• Worldweld 300PW Inverter Plasma Arc Welder (300A)
1 1

Worldweld 300PW Inverter Plasma Arc Welder (300A)

Worldweld 300PW Inverter Plasma Arc Welder (300A)

The 300PW is an inverter plasma arc welding power source.

Key features

  • It delivers 5 to 300 A at 100% duty cycle from 220V three-phase power
  • Pilot gas and shielding gas flows are adjustable over 0.3-3 L/min and 2-20 L/min

Specifications

Input voltage 220V 3-phase
Input capacity 11.1kVA
Output current 5~300A
Pilot gas 0.3~3L/min
Shielding gas 2~20L/min
Rated duty cycle 100%
Dimensions (WxDxH) 420 x 800 x 710mm
Weight 50kg
300PW Input voltage: 220V 3-phase | Input capacity: 11.1kVA | Output current: 5~300A | Pilot gas: 0.3~3L/min | Shielding gas: 2~20L/min | Rated duty cycle: 100% | Dimensions (WxDxH): 420 x 800 x 710mm | Weight: 50kg
Plasma WeldersWorldweld
1 product code available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Worldweld 300PW Inverter Plasma Arc Welder (300A)

Brand Worldweld·Plasma Welders

Available part numbers (1)

300PW

How to order

Send the Worldweld part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
300PWInput voltage: 220V 3-phase | Input capacity: 11.1kVA | Output current: 5~300A | Pilot gas: 0.3~3L/min | Shielding gas: 2~20L/min | Rated duty cycle: 100% | Dimensions (WxDxH): 420 x 800 x 710mm | Weight: 50kg
