[GGM] — GPA Plug-in Speed Control Unit for AC Geared Motors (Built-in Setter, Electrical Brake, Single-phase)
Family ID: GGM-GPA
GGM GPA plug-in speed control unit for AC induction (6–180W), reversible (6–90W) & brake (6–180W) geared motors. Built-in speed setter with electrical brake moment-stop, 90–1700 r/min (60Hz).
12 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| GPA-U | GGM GPA-U plug-in speed control unit, single-phase AC 110/115V 50/60Hz | GGM | Input: 1-ph AC 110/115V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-J | GGM GPA-J plug-in speed control unit, single-phase AC 100V 50/60Hz | GGM | Input: 1-ph AC 100V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-C | GGM GPA-C plug-in speed control unit, single-phase AC 220/230/240V 50/60Hz | GGM | Input: 1-ph AC 220/230/240V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-L | GGM GPA-L plug-in speed control unit, single-phase AC 200V 50/60Hz | GGM | Input: 1-ph AC 200V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-U | GGM GPA-U plug-in speed control unit, single-phase AC 110/115V 50/60Hz | GGM | Input: 1-ph AC 110/115V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-J | GGM GPA-J plug-in speed control unit, single-phase AC 100V 50/60Hz | GGM | Input: 1-ph AC 100V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-C | GGM GPA-C plug-in speed control unit, single-phase AC 220/230/240V 50/60Hz | GGM | Input: 1-ph AC 220/230/240V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-L | GGM GPA-L plug-in speed control unit, single-phase AC 200V 50/60Hz | GGM | Input: 1-ph AC 200V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-U | GGM GPA-U plug-in speed control unit, single-phase AC 110/115V 50/60Hz | GGM | Input: 1-ph AC 110/115V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-J | GGM GPA-J plug-in speed control unit, single-phase AC 100V 50/60Hz | GGM | Input: 1-ph AC 100V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-C | GGM GPA-C plug-in speed control unit, single-phase AC 220/230/240V 50/60Hz | GGM | Input: 1-ph AC 220/230/240V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) | ||
| GPA-L | GGM GPA-L plug-in speed control unit, single-phase AC 200V 50/60Hz | GGM | Input: 1-ph AC 200V 50/60Hz (±10%) | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: plug-in (socket type) | Speed setter: built-in (external = special order) | Brake: electrical moment-stop, 0.5s (no retention) | Slow run/stop: none (use GSA series) |
