals, Barriers and Covers

Mechanical lugs, control-wire and busbar terminals, insulation barriers and terminal covers for LS Electric Susol UL 489 breakers.

Key features

  • Aluminium mechanical lugs for Cu/Al wire, 100 to 1200 A (AL100TE to AL1200TS)
  • CWT control-wire terminals for lug or busbar connection
  • TP busbar terminal sets for UTS150 and UTS250
  • B / BE insulation barriers between phases
  • Transparent ITU terminal covers

Specifications

Applicable breakers Susol UTE100, UTS150-UTS1200 (UL 489)
Code LS item code (11-12 digits) as printed
Brand LS Electric
Standard For UL 489 listed Susol breakers
Installation Field-installable unless noted
Source LS Electric Susol UL MCCB catalog C01081-17 (2026-07), p. 16, 17, 23, 24, 30, 31, 37, 38, 44, 57, 58, 63
70821175005 Accessory: Mechanical lug | Order name: AL100TE | Detail: 100 A, Al, Cu/Al wire | For frames: UTE100
70821172021 Accessory: Mechanical lug | Order name: AL150TS | Detail: 150 A, Al, Cu/Al wire | For frames: UTS150
70821172023 Accessory: Mechanical lug | Order name: AL250TS | Detail: 250 A, Al, Cu/Al wire | For frames: UTS250
70821173006 Accessory: Mechanical lug | Order name: AL400TS | Detail: 400 A, Al, Cu/Al wire | For frames: UTS400
70821173008 Accessory: Mechanical lug | Order name: AL600TS | Detail: 600 A, Al, Cu/Al wire | For frames: UTS600
62671176002 Accessory: Mechanical lug | Order name: AL800TS | Detail: 800 A, Al, Cu/Al wire | For frames: UTS800
70821176304 Accessory: Mechanical lug | Order name: AL1200TS | Detail: 1200 A, Al, Cu/Al wire | For frames: UTS1200
62671175001 Accessory: Control wire terminal | Order name: CWT | Detail: Set of 2, for lug terminal | For frames: UTE100
62671175002 Accessory: Control wire terminal | Order name: CWT | Detail: Set of 2, for busbar terminal | For frames: UTE100
62671172004 Accessory: Control wire terminal | Order name: CWT | Detail: Set of 2 | For frames: UTS150
62671172005 Accessory: Control wire terminal | Order name: CWT | Detail: Set of 2 | For frames: UTS250
62671173001 Accessory: Control wire terminal | Order name: CWT | Detail: Set of 2 | For frames: UTS400
62671173002 Accessory: Control wire terminal | Order name: CWT | Detail: Set of 2 | For frames: UTS600, UTS800
62671176001 Accessory: Control wire terminal | Order name: CWT | Detail: Set of 2, 4 hole | For frames: UTS1200
62671176003 Accessory: Control wire terminal | Order name: CWT | Detail: Set of 2, 3 hole | For frames: UTS1200
83261172053 Accessory: Busbar terminal | Order name: TP2a3 | Detail: Set of 3, 3P | For frames: UTS150
83261172054 Accessory: Busbar terminal | Order name: TP2b3 | Detail: Set of 3, 3P | For frames: UTS250
83261172026 Accessory: Insulation barrier | Order name: B23 | Detail: Set of 4, 3P | For frames: UTS150/250
83261173407 Accessory: Insulation barrier | Order name: B33 | Detail: Set of 4, 3P | For frames: UTS400/600
83261176815 Accessory: Insulation barrier | Order name: B53 | Detail: Set of 2, standard terminal | For frames: UTS800/1200
83261176811 Accessory: Insulation barrier | Order name: BE53 | Detail: Set of 2, extended terminal | For frames: UTS800/1200
64621175284 Accessory: Terminal cover | Order name: ITU02 | Detail: 2P, transparent | For frames: UTE100
64621175282 Accessory: Terminal cover | Order name: ITU03 | Detail: 3P, transparent | For frames: UTE100
64621177496 Accessory: Terminal cover | Order name: ITU-2a3 | Detail: 3P, transparent | For frames: UTS150
64621177498 Accessory: Terminal cover | Order name: ITU-2b3 | Detail: 3P, transparent | For frames: UTS250
64621178047 Accessory: Terminal cover | Order name: ITU33 | Detail: 3P, transparent | For frames: UTS400/600
