Yuken CJT70 7MPa Standard Hydraulic Cylinder (FE Rectangular flange, rod side (FE), Bore 40-250mm, Rod A/B/C)

Yuken CJT70 7MPa Standard Hydraulic Cylinder (FE Rectangular flange, rod side (FE), Bore 40-250mm, Rod A/B/C)

YUKEN's standard hydraulic cylinders are equipped with a variety of mounting styles for wide use across machine tools and general industrial machinery.

Key features

  • In particular, the cushion mechanism has been improved to provide smooth stopping characteristics even under small shocks
  • A proximity-switch-equipped standard hydraulic cylinder, which mounts a slide-type proximity switch on the cylinder body for easy position detection, is also available as a series (see catalog page J-69)
  • Rich variety of mounting styles
  • Good low-speed characteristics, enabling high-precision operation
  • Smooth cushioning effect can be obtained
  • Nominal pressure 7 MPa; bore 40-250 mm

Specifications

Series CJT70 (7 MPa Standard Hydraulic Cylinder)
Mounting FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange
Nominal Pressure 7 MPa
Proof Pressure (cap side) 9 MPa
Internal/Burst Pressure 10.5 MPa
Min Operating Pressure 0.3 MPa or less
Stroke specify at order (made-to-order, within max)
Port direction A up(std) / B right / C down / D left
Cushion-valve direction B right(std) / A up / C down / D left
Air-bleed direction D left(std) / A up / B right / C down / N none
Packing Nitrile(std) / F fluoro (also for phosphate-ester fluid)
Rod Thread JIS B0211-6g (class 2)
CJT70-FE-40-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 40mm, rod A (dia 28mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 40 mm | Rod: A — A series (ultra-high-strength), dia 28 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-40-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 40mm, rod B (dia 22mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 40 mm | Rod: B — B series (high-strength), dia 22 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-40-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 40mm, rod C (dia 18mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 40 mm | Rod: C — C series (standard), dia 18 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-50-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 50mm, rod A (dia 36mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 50 mm | Rod: A — A series (ultra-high-strength), dia 36 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-50-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 50mm, rod B (dia 28mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 50 mm | Rod: B — B series (high-strength), dia 28 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-50-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 50mm, rod C (dia 22mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 50 mm | Rod: C — C series (standard), dia 22 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-63-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 63mm, rod A (dia 45mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 63 mm | Rod: A — A series (ultra-high-strength), dia 45 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-63-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 63mm, rod B (dia 36mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 63 mm | Rod: B — B series (high-strength), dia 36 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-63-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 63mm, rod C (dia 28mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 63 mm | Rod: C — C series (standard), dia 28 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-80-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 80mm, rod A (dia 56mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 80 mm | Rod: A — A series (ultra-high-strength), dia 56 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-80-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 80mm, rod B (dia 45mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 80 mm | Rod: B — B series (high-strength), dia 45 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-80-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 80mm, rod C (dia 36mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 80 mm | Rod: C — C series (standard), dia 36 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-100-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 100mm, rod A (dia 70mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 100 mm | Rod: A — A series (ultra-high-strength), dia 70 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-100-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 100mm, rod B (dia 56mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 100 mm | Rod: B — B series (high-strength), dia 56 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-100-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 100mm, rod C (dia 45mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 100 mm | Rod: C — C series (standard), dia 45 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-125-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 125mm, rod A (dia 90mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 125 mm | Rod: A — A series (ultra-high-strength), dia 90 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-125-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 125mm, rod B (dia 70mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 125 mm | Rod: B — B series (high-strength), dia 70 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-125-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 125mm, rod C (dia 56mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 125 mm | Rod: C — C series (standard), dia 56 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-140-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 140mm, rod A (dia 100mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 140 mm | Rod: A — A series (ultra-high-strength), dia 100 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-140-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 140mm, rod B (dia 80mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 140 mm | Rod: B — B series (high-strength), dia 80 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-140-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 140mm, rod C (dia 63mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 140 mm | Rod: C — C series (standard), dia 63 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-150-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 150mm, rod A (dia 106mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 150 mm | Rod: A — A series (ultra-high-strength), dia 106 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-150-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 150mm, rod B (dia 85mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 150 mm | Rod: B — B series (high-strength), dia 85 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-150-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 150mm, rod C (dia 67mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 150 mm | Rod: C — C series (standard), dia 67 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-160-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 160mm, rod A (dia 110mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 160 mm | Rod: A — A series (ultra-high-strength), dia 110 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-160-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 160mm, rod B (dia 90mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 160 mm | Rod: B — B series (high-strength), dia 90 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-160-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 160mm, rod C (dia 70mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 160 mm | Rod: C — C series (standard), dia 70 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-180-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 180mm, rod A (dia 125mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 180 mm | Rod: A — A series (ultra-high-strength), dia 125 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-180-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 180mm, rod B (dia 100mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 180 mm | Rod: B — B series (high-strength), dia 100 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-180-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 180mm, rod C (dia 80mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 180 mm | Rod: C — C series (standard), dia 80 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-200-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 200mm, rod A (dia 140mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 200 mm | Rod: A — A series (ultra-high-strength), dia 140 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-200-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 200mm, rod B (dia 110mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 200 mm | Rod: B — B series (high-strength), dia 110 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-200-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 200mm, rod C (dia 90mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 200 mm | Rod: C — C series (standard), dia 90 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-220-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 220mm, rod A (dia 160mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 220 mm | Rod: A — A series (ultra-high-strength), dia 160 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-220-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 220mm, rod B (dia 125mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 220 mm | Rod: B — B series (high-strength), dia 125 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-220-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 220mm, rod C (dia 100mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 220 mm | Rod: C — C series (standard), dia 100 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-250-A CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 250mm, rod A (dia 180mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 250 mm | Rod: A — A series (ultra-high-strength), dia 180 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-250-B CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 250mm, rod B (dia 140mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 250 mm | Rod: B — B series (high-strength), dia 140 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-250-C CJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 250mm, rod C (dia 110mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 250 mm | Rod: C — C series (standard), dia 110 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CylindersYuken
39 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken CJT70 7MPa Standard Hydraulic Cylinder (FE Rectangular flange, rod side (FE), Bore 40-250mm, Rod A/B/C)

Brand Yuken·Cylinders

Available part numbers (39)

CJT70-FE-40-A, CJT70-FE-40-B, CJT70-FE-40-C, CJT70-FE-50-A, CJT70-FE-50-B, CJT70-FE-50-C, CJT70-FE-63-A, CJT70-FE-63-B, CJT70-FE-63-C, CJT70-FE-80-A + 29 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CJT70-FE-40-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 40mm, rod A (dia 28mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 40 mm | Rod: A — A series (ultra-high-strength), dia 28 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-40-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 40mm, rod B (dia 22mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 40 mm | Rod: B — B series (high-strength), dia 22 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-40-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 40mm, rod C (dia 18mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 40 mm | Rod: C — C series (standard), dia 18 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-50-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 50mm, rod A (dia 36mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 50 mm | Rod: A — A series (ultra-high-strength), dia 36 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-50-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 50mm, rod B (dia 28mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 50 mm | Rod: B — B series (high-strength), dia 28 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-50-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 50mm, rod C (dia 22mm), max stroke 1200mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 50 mm | Rod: C — C series (standard), dia 22 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1200 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-63-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 63mm, rod A (dia 45mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 63 mm | Rod: A — A series (ultra-high-strength), dia 45 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-63-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 63mm, rod B (dia 36mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 63 mm | Rod: B — B series (high-strength), dia 36 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-63-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 63mm, rod C (dia 28mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 63 mm | Rod: C — C series (standard), dia 28 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-80-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 80mm, rod A (dia 56mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 80 mm | Rod: A — A series (ultra-high-strength), dia 56 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-80-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 80mm, rod B (dia 45mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 80 mm | Rod: B — B series (high-strength), dia 45 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-80-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 80mm, rod C (dia 36mm), max stroke 1600mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 80 mm | Rod: C — C series (standard), dia 36 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-100-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 100mm, rod A (dia 70mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 100 mm | Rod: A — A series (ultra-high-strength), dia 70 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-100-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 100mm, rod B (dia 56mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 100 mm | Rod: B — B series (high-strength), dia 56 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-100-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 100mm, rod C (dia 45mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 100 mm | Rod: C — C series (standard), dia 45 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-125-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 125mm, rod A (dia 90mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 125 mm | Rod: A — A series (ultra-high-strength), dia 90 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-125-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 125mm, rod B (dia 70mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 125 mm | Rod: B — B series (high-strength), dia 70 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-125-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 125mm, rod C (dia 56mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 125 mm | Rod: C — C series (standard), dia 56 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-140-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 140mm, rod A (dia 100mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 140 mm | Rod: A — A series (ultra-high-strength), dia 100 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-140-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 140mm, rod B (dia 80mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 140 mm | Rod: B — B series (high-strength), dia 80 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-140-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 140mm, rod C (dia 63mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 140 mm | Rod: C — C series (standard), dia 63 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-150-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 150mm, rod A (dia 106mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 150 mm | Rod: A — A series (ultra-high-strength), dia 106 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-150-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 150mm, rod B (dia 85mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 150 mm | Rod: B — B series (high-strength), dia 85 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-150-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 150mm, rod C (dia 67mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 150 mm | Rod: C — C series (standard), dia 67 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-160-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 160mm, rod A (dia 110mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 160 mm | Rod: A — A series (ultra-high-strength), dia 110 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-160-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 160mm, rod B (dia 90mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 160 mm | Rod: B — B series (high-strength), dia 90 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-160-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 160mm, rod C (dia 70mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 160 mm | Rod: C — C series (standard), dia 70 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-180-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 180mm, rod A (dia 125mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 180 mm | Rod: A — A series (ultra-high-strength), dia 125 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-180-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 180mm, rod B (dia 100mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 180 mm | Rod: B — B series (high-strength), dia 100 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-180-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 180mm, rod C (dia 80mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 180 mm | Rod: C — C series (standard), dia 80 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-200-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 200mm, rod A (dia 140mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 200 mm | Rod: A — A series (ultra-high-strength), dia 140 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-200-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 200mm, rod B (dia 110mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 200 mm | Rod: B — B series (high-strength), dia 110 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-200-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 200mm, rod C (dia 90mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 200 mm | Rod: C — C series (standard), dia 90 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-220-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 220mm, rod A (dia 160mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 220 mm | Rod: A — A series (ultra-high-strength), dia 160 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-220-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 220mm, rod B (dia 125mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 220 mm | Rod: B — B series (high-strength), dia 125 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-220-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 220mm, rod C (dia 100mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 220 mm | Rod: C — C series (standard), dia 100 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-250-ACJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 250mm, rod A (dia 180mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 250 mm | Rod: A — A series (ultra-high-strength), dia 180 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 15 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-250-BCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 250mm, rod B (dia 140mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 250 mm | Rod: B — B series (high-strength), dia 140 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 13.5 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-FE-250-CCJT70 7 MPa standard hydraulic cylinder, Rectangular flange, rod side (FE) (FE), bore 250mm, rod C (dia 110mm), max stroke 2000mm | Series: CJT70 (7 MPa Standard Hydraulic Cylinder) | Mounting: FE — Rectangular flange, rod side (FE) / Rod-end rectangular flange | Bore: 250 mm | Rod: C — C series (standard), dia 110 mm | Nominal Pressure: 7 MPa | Proof Pressure (cap side): 9 MPa | Proof Pressure (rod side): 11 MPa | Internal/Burst Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) | Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
