SPG PC FA Output Flanges for Worm Reducers (Frame 025-150)

SPG PC FA Output Flanges for Worm Reducers (Frame 025-150)

SPG FA output flanges bolt to the output side of PC series worm reducers (PCMRV / PCRV) to allow flange mounting of the reducer to the driven machine.

Key features

  • Output-side mounting flange for PC worm reducers
  • Sizes for every PC frame from 025 to 150
  • Supplied separately, not assembled to the reducer
  • Aluminium flange matching the reducer housing

Specifications

Flange type FA output flange
For SPG PC series worm reducers (PCMRV, PCRV)
Frames 025, 030, 040, 050, 063, 075, 090, 110, 130, 150
Delivery Ordered separately
Mounting Bolted to reducer output face
Source SPG PC Series Industrial Worm Reducer catalogue, p. 8-19
PC025-FA Reducer frame: PC025 | Output bore: Ø11H7 | Flange weight: 0.1 kg
PC030-FA Reducer frame: PC030 | Output bore: Ø14H7 | Flange weight: 0.13 kg
PC040-FA Reducer frame: PC040 | Output bore: Ø18H7 | Flange weight: 0.25 kg
PC050-FA Reducer frame: PC050 | Output bore: Ø25H7 | Flange weight: 0.32 kg
PC063-FA Reducer frame: PC063 | Output bore: Ø25H7 | Flange weight: 0.39 kg
PC075-FA Reducer frame: PC075 | Output bore: Ø28H7 | Flange weight: 0.70 kg
PC090-FA Reducer frame: PC090 | Output bore: Ø35H7 | Flange weight: 0.85 kg
PC110-FA Reducer frame: PC110 | Output bore: Ø42H7 | Flange weight: 6.0 kg
PC130-FA Reducer frame: PC130 | Output bore: Ø45H7 | Flange weight: 8.0 kg
PC150-FA Reducer frame: PC150 | Output bore: Ø50H7 | Flange weight: 8.0 kg
Gearbox AccessoriesSPG
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SPG PC FA Output Flanges for Worm Reducers (Frame 025-150)

Brand SPG·Gearbox Accessories

Available part numbers (10)

PC025-FA, PC030-FA, PC040-FA, PC050-FA, PC063-FA, PC075-FA, PC090-FA, PC110-FA, PC130-FA, PC150-FA

How to order

Send the SPG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
