Woonyoung WYZS Busbar-Type Zero-Phase Current Transformer for MCCB, 200 mA / 100 mV

Busbar-type zero-phase current transformer (200 mA / 100 mV) that mounts directly on MCCB bus terminals (25-35 mm bus size), in 1P2W, 3P3W and 3P4W versions.

Key features

Primary conductor passes through the core; detects zero-sequence (earth leakage) current
Silicon steel core with good permeability for precise output characteristics
Self-extinguishing ABS flame-retardant resin case (ABS and PC)
Lightweight construction without internal filler
Terminal cover for safety
KC and CE marked

Specifications

Operating temperature	-10 to +60 C
Insulation resistance	Secondary-earth DC 500 V megger, 100 MOhm or more
Impulse withstand	Secondary-earth 6 kV (1.2/50 us), +/- 1 time
Rated output	Primary 200 mA, secondary 100 mV (with 2 kOhm)
Output conditions	200 mA/100 mV (2 kOhm), 500 mA/100 mV (300 Ohm), 1000 mA/100 mV (120 Ohm)
Accuracy	75-125% (primary current)
Dielectric withstand	Secondary-earth AC 1,500 V / 1 min
Certificate	KC (WYZR-030~200, WYZS-160~260, WYZS-160A~260A)
Application	Earth leakage alarm (ELD) / ground fault relay (GFR)
Construction	Busbar type for MCCB

WYZS-102		Wiring: 1P2W \| MCCB bus size: 30 mm \| Rated current: 125 A \| Busbar: 3t x 15 mm \| Weight: 0.2 kg
WYZS-103		Wiring: 3P3W \| MCCB bus size: 30 mm \| Rated current: 125 A \| Busbar: 3t x 15 mm \| Weight: 0.2 kg
WYZS-104		Wiring: 3P4W \| MCCB bus size: 30 mm \| Rated current: 125 A \| Busbar: 3t x 15 mm \| Weight: 0.4 kg
WYZS-054A		Wiring: 3P4W \| MCCB bus size: 25 mm \| Rated current: 50 A \| Busbar: 3t x 15 mm \| Weight: 0.4 kg
WYZS-104A		Wiring: 3P4W \| MCCB bus size: 25 mm \| Rated current: 100 A \| Busbar: 3t x 15 mm \| Weight: 0.4 kg
WYZS-223		Wiring: 3P3W \| MCCB bus size: 35 mm \| Rated current: 250 A \| Busbar: 5t x 20 mm \| Weight: 0.5 kg
WYZS-224		Wiring: 3P4W \| MCCB bus size: 35 mm \| Rated current: 250 A \| Busbar: 5t x 20 mm \| Weight: 0.6 kg

Zero-Phase Current TransformersWoonyoung

7 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Woonyoung WYZS Busbar-Type Zero-Phase Current Transformer for MCCB, 200 mA / 100 mV

Brand Woonyoung·Zero-Phase Current Transformers

Available part numbers (7)

WYZS-102, WYZS-103, WYZS-104, WYZS-054A, WYZS-104A, WYZS-223, WYZS-224

How to order

Send the Woonyoung part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	WYZS-102	Wiring: 1P2W \| MCCB bus size: 30 mm \| Rated current: 125 A \| Busbar: 3t x 15 mm \| Weight: 0.2 kg
	WYZS-103	Wiring: 3P3W \| MCCB bus size: 30 mm \| Rated current: 125 A \| Busbar: 3t x 15 mm \| Weight: 0.2 kg
	WYZS-104	Wiring: 3P4W \| MCCB bus size: 30 mm \| Rated current: 125 A \| Busbar: 3t x 15 mm \| Weight: 0.4 kg
	WYZS-054A	Wiring: 3P4W \| MCCB bus size: 25 mm \| Rated current: 50 A \| Busbar: 3t x 15 mm \| Weight: 0.4 kg
	WYZS-104A	Wiring: 3P4W \| MCCB bus size: 25 mm \| Rated current: 100 A \| Busbar: 3t x 15 mm \| Weight: 0.4 kg
	WYZS-223	Wiring: 3P3W \| MCCB bus size: 35 mm \| Rated current: 250 A \| Busbar: 5t x 20 mm \| Weight: 0.5 kg
	WYZS-224	Wiring: 3P4W \| MCCB bus size: 35 mm \| Rated current: 250 A \| Busbar: 5t x 20 mm \| Weight: 0.6 kg
