Sanyo Denki San Ace 60 DC Axial Fan 60x60x25 mm (San Cooler)

Sanyo Denki San Ace 60 DC Axial Fan 60x60x25 mm (San Cooler)

The San Ace 60 San Cooler is a DC axial cooling fan in a 60x60x25 mm frame.

Key features

  • Models are offered for 12 and 24 V DC rated voltage
  • Rated speeds range from 2,600 to 5,600 min-1 with maximum air flow up to 0.78 m3/min and maximum static pressure up to 87.3 Pa
  • The frame is made of plastic
  • Expected life is rated as L10 (90% survival) at 60°C, rated voltage, continuous operation in free air

Specifications

Size 60x60x25 mm
Mass 80 g
9A0612G401 Size: 60x60x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.2 V | Rated current: 0.24 A | Rated input: 2.88 W | Speed: 5,600 min-1 | Max air flow: 0.78 m3/min (27.6 CFM) | Max static pressure: 87.3 Pa (0.351 inchH2O) | Noise: 39 dB(A) | Operating temperature: -10 to +60 °C | Expected life: 30,000 h | Mass: 80 g
9A0612S401 Size: 60x60x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.17 A | Rated input: 2.04 W | Speed: 4,600 min-1 | Max air flow: 0.65 m3/min (23.0 CFM) | Max static pressure: 56.8 Pa (0.228 inchH2O) | Noise: 33 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0612H401 Size: 60x60x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.11 A | Rated input: 1.32 W | Speed: 3,800 min-1 | Max air flow: 0.53 m3/min (18.7 CFM) | Max static pressure: 40.2 Pa (0.161 inchH2O) | Noise: 28 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0612F401 Size: 60x60x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.09 A | Rated input: 1.08 W | Speed: 3,200 min-1 | Max air flow: 0.44 m3/min (15.5 CFM) | Max static pressure: 29.4 Pa (0.118 inchH2O) | Noise: 24 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0612M401 Size: 60x60x25 mm | Rated voltage: 12 V | Operating voltage range: 7 to 13.8 V | Rated current: 0.06 A | Rated input: 0.72 W | Speed: 2,600 min-1 | Max air flow: 0.36 m3/min (12.7 CFM) | Max static pressure: 19.6 Pa (0.079 inchH2O) | Noise: 20 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0624G401 Size: 60x60x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.13 A | Rated input: 3.12 W | Speed: 5,600 min-1 | Max air flow: 0.78 m3/min (27.6 CFM) | Max static pressure: 87.3 Pa (0.351 inchH2O) | Noise: 39 dB(A) | Operating temperature: -10 to +60 °C | Expected life: 30,000 h | Mass: 80 g
9A0624S401 Size: 60x60x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.08 A | Rated input: 1.92 W | Speed: 4,600 min-1 | Max air flow: 0.65 m3/min (23.0 CFM) | Max static pressure: 56.8 Pa (0.228 inchH2O) | Noise: 33 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0624H401 Size: 60x60x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.06 A | Rated input: 1.44 W | Speed: 3,800 min-1 | Max air flow: 0.53 m3/min (18.7 CFM) | Max static pressure: 40.2 Pa (0.161 inchH2O) | Noise: 28 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0624F401 Size: 60x60x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.05 A | Rated input: 1.2 W | Speed: 3,200 min-1 | Max air flow: 0.44 m3/min (15.5 CFM) | Max static pressure: 29.4 Pa (0.118 inchH2O) | Noise: 24 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0624M401 Size: 60x60x25 mm | Rated voltage: 24 V | Operating voltage range: 14 to 27.6 V | Rated current: 0.04 A | Rated input: 0.96 W | Speed: 2,600 min-1 | Max air flow: 0.36 m3/min (12.7 CFM) | Max static pressure: 19.6 Pa (0.079 inchH2O) | Noise: 20 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
DC Axial FansSanyo Denki
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 60 DC Axial Fan 60x60x25 mm (San Cooler)

Brand Sanyo Denki·DC Axial Fans

Available part numbers (10)

9A0612G401, 9A0612S401, 9A0612H401, 9A0612F401, 9A0612M401, 9A0624G401, 9A0624S401, 9A0624H401, 9A0624F401, 9A0624M401

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9A0612G401Size: 60x60x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.2 V | Rated current: 0.24 A | Rated input: 2.88 W | Speed: 5,600 min-1 | Max air flow: 0.78 m3/min (27.6 CFM) | Max static pressure: 87.3 Pa (0.351 inchH2O) | Noise: 39 dB(A) | Operating temperature: -10 to +60 °C | Expected life: 30,000 h | Mass: 80 g
9A0612S401Size: 60x60x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.17 A | Rated input: 2.04 W | Speed: 4,600 min-1 | Max air flow: 0.65 m3/min (23.0 CFM) | Max static pressure: 56.8 Pa (0.228 inchH2O) | Noise: 33 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0612H401Size: 60x60x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.11 A | Rated input: 1.32 W | Speed: 3,800 min-1 | Max air flow: 0.53 m3/min (18.7 CFM) | Max static pressure: 40.2 Pa (0.161 inchH2O) | Noise: 28 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0612F401Size: 60x60x25 mm | Rated voltage: 12 V | Operating voltage range: 6 to 13.8 V | Rated current: 0.09 A | Rated input: 1.08 W | Speed: 3,200 min-1 | Max air flow: 0.44 m3/min (15.5 CFM) | Max static pressure: 29.4 Pa (0.118 inchH2O) | Noise: 24 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0612M401Size: 60x60x25 mm | Rated voltage: 12 V | Operating voltage range: 7 to 13.8 V | Rated current: 0.06 A | Rated input: 0.72 W | Speed: 2,600 min-1 | Max air flow: 0.36 m3/min (12.7 CFM) | Max static pressure: 19.6 Pa (0.079 inchH2O) | Noise: 20 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0624G401Size: 60x60x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.13 A | Rated input: 3.12 W | Speed: 5,600 min-1 | Max air flow: 0.78 m3/min (27.6 CFM) | Max static pressure: 87.3 Pa (0.351 inchH2O) | Noise: 39 dB(A) | Operating temperature: -10 to +60 °C | Expected life: 30,000 h | Mass: 80 g
9A0624S401Size: 60x60x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.08 A | Rated input: 1.92 W | Speed: 4,600 min-1 | Max air flow: 0.65 m3/min (23.0 CFM) | Max static pressure: 56.8 Pa (0.228 inchH2O) | Noise: 33 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0624H401Size: 60x60x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.06 A | Rated input: 1.44 W | Speed: 3,800 min-1 | Max air flow: 0.53 m3/min (18.7 CFM) | Max static pressure: 40.2 Pa (0.161 inchH2O) | Noise: 28 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0624F401Size: 60x60x25 mm | Rated voltage: 24 V | Operating voltage range: 12 to 27.6 V | Rated current: 0.05 A | Rated input: 1.2 W | Speed: 3,200 min-1 | Max air flow: 0.44 m3/min (15.5 CFM) | Max static pressure: 29.4 Pa (0.118 inchH2O) | Noise: 24 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
9A0624M401Size: 60x60x25 mm | Rated voltage: 24 V | Operating voltage range: 14 to 27.6 V | Rated current: 0.04 A | Rated input: 0.96 W | Speed: 2,600 min-1 | Max air flow: 0.36 m3/min (12.7 CFM) | Max static pressure: 19.6 Pa (0.079 inchH2O) | Noise: 20 dB(A) | Operating temperature: -10 to +70 °C | Expected life: 40,000 h | Mass: 80 g
