LS Electric Susol UTS250 UL 489 MCCB (150-250 A)

LS Electric Susol UTS250 UL 489 MCCB (150-250 A)

LS Electric Susol UTS250 molded case circuit breakers are UL 489 listed for North American and export panels, covering 150-250 A with thermal-magnetic, electronic, switch and motor-protection versions.

Key features

  • UL 489 listed 250 AF breaker, 2P and 3P, up to 600 Vac
  • N, H and L interrupting classes up to 150 kA at 240 Vac
  • FTU, FMU, ATU thermal-magnetic and ETS23 electronic (LI/LSI/LIG) trip units
  • MCS molded case switch and MCP motor circuit protector versions
  • Same 105 mm width as UTS150 for compact panel layouts

Specifications

Frame size 250 AF
Rated insulation voltage (Ui) AC 750 V
Rated impulse voltage (Uimp) 8 kV
UL 489 interrupting rating (240/480/600 V) N 65/35/18 kA, H 100/65/35 kA, L 150/100/50 kA
DC rating (250 V 2P / 600 V 3P) N 35 kA, H 50 kA, L 65 kA
Dimensions (W x H x D) 105 x 190 x 87.5 mm (2P/3P)
Applications HACR
Standards UL 489, CSA C22.2 No.5, IEC 60947-2
Rated frequency AC 50/60 Hz
Source LS Electric Susol UL MCCB catalog C01081-17 (2026-07), p. 26-29
UTS250-H-FTU-150A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-H-FTU-150A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-HT-FTU-150A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-HT-FTU-150A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-L-FTU-150A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-L-FTU-150A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-LT-FTU-150A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-LT-FTU-150A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-N-FTU-150A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-N-FTU-150A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-NT-FTU-150A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-NT-FTU-150A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-H-FTU-175A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-H-FTU-175A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-HT-FTU-175A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-HT-FTU-175A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-L-FTU-175A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-L-FTU-175A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-LT-FTU-175A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-LT-FTU-175A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-N-FTU-175A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-N-FTU-175A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-NT-FTU-175A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-NT-FTU-175A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-H-FTU-200A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-H-FTU-200A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-HT-FTU-200A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-HT-FTU-200A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-L-FTU-200A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-L-FTU-200A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-LT-FTU-200A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-LT-FTU-200A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-N-FTU-200A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-N-FTU-200A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-NT-FTU-200A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-NT-FTU-200A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-H-FTU-225A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-H-FTU-225A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-HT-FTU-225A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-HT-FTU-225A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-L-FTU-225A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-L-FTU-225A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-LT-FTU-225A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-LT-FTU-225A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-N-FTU-225A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-N-FTU-225A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-NT-FTU-225A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-NT-FTU-225A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-H-FTU-250A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-H-FTU-250A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-HT-FTU-250A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-HT-FTU-250A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-L-FTU-250A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-L-FTU-250A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-LT-FTU-250A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-LT-FTU-250A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-N-FTU-250A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-N-FTU-250A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-NT-FTU-250A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-NT-FTU-250A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-H-FMU-160A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-H-FMU-160A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-HT-FMU-160A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-HT-FMU-160A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-L-FMU-160A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-L-FMU-160A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-LT-FMU-160A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-LT-FMU-160A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-N-FMU-160A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-N-FMU-160A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-NT-FMU-160A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-NT-FMU-160A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-H-FMU-200A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-H-FMU-200A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-HT-FMU-200A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-HT-FMU-200A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-L-FMU-200A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-L-FMU-200A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-LT-FMU-200A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-LT-FMU-200A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-N-FMU-200A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-N-FMU-200A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-NT-FMU-200A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-NT-FMU-200A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-H-FMU-250A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-H-FMU-250A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-HT-FMU-250A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-HT-FMU-250A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-L-FMU-250A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-L-FMU-250A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-LT-FMU-250A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-LT-FMU-250A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-N-FMU-250A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-N-FMU-250A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-NT-FMU-250A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-NT-FMU-250A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-H-ATU-160A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-H-ATU-160A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-HT-ATU-160A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-HT-ATU-160A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-L-ATU-160A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-L-ATU-160A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-LT-ATU-160A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-LT-ATU-160A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-N-ATU-160A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-N-ATU-160A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-NT-ATU-160A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-NT-ATU-160A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-H-ATU-200A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-H-ATU-200A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-HT-ATU-200A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-HT-ATU-200A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-L-ATU-200A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-L-ATU-200A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-LT-ATU-200A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-LT-ATU-200A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-N-ATU-200A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-N-ATU-200A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-NT-ATU-200A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-NT-ATU-200A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-H-ATU-250A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-H-ATU-250A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-HT-ATU-250A-2P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-HT-ATU-250A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-L-ATU-250A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-L-ATU-250A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-LT-ATU-250A-2P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-LT-ATU-250A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-N-ATU-250A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-N-ATU-250A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-NT-ATU-250A-2P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-NT-ATU-250A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-H-ETS23-150A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-HT-ETS23-150A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-L-ETS23-150A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-LT-ETS23-150A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-N-ETS23-150A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-NT-ETS23-150A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-H-ETS23-250A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-HT-ETS23-250A-3P-UL Type: HT, 65 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-L-ETS23-250A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-LT-ETS23-250A-3P-UL Type: LT, 100 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-N-ETS23-250A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-NT-ETS23-250A-3P-UL Type: NT, 35 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-H-MCS-175A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-H-MCS-175A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-L-MCS-175A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-L-MCS-175A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-N-MCS-175A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-N-MCS-175A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-H-MCS-250A-2P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-H-MCS-250A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-L-MCS-250A-2P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-L-MCS-250A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-N-MCS-250A-2P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-N-MCS-250A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-H-MCP-220A-3P-UL Type: H, 65 kA at 480 V, 80% rated | Trip unit: MCP motor circuit protector | Rated current In: 220 A | Setting: Ii 1320-2640 A | Poles: 3P
UTS250-L-MCP-220A-3P-UL Type: L, 100 kA at 480 V, 80% rated | Trip unit: MCP motor circuit protector | Rated current In: 220 A | Setting: Ii 1320-2640 A | Poles: 3P
UTS250-N-MCP-220A-3P-UL Type: N, 35 kA at 480 V, 80% rated | Trip unit: MCP motor circuit protector | Rated current In: 220 A | Setting: Ii 1320-2640 A | Poles: 3P
Molded Case Circuit BreakersLS Electric
159 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric Susol UTS250 UL 489 MCCB (150-250 A)

Brand LS Electric·Molded Case Circuit Breakers

Available part numbers (159)

UTS250-H-FTU-150A-2P-UL, UTS250-H-FTU-150A-3P-UL, UTS250-HT-FTU-150A-2P-UL, UTS250-HT-FTU-150A-3P-UL, UTS250-L-FTU-150A-2P-UL, UTS250-L-FTU-150A-3P-UL, UTS250-LT-FTU-150A-2P-UL, UTS250-LT-FTU-150A-3P-UL, UTS250-N-FTU-150A-2P-UL, UTS250-N-FTU-150A-3P-UL + 149 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UTS250-H-FTU-150A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-H-FTU-150A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-HT-FTU-150A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-HT-FTU-150A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-L-FTU-150A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-L-FTU-150A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-LT-FTU-150A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-LT-FTU-150A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-N-FTU-150A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-N-FTU-150A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-NT-FTU-150A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 2P
UTS250-NT-FTU-150A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 150 A | Setting: Fixed | Poles: 3P
UTS250-H-FTU-175A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-H-FTU-175A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-HT-FTU-175A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-HT-FTU-175A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-L-FTU-175A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-L-FTU-175A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-LT-FTU-175A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-LT-FTU-175A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-N-FTU-175A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-N-FTU-175A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-NT-FTU-175A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 2P
UTS250-NT-FTU-175A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 175 A | Setting: Fixed | Poles: 3P
UTS250-H-FTU-200A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-H-FTU-200A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-HT-FTU-200A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-HT-FTU-200A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-L-FTU-200A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-L-FTU-200A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-LT-FTU-200A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-LT-FTU-200A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-N-FTU-200A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-N-FTU-200A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-NT-FTU-200A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 2P
UTS250-NT-FTU-200A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 200 A | Setting: Fixed | Poles: 3P
UTS250-H-FTU-225A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-H-FTU-225A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-HT-FTU-225A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-HT-FTU-225A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-L-FTU-225A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-L-FTU-225A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-LT-FTU-225A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-LT-FTU-225A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-N-FTU-225A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-N-FTU-225A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-NT-FTU-225A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 2P
UTS250-NT-FTU-225A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 225 A | Setting: Fixed | Poles: 3P
UTS250-H-FTU-250A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-H-FTU-250A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-HT-FTU-250A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-HT-FTU-250A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-L-FTU-250A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-L-FTU-250A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-LT-FTU-250A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-LT-FTU-250A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-N-FTU-250A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-N-FTU-250A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-NT-FTU-250A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 2P
UTS250-NT-FTU-250A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FTU (fixed thermal, fixed magnetic) | Rated current In: 250 A | Setting: Fixed | Poles: 3P
UTS250-H-FMU-160A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-H-FMU-160A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-HT-FMU-160A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-HT-FMU-160A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-L-FMU-160A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-L-FMU-160A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-LT-FMU-160A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-LT-FMU-160A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-N-FMU-160A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-N-FMU-160A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-NT-FMU-160A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-NT-FMU-160A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-H-FMU-200A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-H-FMU-200A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-HT-FMU-200A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-HT-FMU-200A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-L-FMU-200A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-L-FMU-200A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-LT-FMU-200A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-LT-FMU-200A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-N-FMU-200A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-N-FMU-200A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-NT-FMU-200A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-NT-FMU-200A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-H-FMU-250A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-H-FMU-250A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-HT-FMU-250A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-HT-FMU-250A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-L-FMU-250A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-L-FMU-250A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-LT-FMU-250A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-LT-FMU-250A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-N-FMU-250A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-N-FMU-250A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-NT-FMU-250A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-NT-FMU-250A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: FMU (adj. thermal, fixed magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-H-ATU-160A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-H-ATU-160A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-HT-ATU-160A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-HT-ATU-160A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-L-ATU-160A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-L-ATU-160A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-LT-ATU-160A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-LT-ATU-160A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-N-ATU-160A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-N-ATU-160A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-NT-ATU-160A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 2P
UTS250-NT-ATU-160A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 160 A | Setting: Ir 128-160 A | Poles: 3P
UTS250-H-ATU-200A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-H-ATU-200A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-HT-ATU-200A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-HT-ATU-200A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-L-ATU-200A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-L-ATU-200A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-LT-ATU-200A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-LT-ATU-200A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-N-ATU-200A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-N-ATU-200A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-NT-ATU-200A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 2P
UTS250-NT-ATU-200A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 200 A | Setting: Ir 160-200 A | Poles: 3P
UTS250-H-ATU-250A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-H-ATU-250A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-HT-ATU-250A-2P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-HT-ATU-250A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-L-ATU-250A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-L-ATU-250A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-LT-ATU-250A-2P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-LT-ATU-250A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-N-ATU-250A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-N-ATU-250A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-NT-ATU-250A-2P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 2P
UTS250-NT-ATU-250A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: ATU (adj. thermal, adj. magnetic) | Rated current In: 250 A | Setting: Ir 200-250 A | Poles: 3P
UTS250-H-ETS23-150A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-HT-ETS23-150A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-L-ETS23-150A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-LT-ETS23-150A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-N-ETS23-150A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-NT-ETS23-150A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 150 A | Setting: Ir 60-150 A | Poles: 3P
UTS250-H-ETS23-250A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-HT-ETS23-250A-3P-ULType: HT, 65 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-L-ETS23-250A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-LT-ETS23-250A-3P-ULType: LT, 100 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-N-ETS23-250A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-NT-ETS23-250A-3P-ULType: NT, 35 kA at 480 V, 100% rated | Trip unit: ETS23 electronic (LI/LSI/LIG) | Rated current In: 250 A | Setting: Ir 80-250 A | Poles: 3P
UTS250-H-MCS-175A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-H-MCS-175A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-L-MCS-175A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-L-MCS-175A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-N-MCS-175A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-N-MCS-175A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 175 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-H-MCS-250A-2P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-H-MCS-250A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-L-MCS-250A-2P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-L-MCS-250A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-N-MCS-250A-2P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 2P
UTS250-N-MCS-250A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: MCS molded case switch | Rated current In: 250 A | Setting: Ii fixed 10 x In | Poles: 3P
UTS250-H-MCP-220A-3P-ULType: H, 65 kA at 480 V, 80% rated | Trip unit: MCP motor circuit protector | Rated current In: 220 A | Setting: Ii 1320-2640 A | Poles: 3P
UTS250-L-MCP-220A-3P-ULType: L, 100 kA at 480 V, 80% rated | Trip unit: MCP motor circuit protector | Rated current In: 220 A | Setting: Ii 1320-2640 A | Poles: 3P
UTS250-N-MCP-220A-3P-ULType: N, 35 kA at 480 V, 80% rated | Trip unit: MCP motor circuit protector | Rated current In: 220 A | Setting: Ii 1320-2640 A | Poles: 3P

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Circuit Breakers & Contactors →
