Yuken CJT210C 21MPa Compact Hydraulic Cylinder (SD Basic, Bore 40-160mm, Rod A/B)

Yuken CJT210C 21MPa Compact Hydraulic Cylinder (SD Basic, Bore 40-160mm, Rod A/B)

YUKEN's 21 MPa Series compact type hydraulic cylinders realize a high working pressure of 21 MPa for wide use across machine tools and general industrial machinery.

Key features

  • Compared with conventional 21 MPa standard hydraulic cylinders, the external dimensions are smaller, enabling compact equipment design
  • A proximity-switch-equipped version, which mounts a slide-type proximity switch on the cylinder body for position detection, is also available as a series (see catalog page J-69)
  • Nominal pressure 21 MPa; bore 40-160 mm; mounting styles SD/LA/FA/FB/CA/TC; rod series A/B
  • This listing is the SD mounting type (Basic / Basic); rod A/B selectable

Specifications

Series CJT210C (21MPa Compact Hydraulic Cylinder)
Mounting SD — Basic / Basic
Nominal Pressure 21 MPa
Proof Pressure (cap side) 26.5 MPa
Internal/Burst Pressure 31.5 MPa
Stroke specify at order (made-to-order, within max)
Cushion B both ends / R rod side / H cap side / N none (specify)
Port direction A up(std) / B right / C down / D left
Cushion-valve direction B right(std) / A up / C down / D left
Air-bleed direction D left(std) / A up / B right / C down / N none
Options E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only)
Packing Nitrile(std) / F fluoro / 6 H-NBR
CJT210C-SD-40-A CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 40mm, rod A (dia 28mm), max stroke 1600mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 40 mm | Rod: A — A series (high-strength), dia 28 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-40-B CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 40mm, rod B (dia 22mm), max stroke 1600mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 40 mm | Rod: B — B series (standard), dia 22 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-50-A CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 50mm, rod A (dia 36mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 50 mm | Rod: A — A series (high-strength), dia 36 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-50-B CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 50mm, rod B (dia 28mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 50 mm | Rod: B — B series (standard), dia 28 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-63-A CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 63mm, rod A (dia 45mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 63 mm | Rod: A — A series (high-strength), dia 45 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-63-B CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 63mm, rod B (dia 36mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 63 mm | Rod: B — B series (standard), dia 36 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-80-A CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 80mm, rod A (dia 56mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 80 mm | Rod: A — A series (high-strength), dia 56 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-80-B CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 80mm, rod B (dia 45mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 80 mm | Rod: B — B series (standard), dia 45 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-100-A CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 100mm, rod A (dia 70mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 100 mm | Rod: A — A series (high-strength), dia 70 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-100-B CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 100mm, rod B (dia 56mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 100 mm | Rod: B — B series (standard), dia 56 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-125-A CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 125mm, rod A (dia 90mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 125 mm | Rod: A — A series (high-strength), dia 90 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-125-B CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 125mm, rod B (dia 70mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 125 mm | Rod: B — B series (standard), dia 70 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-140-A CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 140mm, rod A (dia 100mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 140 mm | Rod: A — A series (high-strength), dia 100 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-140-B CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 140mm, rod B (dia 80mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 140 mm | Rod: B — B series (standard), dia 80 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-160-A CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 160mm, rod A (dia 110mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 160 mm | Rod: A — A series (high-strength), dia 110 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-160-B CJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 160mm, rod B (dia 90mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 160 mm | Rod: B — B series (standard), dia 90 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CylindersYuken
16 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken CJT210C 21MPa Compact Hydraulic Cylinder (SD Basic, Bore 40-160mm, Rod A/B)

Brand Yuken·Cylinders

Available part numbers (16)

CJT210C-SD-40-A, CJT210C-SD-40-B, CJT210C-SD-50-A, CJT210C-SD-50-B, CJT210C-SD-63-A, CJT210C-SD-63-B, CJT210C-SD-80-A, CJT210C-SD-80-B, CJT210C-SD-100-A, CJT210C-SD-100-B + 6 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CJT210C-SD-40-ACJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 40mm, rod A (dia 28mm), max stroke 1600mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 40 mm | Rod: A — A series (high-strength), dia 28 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-40-BCJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 40mm, rod B (dia 22mm), max stroke 1600mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 40 mm | Rod: B — B series (standard), dia 22 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-50-ACJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 50mm, rod A (dia 36mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 50 mm | Rod: A — A series (high-strength), dia 36 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-50-BCJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 50mm, rod B (dia 28mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 50 mm | Rod: B — B series (standard), dia 28 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-63-ACJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 63mm, rod A (dia 45mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 63 mm | Rod: A — A series (high-strength), dia 45 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-63-BCJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 63mm, rod B (dia 36mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 63 mm | Rod: B — B series (standard), dia 36 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-80-ACJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 80mm, rod A (dia 56mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 80 mm | Rod: A — A series (high-strength), dia 56 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-80-BCJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 80mm, rod B (dia 45mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 80 mm | Rod: B — B series (standard), dia 45 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-100-ACJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 100mm, rod A (dia 70mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 100 mm | Rod: A — A series (high-strength), dia 70 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-100-BCJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 100mm, rod B (dia 56mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 100 mm | Rod: B — B series (standard), dia 56 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-125-ACJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 125mm, rod A (dia 90mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 125 mm | Rod: A — A series (high-strength), dia 90 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-125-BCJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 125mm, rod B (dia 70mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 125 mm | Rod: B — B series (standard), dia 70 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-140-ACJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 140mm, rod A (dia 100mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 140 mm | Rod: A — A series (high-strength), dia 100 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-140-BCJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 140mm, rod B (dia 80mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 140 mm | Rod: B — B series (standard), dia 80 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-160-ACJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 160mm, rod A (dia 110mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 160 mm | Rod: A — A series (high-strength), dia 110 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT210C-SD-160-BCJT210C 21MPa compact hydraulic cylinder, Basic (SD), bore 160mm, rod B (dia 90mm), max stroke 2000mm | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: SD — Basic / Basic | Bore: 160 mm | Rod: B — B series (standard), dia 90 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
