[GGM] — GSA Plug-in Speed Control Unit for AC Geared Motors (11-pin, Electrical Brake, Single-phase)
Family ID: GGM-GSA
GGM GSA 11-pin plug-in speed control unit for AC induction (6–180W), reversible (6–90W) & speed-brake (6–180W) motors. Electrical brake stop, slow run/stop and parallel operation via external speed setter.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| GSA-U | GGM GSA-U 11-pin plug-in speed control unit, single-phase AC 110/115V 60Hz | GGM | Input: 1-ph AC 110/115V 60Hz (±10%) | Rated current: 3A | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz | Type: 11-pin plug-in (socket type) | Brake: electrical moment-stop, 0.5s (no retention) | Functions: slow run/stop, parallel operation | Speed setter: external (required) | ||
| GSA-J | GGM GSA-J 11-pin plug-in speed control unit, single-phase AC 100V 50/60Hz | GGM | Input: 1-ph AC 100V 50/60Hz (±10%) | Rated current: 3A | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: 11-pin plug-in (socket type) | Brake: electrical moment-stop, 0.5s (no retention) | Functions: slow run/stop, parallel operation | Speed setter: external (required) | ||
| GSA-C | GGM GSA-C 11-pin plug-in speed control unit, single-phase AC 220/230V 50/60Hz, 240V 50Hz | GGM | Input: 1-ph AC 220/230V 50/60Hz, 240V 50Hz (±10%) | Rated current: 3A | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: 11-pin plug-in (socket type) | Brake: electrical moment-stop, 0.5s (no retention) | Functions: slow run/stop, parallel operation | Speed setter: external (required) | ||
| GSA-L | GGM GSA-L 11-pin plug-in speed control unit, single-phase AC 200V 50/60Hz | GGM | Input: 1-ph AC 200V 50/60Hz (±10%) | Rated current: 3A | Applied motor: induction 6–180W / reversible 6–90W / speed&brake 6–180W | Speed range: 90–1700 r/min @60Hz, 90–1400 @50Hz | Type: 11-pin plug-in (socket type) | Brake: electrical moment-stop, 0.5s (no retention) | Functions: slow run/stop, parallel operation | Speed setter: external (required) |
