Yuken - Mini Series SW-1 Hydraulic Cylinder (made-to-order / RFQ)

Yuken - Mini Series SW-1 Hydraulic Cylinder (made-to-order / RFQ)

YUKEN Mini Series hydraulic cylinder (SW-1).

Key features

  • A compact hydraulic cylinder developed for space-saving applications such as small machine tools and medical devices, where miniaturization is required
  • Offers a rich selection of support styles, and can be combined with other Mini Series components such as solenoid valves to build a mini hydraulic system
  • Detailed specifications are made-to-order - please consult Yuken

Specifications

Series Mini Series SW-1 (compact hydraulic cylinder, made-to-order)
Max Operating Pressure 3.5 MPa
Allowable Surge Pressure 5.3 MPa
Proof Pressure 5.3 MPa
Min Operating Pressure 0.3 MPa
Support (selectable) ST, LB, FA, CA, TA, TB
Max Stroke 300 mm (may be limited lower by buckling strength - consult)
Speed Range 10-300 mm/s
Ambient/Oil Temp -10 to +60 C
Rod Configuration Single / double rod available (consult)
Design No. 00
Ordering Made-to-order - consult Yuken for full configuration
SW1-20 Mini Series SW-1 hydraulic cylinder, 20mm bore, made-to-order (RFQ) | Series: Mini Series SW-1 (compact hydraulic cylinder, made-to-order) | Bore: 20 mm | Max Operating Pressure: 3.5 MPa | Allowable Surge Pressure: 5.3 MPa | Proof Pressure: 5.3 MPa | Min Operating Pressure: 0.3 MPa | Support (selectable): ST, LB, FA, CA, TA, TB | Max Stroke: 300 mm (may be limited lower by buckling strength - consult) | Speed Range: 10-300 mm/s | Ambient/Oil Temp: -10 to +60 C | Rod Configuration: Single / double rod available (consult) | Design No.: 00 | Ordering: Made-to-order - consult Yuken for full configuration | Full Code: SW-1[size]x[rod]-[support]-[stroke]-[..]-[..]-00
SW1-25 Mini Series SW-1 hydraulic cylinder, 25mm bore, made-to-order (RFQ) | Series: Mini Series SW-1 (compact hydraulic cylinder, made-to-order) | Bore: 25 mm | Max Operating Pressure: 3.5 MPa | Allowable Surge Pressure: 5.3 MPa | Proof Pressure: 5.3 MPa | Min Operating Pressure: 0.3 MPa | Support (selectable): ST, LB, FA, CA, TA, TB | Max Stroke: 300 mm (may be limited lower by buckling strength - consult) | Speed Range: 10-300 mm/s | Ambient/Oil Temp: -10 to +60 C | Rod Configuration: Single / double rod available (consult) | Design No.: 00 | Ordering: Made-to-order - consult Yuken for full configuration | Full Code: SW-1[size]x[rod]-[support]-[stroke]-[..]-[..]-00
SW1-30 Mini Series SW-1 hydraulic cylinder, 30mm bore, made-to-order (RFQ) | Series: Mini Series SW-1 (compact hydraulic cylinder, made-to-order) | Bore: 30 mm | Max Operating Pressure: 3.5 MPa | Allowable Surge Pressure: 5.3 MPa | Proof Pressure: 5.3 MPa | Min Operating Pressure: 0.3 MPa | Support (selectable): ST, LB, FA, CA, TA, TB | Max Stroke: 300 mm (may be limited lower by buckling strength - consult) | Speed Range: 10-300 mm/s | Ambient/Oil Temp: -10 to +60 C | Rod Configuration: Single / double rod available (consult) | Design No.: 00 | Ordering: Made-to-order - consult Yuken for full configuration | Full Code: SW-1[size]x[rod]-[support]-[stroke]-[..]-[..]-00
CylindersYuken
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken - Mini Series SW-1 Hydraulic Cylinder (made-to-order / RFQ)

Brand Yuken·Cylinders

Available part numbers (3)

SW1-20, SW1-25, SW1-30

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SW1-20Mini Series SW-1 hydraulic cylinder, 20mm bore, made-to-order (RFQ) | Series: Mini Series SW-1 (compact hydraulic cylinder, made-to-order) | Bore: 20 mm | Max Operating Pressure: 3.5 MPa | Allowable Surge Pressure: 5.3 MPa | Proof Pressure: 5.3 MPa | Min Operating Pressure: 0.3 MPa | Support (selectable): ST, LB, FA, CA, TA, TB | Max Stroke: 300 mm (may be limited lower by buckling strength - consult) | Speed Range: 10-300 mm/s | Ambient/Oil Temp: -10 to +60 C | Rod Configuration: Single / double rod available (consult) | Design No.: 00 | Ordering: Made-to-order - consult Yuken for full configuration | Full Code: SW-1[size]x[rod]-[support]-[stroke]-[..]-[..]-00
SW1-25Mini Series SW-1 hydraulic cylinder, 25mm bore, made-to-order (RFQ) | Series: Mini Series SW-1 (compact hydraulic cylinder, made-to-order) | Bore: 25 mm | Max Operating Pressure: 3.5 MPa | Allowable Surge Pressure: 5.3 MPa | Proof Pressure: 5.3 MPa | Min Operating Pressure: 0.3 MPa | Support (selectable): ST, LB, FA, CA, TA, TB | Max Stroke: 300 mm (may be limited lower by buckling strength - consult) | Speed Range: 10-300 mm/s | Ambient/Oil Temp: -10 to +60 C | Rod Configuration: Single / double rod available (consult) | Design No.: 00 | Ordering: Made-to-order - consult Yuken for full configuration | Full Code: SW-1[size]x[rod]-[support]-[stroke]-[..]-[..]-00
SW1-30Mini Series SW-1 hydraulic cylinder, 30mm bore, made-to-order (RFQ) | Series: Mini Series SW-1 (compact hydraulic cylinder, made-to-order) | Bore: 30 mm | Max Operating Pressure: 3.5 MPa | Allowable Surge Pressure: 5.3 MPa | Proof Pressure: 5.3 MPa | Min Operating Pressure: 0.3 MPa | Support (selectable): ST, LB, FA, CA, TA, TB | Max Stroke: 300 mm (may be limited lower by buckling strength - consult) | Speed Range: 10-300 mm/s | Ambient/Oil Temp: -10 to +60 C | Rod Configuration: Single / double rod available (consult) | Design No.: 00 | Ordering: Made-to-order - consult Yuken for full configuration | Full Code: SW-1[size]x[rod]-[support]-[stroke]-[..]-[..]-00
