Yuken Restrictor (SRT/SRG-03/06/10)

Yuken Restrictor (SRT/SRG-03/06/10)

Restrictors · One Way Restrictors.

Key features

  • Max. operating pressure: 25 MPa
  • Rated flow: 30 (03) / 85 (06) / 230 (10) L/min (at 0.3 MPa drop)
  • Threaded (T) / sub-plate (G) mounting

Specifications

Type Restrictor
Max. Operating Pressure 25 MPa
Reverse Flow Restricted (both directions)
Design No. 50
SRT-03-50 Restrictor SRT-03, Threaded | Type: Restrictor | Mounting: Threaded | Valve Size: 03 | Rated Flow: 30 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 1.5 kg | Design No.: 50
SRT-06-50 Restrictor SRT-06, Threaded | Type: Restrictor | Mounting: Threaded | Valve Size: 06 | Rated Flow: 85 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 3.8 kg | Design No.: 50
SRT-10-50 Restrictor SRT-10, Threaded | Type: Restrictor | Mounting: Threaded | Valve Size: 10 | Rated Flow: 230 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 9.1 kg | Design No.: 50
SRG-03-50 Restrictor SRG-03, Sub-plate | Type: Restrictor | Mounting: Sub-plate | Valve Size: 03 | Rated Flow: 30 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 2.5 kg | Design No.: 50
SRG-06-50 Restrictor SRG-06, Sub-plate | Type: Restrictor | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 85 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 3.9 kg | Design No.: 50
SRG-10-50 Restrictor SRG-10, Sub-plate | Type: Restrictor | Mounting: Sub-plate | Valve Size: 10 | Rated Flow: 230 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 7.5 kg | Design No.: 50
RestrictorsYuken
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Yuken Restrictor (SRT/SRG-03/06/10)

Brand Yuken·Restrictors

Available part numbers (6)

SRT-03-50, SRT-06-50, SRT-10-50, SRG-03-50, SRG-06-50, SRG-10-50

How to order

Send the Yuken part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SRT-03-50Restrictor SRT-03, Threaded | Type: Restrictor | Mounting: Threaded | Valve Size: 03 | Rated Flow: 30 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 1.5 kg | Design No.: 50
SRT-06-50Restrictor SRT-06, Threaded | Type: Restrictor | Mounting: Threaded | Valve Size: 06 | Rated Flow: 85 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 3.8 kg | Design No.: 50
SRT-10-50Restrictor SRT-10, Threaded | Type: Restrictor | Mounting: Threaded | Valve Size: 10 | Rated Flow: 230 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 9.1 kg | Design No.: 50
SRG-03-50Restrictor SRG-03, Sub-plate | Type: Restrictor | Mounting: Sub-plate | Valve Size: 03 | Rated Flow: 30 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 2.5 kg | Design No.: 50
SRG-06-50Restrictor SRG-06, Sub-plate | Type: Restrictor | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 85 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 3.9 kg | Design No.: 50
SRG-10-50Restrictor SRG-10, Sub-plate | Type: Restrictor | Mounting: Sub-plate | Valve Size: 10 | Rated Flow: 230 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Restricted (both directions) | Mass: 7.5 kg | Design No.: 50
