SMC AC20D-D F.R. Clean Combination (Filter Regulator + Mist Separator)

SMC AC20D-D F.R. Clean Combination (Filter Regulator + Mist Separator)

SMC modular F.R.L. combination for compressed air preparation.

Key features

  • Body size 20, port size: 1/8, 1/4
  • Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm)
  • Setting pressure: 0.05–0.85 MPa (low-pressure 0.02–0.2 MPa available on request)
  • Max working pressure 1.0 MPa, proof pressure 1.5 MPa
  • Operating temperature: -5 to 60°C
  • Threads: Rc / NPT / G

Specifications

Body size 20
Combination type AC-D
Constituent units AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm)
Setting pressure 0.05–0.85 MPa
Max working pressure 1.0 MPa
Proof pressure 1.5 MPa
Operating temperature -5 to 60°C
Spec Clean/Low-particle (-D)
AC20D-01-D Rc 1/8, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-01E-D Rc 1/8, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-01C-D Rc 1/8, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-01CE-D Rc 1/8, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-02-D Rc 1/4, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-02E-D Rc 1/4, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-02C-D Rc 1/4, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-02CE-D Rc 1/4, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N01-D NPT 1/8, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N01E-D NPT 1/8, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N01C-D NPT 1/8, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N01CE-D NPT 1/8, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N02-D NPT 1/4, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N02E-D NPT 1/4, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N02C-D NPT 1/4, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N02CE-D NPT 1/4, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F01-D G 1/8, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F01E-D G 1/8, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F01C-D G 1/8, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F01CE-D G 1/8, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F02-D G 1/4, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F02E-D G 1/4, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F02C-D G 1/4, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F02CE-D G 1/4, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
FRL CombinationsSMC
24 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AC20D-D F.R. Clean Combination (Filter Regulator + Mist Separator)

Brand SMC·FRL Combinations

Available part numbers (24)

AC20D-01-D, AC20D-01E-D, AC20D-01C-D, AC20D-01CE-D, AC20D-02-D, AC20D-02E-D, AC20D-02C-D, AC20D-02CE-D, AC20D-N01-D, AC20D-N01E-D + 14 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AC20D-01-DRc 1/8, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-01E-DRc 1/8, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-01C-DRc 1/8, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-01CE-DRc 1/8, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-02-DRc 1/4, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-02E-DRc 1/4, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-02C-DRc 1/4, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-02CE-DRc 1/4, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: Rc | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N01-DNPT 1/8, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N01E-DNPT 1/8, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N01C-DNPT 1/8, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N01CE-DNPT 1/8, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N02-DNPT 1/4, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N02E-DNPT 1/4, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N02C-DNPT 1/4, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-N02CE-DNPT 1/4, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: NPT | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F01-DG 1/8, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F01E-DG 1/8, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/8 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F01C-DG 1/8, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F01CE-DG 1/8, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/8 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F02-DG 1/4, Manual drain | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F02E-DG 1/4, Manual drain, Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/4 | Auto drain: Manual drain | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F02C-DG 1/4, Auto drain N.C. | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
AC20D-F02CE-DG 1/4, Auto drain N.C., Square embedded gauge | Body size: 20 | Combination type: AC-D | Constituent units: AW (filter regulator with 5μm filter) + AFM (mist separator, 0.3μm) | Thread: G | Port size: 1/4 | Auto drain: Auto drain N.C. | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Spec: Clean/Low-particle (-D)
