SMC AR50K-D Modular Regulator (Reverse Flow)

SMC AR50K-D Modular Regulator (Reverse Flow)

SMC modular pneumatic regulator (clean/low-particle spec).

Key features

  • Body size 50, port size: 3/4, 1
  • Setting pressure 0.05–0.85 MPa, max working pressure 1.0 MPa
  • Mass: 1.13 kg
  • Threads: Rc / NPT / G
  • Options: bracket, square embedded gauge, round gauge
  • Other options (set nut H, light-angle gauge J, color zone M, digital pressure switch E1–E4, low-pressure spec, non-relief, reverse flow direction, psi units) available on request

Specifications

Body size 50
Reverse flow Yes
Setting pressure 0.05–0.85 MPa
Max working pressure 1.0 MPa
Construction Relief type
Spec Clean/Low-particle (-D)
AR50K-06-D Reverse flow, Rc 3/4, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-06E-D Reverse flow, Rc 3/4, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-06G-D Reverse flow, Rc 3/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-06B-D Reverse flow, Rc 3/4, Bracket, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-06BE-D Reverse flow, Rc 3/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-06BG-D Reverse flow, Rc 3/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10-D Reverse flow, Rc 1, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10E-D Reverse flow, Rc 1, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10G-D Reverse flow, Rc 1, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10B-D Reverse flow, Rc 1, Bracket, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10BE-D Reverse flow, Rc 1, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10BG-D Reverse flow, Rc 1, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06-D Reverse flow, NPT 3/4, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06E-D Reverse flow, NPT 3/4, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06G-D Reverse flow, NPT 3/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06B-D Reverse flow, NPT 3/4, Bracket, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06BE-D Reverse flow, NPT 3/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06BG-D Reverse flow, NPT 3/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10-D Reverse flow, NPT 1, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10E-D Reverse flow, NPT 1, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10G-D Reverse flow, NPT 1, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10B-D Reverse flow, NPT 1, Bracket, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10BE-D Reverse flow, NPT 1, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10BG-D Reverse flow, NPT 1, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06-D Reverse flow, G 3/4, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06E-D Reverse flow, G 3/4, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06G-D Reverse flow, G 3/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06B-D Reverse flow, G 3/4, Bracket, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06BE-D Reverse flow, G 3/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06BG-D Reverse flow, G 3/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10-D Reverse flow, G 1, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10E-D Reverse flow, G 1, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10G-D Reverse flow, G 1, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10B-D Reverse flow, G 1, Bracket, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10BE-D Reverse flow, G 1, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10BG-D Reverse flow, G 1, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
RegulatorsSMC
36 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC AR50K-D Modular Regulator (Reverse Flow)

Brand SMC·Regulators

Available part numbers (36)

AR50K-06-D, AR50K-06E-D, AR50K-06G-D, AR50K-06B-D, AR50K-06BE-D, AR50K-06BG-D, AR50K-10-D, AR50K-10E-D, AR50K-10G-D, AR50K-10B-D + 26 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AR50K-06-DReverse flow, Rc 3/4, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-06E-DReverse flow, Rc 3/4, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-06G-DReverse flow, Rc 3/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-06B-DReverse flow, Rc 3/4, Bracket, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-06BE-DReverse flow, Rc 3/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-06BG-DReverse flow, Rc 3/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10-DReverse flow, Rc 1, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10E-DReverse flow, Rc 1, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10G-DReverse flow, Rc 1, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10B-DReverse flow, Rc 1, Bracket, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10BE-DReverse flow, Rc 1, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-10BG-DReverse flow, Rc 1, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: Rc | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06-DReverse flow, NPT 3/4, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06E-DReverse flow, NPT 3/4, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06G-DReverse flow, NPT 3/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06B-DReverse flow, NPT 3/4, Bracket, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06BE-DReverse flow, NPT 3/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N06BG-DReverse flow, NPT 3/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10-DReverse flow, NPT 1, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10E-DReverse flow, NPT 1, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10G-DReverse flow, NPT 1, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10B-DReverse flow, NPT 1, Bracket, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10BE-DReverse flow, NPT 1, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-N10BG-DReverse flow, NPT 1, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: NPT | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06-DReverse flow, G 3/4, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06E-DReverse flow, G 3/4, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06G-DReverse flow, G 3/4, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06B-DReverse flow, G 3/4, Bracket, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06BE-DReverse flow, G 3/4, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F06BG-DReverse flow, G 3/4, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 3/4 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10-DReverse flow, G 1, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10E-DReverse flow, G 1, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10G-DReverse flow, G 1, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: No mounting option | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10B-DReverse flow, G 1, Bracket, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: No pressure gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10BE-DReverse flow, G 1, Bracket, Square embedded gauge, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Square embedded gauge | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
AR50K-F10BG-DReverse flow, G 1, Bracket, Round gauge with limit indicator, clean/low-particle spec | Body size: 50 | Thread: G | Port size: 1 | Reverse flow: Yes | Mounting: Bracket | Pressure gauge: Round gauge with limit indicator | Setting pressure: 0.05–0.85 MPa | Max working pressure: 1.0 MPa | Construction: Relief type | Spec: Clean/Low-particle (-D)
