[GGM] — GUD Digital Speed Control Unit for AC Geared Motors (6–180W, Single-phase)
Family ID: GGM-GUD
GGM GUD digital speed control unit for AC induction & reversible geared motors, 6–180W. CW/CCW reversing, 4-step multi-speed, electromagnetic brake control via I/O port; 90–1730 r/min (60Hz).
18 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| GUD-U-6 | GGM GUD-U-6 digital speed control unit, single-phase AC 100–115V, for 6W motor | GGM | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 6W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-U-15 | GGM GUD-U-15 digital speed control unit, single-phase AC 100–115V, for 15W motor | GGM | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 15W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-U-25 | GGM GUD-U-25 digital speed control unit, single-phase AC 100–115V, for 25W motor | GGM | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 25W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-U-40 | GGM GUD-U-40 digital speed control unit, single-phase AC 100–115V, for 40W motor | GGM | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 40W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-U-60 | GGM GUD-U-60 digital speed control unit, single-phase AC 100–115V, for 60W motor | GGM | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 60W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-U-90 | GGM GUD-U-90 digital speed control unit, single-phase AC 100–115V, for 90W motor | GGM | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 90W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-U-120 | GGM GUD-U-120 digital speed control unit, single-phase AC 100–115V, for 120W motor | GGM | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 120W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-U-150 | GGM GUD-U-150 digital speed control unit, single-phase AC 100–115V, for 150W motor | GGM | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 150W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-U-180 | GGM GUD-U-180 digital speed control unit, single-phase AC 100–115V, for 180W motor | GGM | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 180W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-C-6 | GGM GUD-C-6 digital speed control unit, single-phase AC 220–240V, for 6W motor | GGM | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 6W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-C-15 | GGM GUD-C-15 digital speed control unit, single-phase AC 220–240V, for 15W motor | GGM | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 15W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-C-25 | GGM GUD-C-25 digital speed control unit, single-phase AC 220–240V, for 25W motor | GGM | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 25W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-C-40 | GGM GUD-C-40 digital speed control unit, single-phase AC 220–240V, for 40W motor | GGM | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 40W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-C-60 | GGM GUD-C-60 digital speed control unit, single-phase AC 220–240V, for 60W motor | GGM | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 60W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-C-90 | GGM GUD-C-90 digital speed control unit, single-phase AC 220–240V, for 90W motor | GGM | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 90W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-C-120 | GGM GUD-C-120 digital speed control unit, single-phase AC 220–240V, for 120W motor | GGM | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 120W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-C-150 | GGM GUD-C-150 digital speed control unit, single-phase AC 220–240V, for 150W motor | GGM | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 150W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 | ||
| GUD-C-180 | GGM GUD-C-180 digital speed control unit, single-phase AC 220–240V, for 180W motor | GGM | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 180W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20 |
