Speed Controllers GGM

[GGM] — GUA Volume-Type Speed Control Unit for AC Geared Motors (Single-phase)

Family ID: GGM-GUA

GGM GUA volume-type speed control unit for AC induction (6–180W) & reversible (6–90W) geared motors. One-touch motor connector, front speed dial, CW/CCW and accel/decel control; 90–1700 r/min (60Hz).

4 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code	Description	Brand	Spec
GUA-U	GGM GUA-U volume-type speed control unit, single-phase AC 110/115V 60Hz	GGM	Input: 1-ph AC 110/115V 60Hz (±10%) \| Applied motor: induction 6–180W / reversible 6–90W \| Speed range: 90–1700 r/min @60Hz \| Speed setter: volume dial \| Direction: CW/CCW \| Accel/decel: adjustable \| Connector: one-touch (motor link), extension up to 2.0m
GUA-J	GGM GUA-J volume-type speed control unit, single-phase AC 110V 50/60Hz	GGM	Input: 1-ph AC 110V 50/60Hz (±10%) \| Applied motor: induction 6–180W / reversible 6–90W \| Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz \| Speed setter: volume dial \| Direction: CW/CCW \| Accel/decel: adjustable \| Connector: one-touch (motor link), extension up to 2.0m
GUA-C	GGM GUA-C volume-type speed control unit, single-phase AC 220/230V 50/60Hz, 240V 50Hz	GGM	Input: 1-ph AC 220/230V 50/60Hz, 240V 50Hz (±10%) \| Applied motor: induction 6–180W / reversible 6–90W \| Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz \| Speed setter: volume dial \| Direction: CW/CCW \| Accel/decel: adjustable \| Connector: one-touch (motor link), extension up to 2.0m
GUA-L	GGM GUA-L volume-type speed control unit, single-phase AC 200V 50/60Hz	GGM	Input: 1-ph AC 200V 50/60Hz (±10%) \| Applied motor: induction 6–180W / reversible 6–90W \| Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz \| Speed setter: volume dial \| Direction: CW/CCW \| Accel/decel: adjustable \| Connector: one-touch (motor link), extension up to 2.0m

[GGM] — GUA Volume-Type Speed Control Unit for AC Geared Motors (Single-phase)

Product Codes & Specifications
