LS Electric XGT XGB Main and Expansion Bases (4 to 12 Slots)

LS Electric XGT XGB Main and Expansion Bases (4 to 12 Slots)

LS Electric XGT XGB-M main bases carry the power supply, CPU and up to 12 I/O modules, while XGB-E expansion bases extend the system by expansion cable.

Key features

  • Main bases with 4, 6, 8, 10 or 12 I/O slots plus power and CPU slots
  • Expansion bases with 4, 6, 8 or 12 I/O slots plus a power slot
  • Up to 7 expansion stages depending on CPU, total cable length 15 m
  • Each slot is allocated 64 I/O points (XGI) or 64/16 points (XGK fixed/variable)
  • Connect with XGC-E expansion cables; terminate the last base with XGT-TERA

Specifications

Compatible CPUs XGK, XGI (incl. XGI-CPUZ)
Power module XGP series (separate)
Expansion cable XGC-E041 to XGC-E152 (separate)
Max. expansion distance 15 m total
Operating temperature 0 to 55 C
Humidity 5 to 95% RH, non-condensing
Vibration / shock IEC 61131-2
Source LS Electric XGT Series catalog (2026-07), p. 17, 23, 148, 150
XGB-M04A Base type: Main base | I/O slots: 4 | Overall width: 210 mm
XGB-M06A Base type: Main base | I/O slots: 6 | Overall width: 264 mm
XGB-M08A Base type: Main base | I/O slots: 8 | Overall width: 318 mm
XGB-M10A Base type: Main base | I/O slots: 10 | Overall width: 375 mm
XGB-M12A Base type: Main base | I/O slots: 12 | Overall width: 426 mm
XGB-E04A Base type: Expansion base | I/O slots: 4 | Overall width: 210 mm
XGB-E06A Base type: Expansion base | I/O slots: 6 | Overall width: 264 mm
XGB-E08A Base type: Expansion base | I/O slots: 8 | Overall width: 318 mm
XGB-E12A Base type: Expansion base | I/O slots: 12 | Overall width: 426 mm
PLC AccessoriesLS Electric
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric XGT XGB Main and Expansion Bases (4 to 12 Slots)

Brand LS Electric·PLC Accessories

Available part numbers (9)

XGB-M04A, XGB-M06A, XGB-M08A, XGB-M10A, XGB-M12A, XGB-E04A, XGB-E06A, XGB-E08A, XGB-E12A

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
