NSK Grease Unit: GRS Grease Tubes, HGP Hand Pump and Nozzles

NSK Grease Unit: GRS Grease Tubes, HGP Hand Pump and Nozzles

The NSK Grease Unit combines NSK greases in 80 g bellows tubes with a one-hand grease pump and interchangeable nozzles for re-lubricating NSK linear guides and ball screws.

Key features

  • Six NSK greases in colour-coded 80 g bellows tubes
  • Hand pump operable with one hand, delivers at 15 MPa
  • Does not leak when held upside down; remaining grease visible through a slit
  • Grease tube attaches directly to the pump
  • Straight, chuck, drive-fitting, point and flexible nozzles plus extension pipes

Specifications

Grease tube content 80 g
Pump discharge pressure 15 MPa
Standard nozzle NSK HGP NZ1 (supplied with pump)
Brand NSK
Product type Lubricators
Source NSK Linear Guides / Ball Screws / Monocarriers catalogue (Precision Machine Components), p. D13-D20
NSK GRS AS2 Item: Grease AS2 (brown), 80 g tube | Base oil: mineral | Temp: -10 to 110 C
NSK GRS PS2 Item: Grease PS2 (orange), 80 g tube | Base oil: synthetic+mineral | Temp: -50 to 110 C
NSK GRS LR3 Item: Grease LR3 (green), 80 g tube | Base oil: synthetic | Temp: -30 to 130 C
NSK GRS LG2 Item: Grease LG2 (blue), 80 g tube | Base oil: mineral+synthetic HC | Temp: -20 to 70 C
NSK GRS LGU Item: Grease LGU (yellow), 80 g tube | Base oil: synthetic HC | Temp: -30 to 120 C
NSK GRS NF2 Item: Grease NF2 (gray), 80 g tube | Base oil: synthetic+mineral | Temp: -40 to 100 C
NSK HGP Item: Hand grease pump unit | Includes: straight nozzle NZ1 | Pressure: 15 MPa
NSK HGP NZ1 Item: Grease nozzle | Type: straight nozzle
NSK HGP NZ2 Item: Grease nozzle | Type: chuck nozzle
NSK HGP NZ3 Item: Grease nozzle | Type: drive fitting nozzle
NSK HGP NZ4 Item: Grease nozzle | Type: point nozzle
NSK HGP NZ5 Item: Grease nozzle | Type: flexible nozzle
NSK HGP NZ6 Item: Grease nozzle | Type: flexible extension pipe
NSK HGP NZ7 Item: Grease nozzle | Type: straight extension pipe
LubricatorsNSK
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

NSK Grease Unit: GRS Grease Tubes, HGP Hand Pump and Nozzles

Brand NSK·Lubricators

Available part numbers (14)

NSK GRS AS2, NSK GRS PS2, NSK GRS LR3, NSK GRS LG2, NSK GRS LGU, NSK GRS NF2, NSK HGP, NSK HGP NZ1, NSK HGP NZ2, NSK HGP NZ3 + 4 more — see full table ↓

How to order

Send the NSK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
NSK GRS AS2Item: Grease AS2 (brown), 80 g tube | Base oil: mineral | Temp: -10 to 110 C
NSK GRS PS2Item: Grease PS2 (orange), 80 g tube | Base oil: synthetic+mineral | Temp: -50 to 110 C
NSK GRS LR3Item: Grease LR3 (green), 80 g tube | Base oil: synthetic | Temp: -30 to 130 C
NSK GRS LG2Item: Grease LG2 (blue), 80 g tube | Base oil: mineral+synthetic HC | Temp: -20 to 70 C
NSK GRS LGUItem: Grease LGU (yellow), 80 g tube | Base oil: synthetic HC | Temp: -30 to 120 C
NSK GRS NF2Item: Grease NF2 (gray), 80 g tube | Base oil: synthetic+mineral | Temp: -40 to 100 C
NSK HGPItem: Hand grease pump unit | Includes: straight nozzle NZ1 | Pressure: 15 MPa
NSK HGP NZ1Item: Grease nozzle | Type: straight nozzle
NSK HGP NZ2Item: Grease nozzle | Type: chuck nozzle
NSK HGP NZ3Item: Grease nozzle | Type: drive fitting nozzle
NSK HGP NZ4Item: Grease nozzle | Type: point nozzle
NSK HGP NZ5Item: Grease nozzle | Type: flexible nozzle
NSK HGP NZ6Item: Grease nozzle | Type: flexible extension pipe
NSK HGP NZ7Item: Grease nozzle | Type: straight extension pipe

Need a different model, or a part not listed here? Send us your parts list →
