Yuken CJT70 7MPa Standard Hydraulic Cylinder (TC Intermediate fixed trunnion, Bore 40-250mm, Rod A/B/C)

YUKEN's standard hydraulic cylinders are equipped with a variety of mounting styles for wide use across machine tools and general industrial machinery.

Key features

In particular, the cushion mechanism has been improved to provide smooth stopping characteristics even under small shocks
A proximity-switch-equipped standard hydraulic cylinder, which mounts a slide-type proximity switch on the cylinder body for easy position detection, is also available as a series (see catalog page J-69)
Rich variety of mounting styles
Good low-speed characteristics, enabling high-precision operation
Smooth cushioning effect can be obtained
Nominal pressure 7 MPa; bore 40-250 mm

Specifications

Series	CJT70 (7 MPa Standard Hydraulic Cylinder)
Mounting	TC — Intermediate fixed trunnion / Intermediate trunnion
Nominal Pressure	7 MPa
Proof Pressure (cap side)	9 MPa
Internal/Burst Pressure	10.5 MPa
Min Operating Pressure	0.3 MPa or less
Stroke	specify at order (made-to-order, within max)
Port direction	A up(std) / B right / C down / D left
Cushion-valve direction	B right(std) / A up / C down / D left
Air-bleed direction	D left(std) / A up / B right / C down / N none
Packing	Nitrile(std) / F fluoro (also for phosphate-ester fluid)
Rod Thread	JIS B0211-6g (class 2)

CJT70-TC-40-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 40mm, rod A (dia 28mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 40 mm \| Rod: A — A series (ultra-high-strength), dia 28 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-40-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 40mm, rod B (dia 22mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 40 mm \| Rod: B — B series (high-strength), dia 22 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-40-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 40mm, rod C (dia 18mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 40 mm \| Rod: C — C series (standard), dia 18 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-50-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 50mm, rod A (dia 36mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 50 mm \| Rod: A — A series (ultra-high-strength), dia 36 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-50-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 50mm, rod B (dia 28mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 50 mm \| Rod: B — B series (high-strength), dia 28 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-50-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 50mm, rod C (dia 22mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 50 mm \| Rod: C — C series (standard), dia 22 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-63-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 63mm, rod A (dia 45mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 63 mm \| Rod: A — A series (ultra-high-strength), dia 45 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-63-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 63mm, rod B (dia 36mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 63 mm \| Rod: B — B series (high-strength), dia 36 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-63-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 63mm, rod C (dia 28mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 63 mm \| Rod: C — C series (standard), dia 28 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-80-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 80mm, rod A (dia 56mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 80 mm \| Rod: A — A series (ultra-high-strength), dia 56 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-80-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 80mm, rod B (dia 45mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 80 mm \| Rod: B — B series (high-strength), dia 45 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-80-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 80mm, rod C (dia 36mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 80 mm \| Rod: C — C series (standard), dia 36 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-100-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 100mm, rod A (dia 70mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 100 mm \| Rod: A — A series (ultra-high-strength), dia 70 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-100-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 100mm, rod B (dia 56mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 100 mm \| Rod: B — B series (high-strength), dia 56 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-100-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 100mm, rod C (dia 45mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 100 mm \| Rod: C — C series (standard), dia 45 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-125-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 125mm, rod A (dia 90mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 125 mm \| Rod: A — A series (ultra-high-strength), dia 90 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-125-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 125mm, rod B (dia 70mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 125 mm \| Rod: B — B series (high-strength), dia 70 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-125-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 125mm, rod C (dia 56mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 125 mm \| Rod: C — C series (standard), dia 56 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-140-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 140mm, rod A (dia 100mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 140 mm \| Rod: A — A series (ultra-high-strength), dia 100 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-140-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 140mm, rod B (dia 80mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 140 mm \| Rod: B — B series (high-strength), dia 80 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-140-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 140mm, rod C (dia 63mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 140 mm \| Rod: C — C series (standard), dia 63 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-150-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 150mm, rod A (dia 106mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 150 mm \| Rod: A — A series (ultra-high-strength), dia 106 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-150-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 150mm, rod B (dia 85mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 150 mm \| Rod: B — B series (high-strength), dia 85 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-150-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 150mm, rod C (dia 67mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 150 mm \| Rod: C — C series (standard), dia 67 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-160-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 160mm, rod A (dia 110mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 160 mm \| Rod: A — A series (ultra-high-strength), dia 110 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-160-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 160mm, rod B (dia 90mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 160 mm \| Rod: B — B series (high-strength), dia 90 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-160-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 160mm, rod C (dia 70mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 160 mm \| Rod: C — C series (standard), dia 70 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-180-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 180mm, rod A (dia 125mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 180 mm \| Rod: A — A series (ultra-high-strength), dia 125 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-180-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 180mm, rod B (dia 100mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 180 mm \| Rod: B — B series (high-strength), dia 100 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-180-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 180mm, rod C (dia 80mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 180 mm \| Rod: C — C series (standard), dia 80 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-200-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 200mm, rod A (dia 140mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 200 mm \| Rod: A — A series (ultra-high-strength), dia 140 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-200-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 200mm, rod B (dia 110mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 200 mm \| Rod: B — B series (high-strength), dia 110 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-200-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 200mm, rod C (dia 90mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 200 mm \| Rod: C — C series (standard), dia 90 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-220-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 220mm, rod A (dia 160mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 220 mm \| Rod: A — A series (ultra-high-strength), dia 160 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-220-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 220mm, rod B (dia 125mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 220 mm \| Rod: B — B series (high-strength), dia 125 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-220-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 220mm, rod C (dia 100mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 220 mm \| Rod: C — C series (standard), dia 100 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-250-A		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 250mm, rod A (dia 180mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 250 mm \| Rod: A — A series (ultra-high-strength), dia 180 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-250-B		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 250mm, rod B (dia 140mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 250 mm \| Rod: B — B series (high-strength), dia 140 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
CJT70-TC-250-C		CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 250mm, rod C (dia 110mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 250 mm \| Rod: C — C series (standard), dia 110 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20

CylindersYuken

39 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken CJT70 7MPa Standard Hydraulic Cylinder (TC Intermediate fixed trunnion, Bore 40-250mm, Rod A/B/C)

Brand Yuken·Cylinders

Available part numbers (39)

CJT70-TC-40-A, CJT70-TC-40-B, CJT70-TC-40-C, CJT70-TC-50-A, CJT70-TC-50-B, CJT70-TC-50-C, CJT70-TC-63-A, CJT70-TC-63-B, CJT70-TC-63-C, CJT70-TC-80-A + 29 more — see full table ↓

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	CJT70-TC-40-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 40mm, rod A (dia 28mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 40 mm \| Rod: A — A series (ultra-high-strength), dia 28 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-40-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 40mm, rod B (dia 22mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 40 mm \| Rod: B — B series (high-strength), dia 22 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-40-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 40mm, rod C (dia 18mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 40 mm \| Rod: C — C series (standard), dia 18 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-50-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 50mm, rod A (dia 36mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 50 mm \| Rod: A — A series (ultra-high-strength), dia 36 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-50-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 50mm, rod B (dia 28mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 50 mm \| Rod: B — B series (high-strength), dia 28 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-50-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 50mm, rod C (dia 22mm), max stroke 1200mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 50 mm \| Rod: C — C series (standard), dia 22 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1200 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-63-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 63mm, rod A (dia 45mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 63 mm \| Rod: A — A series (ultra-high-strength), dia 45 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: H cap side / N none only (B both & R rod not available for bore 40/50/63 rod-A) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-63-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 63mm, rod B (dia 36mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 63 mm \| Rod: B — B series (high-strength), dia 36 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-63-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 63mm, rod C (dia 28mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 63 mm \| Rod: C — C series (standard), dia 28 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-400 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-80-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 80mm, rod A (dia 56mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 80 mm \| Rod: A — A series (ultra-high-strength), dia 56 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-80-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 80mm, rod B (dia 45mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 80 mm \| Rod: B — B series (high-strength), dia 45 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-80-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 80mm, rod C (dia 36mm), max stroke 1600mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 80 mm \| Rod: C — C series (standard), dia 36 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 1600 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-100-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 100mm, rod A (dia 70mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 100 mm \| Rod: A — A series (ultra-high-strength), dia 70 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-100-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 100mm, rod B (dia 56mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 100 mm \| Rod: B — B series (high-strength), dia 56 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-100-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 100mm, rod C (dia 45mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 100 mm \| Rod: C — C series (standard), dia 45 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-125-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 125mm, rod A (dia 90mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 125 mm \| Rod: A — A series (ultra-high-strength), dia 90 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-125-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 125mm, rod B (dia 70mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 125 mm \| Rod: B — B series (high-strength), dia 70 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-125-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 125mm, rod C (dia 56mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 125 mm \| Rod: C — C series (standard), dia 56 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-300 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-140-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 140mm, rod A (dia 100mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 140 mm \| Rod: A — A series (ultra-high-strength), dia 100 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-140-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 140mm, rod B (dia 80mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 140 mm \| Rod: B — B series (high-strength), dia 80 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-140-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 140mm, rod C (dia 63mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 140 mm \| Rod: C — C series (standard), dia 63 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-150-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 150mm, rod A (dia 106mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 150 mm \| Rod: A — A series (ultra-high-strength), dia 106 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-150-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 150mm, rod B (dia 85mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 150 mm \| Rod: B — B series (high-strength), dia 85 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-150-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 150mm, rod C (dia 67mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 150 mm \| Rod: C — C series (standard), dia 67 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-160-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 160mm, rod A (dia 110mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 160 mm \| Rod: A — A series (ultra-high-strength), dia 110 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-160-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 160mm, rod B (dia 90mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 160 mm \| Rod: B — B series (high-strength), dia 90 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-160-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 160mm, rod C (dia 70mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 160 mm \| Rod: C — C series (standard), dia 70 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-180-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 180mm, rod A (dia 125mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 180 mm \| Rod: A — A series (ultra-high-strength), dia 125 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-180-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 180mm, rod B (dia 100mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 180 mm \| Rod: B — B series (high-strength), dia 100 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-180-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 180mm, rod C (dia 80mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 180 mm \| Rod: C — C series (standard), dia 80 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-200-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 200mm, rod A (dia 140mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 200 mm \| Rod: A — A series (ultra-high-strength), dia 140 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-200-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 200mm, rod B (dia 110mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 200 mm \| Rod: B — B series (high-strength), dia 110 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-200-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 200mm, rod C (dia 90mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 200 mm \| Rod: C — C series (standard), dia 90 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-220-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 220mm, rod A (dia 160mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 220 mm \| Rod: A — A series (ultra-high-strength), dia 160 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-220-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 220mm, rod B (dia 125mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 220 mm \| Rod: B — B series (high-strength), dia 125 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-220-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 220mm, rod C (dia 100mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 220 mm \| Rod: C — C series (standard), dia 100 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-250-A	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 250mm, rod A (dia 180mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 250 mm \| Rod: A — A series (ultra-high-strength), dia 180 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 15 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-250-B	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 250mm, rod B (dia 140mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 250 mm \| Rod: B — B series (high-strength), dia 140 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 13.5 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
	CJT70-TC-250-C	CJT70 7 MPa standard hydraulic cylinder, Intermediate fixed trunnion (TC), bore 250mm, rod C (dia 110mm), max stroke 2000mm \| Series: CJT70 (7 MPa Standard Hydraulic Cylinder) \| Mounting: TC — Intermediate fixed trunnion / Intermediate trunnion \| Bore: 250 mm \| Rod: C — C series (standard), dia 110 mm \| Nominal Pressure: 7 MPa \| Proof Pressure (cap side): 9 MPa \| Proof Pressure (rod side): 11 MPa \| Internal/Burst Pressure: 10.5 MPa \| Min Operating Pressure: 0.3 MPa or less \| Operating Speed: 8-200 mm/s \| Max Stroke: 2000 mm \| Stroke: specify at order (made-to-order, within max) \| Cushion: B both ends / R rod side / H cap side / N none (specify) \| Port direction: A up(std) / B right / C down / D left \| Cushion-valve direction: B right(std) / A up / C down / D left \| Air-bleed direction: D left(std) / A up / B right / C down / N none \| Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting, N double-rod (alpha order; bore>=180 L/M consult) \| Packing: Nitrile(std) / F fluoro (also for phosphate-ester fluid) \| Rod Thread: JIS B0211-6g (class 2) \| Ambient Temp: -10 to +80 C \| Standard: former JIS B8354 \| Design No.: 20 \| Full Code: F-CJT70-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20
