Yuken - CJT210 21MPa Hydraulic Cylinder (TC Trunnion)

Yuken - CJT210 21MPa Hydraulic Cylinder (TC Trunnion)

YUKEN CJT210 Series 21 MPa standard hydraulic cylinder.

Key features

  • Used for a wide range of applications including machine tools and general industrial machinery, realizing high-pressure operation at a nominal pressure of 21 MPa
  • Bore sizes 40-160 mm, B-series rod
  • TC Trunnion support
  • Conforms to former JIS B8354
  • Stroke is made-to-order - specify the required stroke

Specifications

Series CJT210 (21 MPa standard hydraulic cylinder)
Nominal Pressure 21 MPa
Max Allowable Pressure Cap side 24.5 MPa / Rod side 26.5 MPa
Proof Pressure 31.5 MPa
Support TC - Intermediate fixed trunnion
Design No. 30
Max Stroke 2000 mm
Stroke Made-to-order (specify required stroke)
Cushion B: both ends / R: rod side / H: cap side / N: none
Port Direction A: top (std) / B: right / C: bottom / D: left (viewed from rod side)
Cushion Valve Direction B: right (std) / A: top / C: bottom / D: left / N: none
Air Bleed Direction D: left (std) / A: top / B: right / C: bottom
CJT210-TC-63-B-30 CJT210 21MPa Hydraulic Cylinder, TC support, 63mm bore, B-rod d36mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 63 mm | Rod: B-series d36 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 15 mm | Full Code: [F/6]CJT210-TC-63B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CJT210-TC-80-B-30 CJT210 21MPa Hydraulic Cylinder, TC support, 80mm bore, B-rod d45mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 80 mm | Rod: B-series d45 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 31 mm | Full Code: [F/6]CJT210-TC-80B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CJT210-TC-100-B-30 CJT210 21MPa Hydraulic Cylinder, TC support, 100mm bore, B-rod d56mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 100 mm | Rod: B-series d56 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 39 mm | Full Code: [F/6]CJT210-TC-100B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CJT210-TC-125-B-30 CJT210 21MPa Hydraulic Cylinder, TC support, 125mm bore, B-rod d70mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 125 mm | Rod: B-series d70 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 34 mm | Full Code: [F/6]CJT210-TC-125B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CJT210-TC-140-B-30 CJT210 21MPa Hydraulic Cylinder, TC support, 140mm bore, B-rod d80mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 140 mm | Rod: B-series d80 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 32 mm | Full Code: [F/6]CJT210-TC-140B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CJT210-TC-160-B-30 CJT210 21MPa Hydraulic Cylinder, TC support, 160mm bore, B-rod d90mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 160 mm | Rod: B-series d90 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 54 mm | Full Code: [F/6]CJT210-TC-160B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CylindersYuken
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken - CJT210 21MPa Hydraulic Cylinder (TC Trunnion)

Brand Yuken·Cylinders

Available part numbers (6)

CJT210-TC-63-B-30, CJT210-TC-80-B-30, CJT210-TC-100-B-30, CJT210-TC-125-B-30, CJT210-TC-140-B-30, CJT210-TC-160-B-30

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CJT210-TC-63-B-30CJT210 21MPa Hydraulic Cylinder, TC support, 63mm bore, B-rod d36mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 63 mm | Rod: B-series d36 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 15 mm | Full Code: [F/6]CJT210-TC-63B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CJT210-TC-80-B-30CJT210 21MPa Hydraulic Cylinder, TC support, 80mm bore, B-rod d45mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 80 mm | Rod: B-series d45 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 31 mm | Full Code: [F/6]CJT210-TC-80B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CJT210-TC-100-B-30CJT210 21MPa Hydraulic Cylinder, TC support, 100mm bore, B-rod d56mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 100 mm | Rod: B-series d56 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 39 mm | Full Code: [F/6]CJT210-TC-100B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CJT210-TC-125-B-30CJT210 21MPa Hydraulic Cylinder, TC support, 125mm bore, B-rod d70mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 125 mm | Rod: B-series d70 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 34 mm | Full Code: [F/6]CJT210-TC-125B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CJT210-TC-140-B-30CJT210 21MPa Hydraulic Cylinder, TC support, 140mm bore, B-rod d80mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 140 mm | Rod: B-series d80 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 32 mm | Full Code: [F/6]CJT210-TC-140B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
CJT210-TC-160-B-30CJT210 21MPa Hydraulic Cylinder, TC support, 160mm bore, B-rod d90mm, design 30 | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: TC - Intermediate fixed trunnion | Bore: 160 mm | Rod: B-series d90 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | TC Min Stroke: 54 mm | Full Code: [F/6]CJT210-TC-160B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30
