[GGM] — K7G□C Gear Head for 15W Motor (□70mm, Ball Bearing + Metal Bearing, 1/3–1/200, incl. Decimal (K7G10BX))
AC Geared Motors GGM

[GGM] — K7G□C Gear Head for 15W Motor (□70mm, Ball Bearing + Metal Bearing, 1/3–1/200, incl. Decimal (K7G10BX))

Family ID: GGM-K7G-C

GGM gear head converts motor speed/torque by gear ratio. Helical-gear precision machining lowers noise approx. 10 dB vs conventional. Ball Bearing + Metal Bearing (C) type, ratios 1/3–1/200 (24 steps); dedicated to □70mm 15W pinion-shaft motor (K7□G), matching face/teeth only. Includes decimal gear head K7G10BX (1/10 intermediate reducer) for ratios beyond 1/200 (speed ÷10; permissible torque 5N·m/50kgf·cm).

25 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K7G3C GGM gear head K7G3C — ratio 1/3, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/3 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 0.29N·m(2.9kgf·cm)@50Hz / 0.24N·m(2.4kgf·cm)@60Hz | Output Speed: 500rpm@50Hz / 600rpm@60Hz | Gearhead Length L: 32mm | Mounting Bolt: M5 P0.8 X 50 | Weight: 0.38kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G3.6C GGM gear head K7G3.6C — ratio 1/3.6, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/3.6 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 0.35N·m(3.5kgf·cm)@50Hz / 0.29N·m(2.9kgf·cm)@60Hz | Output Speed: 416rpm@50Hz / 500rpm@60Hz | Gearhead Length L: 32mm | Mounting Bolt: M5 P0.8 X 50 | Weight: 0.38kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G5C GGM gear head K7G5C — ratio 1/5, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/5 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 0.49N·m(4.9kgf·cm)@50Hz / 0.41N·m(4.1kgf·cm)@60Hz | Output Speed: 300rpm@50Hz / 360rpm@60Hz | Gearhead Length L: 32mm | Mounting Bolt: M5 P0.8 X 50 | Weight: 0.38kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G6C GGM gear head K7G6C — ratio 1/6, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/6 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 0.58N·m(5.8kgf·cm)@50Hz / 0.49N·m(4.9kgf·cm)@60Hz | Output Speed: 250rpm@50Hz / 300rpm@60Hz | Gearhead Length L: 32mm | Mounting Bolt: M5 P0.8 X 50 | Weight: 0.38kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G7.5C GGM gear head K7G7.5C — ratio 1/7.5, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/7.5 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 0.73N·m(7.3kgf·cm)@50Hz / 0.61N·m(6.1kgf·cm)@60Hz | Output Speed: 200rpm@50Hz / 240rpm@60Hz | Gearhead Length L: 32mm | Mounting Bolt: M5 P0.8 X 50 | Weight: 0.38kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G9C GGM gear head K7G9C — ratio 1/9, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/9 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 0.87N·m(8.7kgf·cm)@50Hz / 0.73N·m(7.3kgf·cm)@60Hz | Output Speed: 166rpm@50Hz / 200rpm@60Hz | Gearhead Length L: 32mm | Mounting Bolt: M5 P0.8 X 50 | Weight: 0.38kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G10C GGM gear head K7G10C — ratio 1/10, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/10 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 0.97N·m(9.7kgf·cm)@50Hz / 0.81N·m(8.1kgf·cm)@60Hz | Output Speed: 150rpm@50Hz / 180rpm@60Hz | Gearhead Length L: 32mm | Mounting Bolt: M5 P0.8 X 50 | Weight: 0.38kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G12.5C GGM gear head K7G12.5C — ratio 1/12.5, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/12.5 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 1.22N·m(12.2kgf·cm)@50Hz / 1.01N·m(10.1kgf·cm)@60Hz | Output Speed: 120rpm@50Hz / 144rpm@60Hz | Gearhead Length L: 32mm | Mounting Bolt: M5 P0.8 X 50 | Weight: 0.38kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G15C GGM gear head K7G15C — ratio 1/15, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/15 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 1.46N·m(14.6kgf·cm)@50Hz / 1.22N·m(12.2kgf·cm)@60Hz | Output Speed: 100rpm@50Hz / 120rpm@60Hz | Gearhead Length L: 32mm | Mounting Bolt: M5 P0.8 X 50 | Weight: 0.38kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G18C GGM gear head K7G18C — ratio 1/18, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/18 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 1.75N·m(17.5kgf·cm)@50Hz / 1.46N·m(14.6kgf·cm)@60Hz | Output Speed: 83rpm@50Hz / 100rpm@60Hz | Gearhead Length L: 32mm | Mounting Bolt: M5 P0.8 X 50 | Weight: 0.38kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G20C GGM gear head K7G20C — ratio 1/20, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/20 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 1.75N·m(17.5kgf·cm)@50Hz / 1.46N·m(14.6kgf·cm)@60Hz | Output Speed: 75rpm@50Hz / 90rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.46kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G25C GGM gear head K7G25C — ratio 1/25, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/25 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 2.19N·m(21.9kgf·cm)@50Hz / 1.82N·m(18.2kgf·cm)@60Hz | Output Speed: 60rpm@50Hz / 72rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.46kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G30C GGM gear head K7G30C — ratio 1/30, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/30 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 2.62N·m(26.2kgf·cm)@50Hz / 2.19N·m(21.9kgf·cm)@60Hz | Output Speed: 50rpm@50Hz / 60rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.46kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G36C GGM gear head K7G36C — ratio 1/36, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/36 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 3.15N·m(31.5kgf·cm)@50Hz / 2.62N·m(26.2kgf·cm)@60Hz | Output Speed: 41rpm@50Hz / 50rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.46kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G40C GGM gear head K7G40C — ratio 1/40, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/40 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 3.5N·m(35kgf·cm)@50Hz / 2.92N·m(29.2kgf·cm)@60Hz | Output Speed: 37rpm@50Hz / 45rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.46kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G50C GGM gear head K7G50C — ratio 1/50, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/50 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 3.94N·m(39.4kgf·cm)@50Hz / 3.28N·m(32.8kgf·cm)@60Hz | Output Speed: 30rpm@50Hz / 36rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.51kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G60C GGM gear head K7G60C — ratio 1/60, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/60 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 4.72N·m(47.2kgf·cm)@50Hz / 3.94N·m(39.4kgf·cm)@60Hz | Output Speed: 25rpm@50Hz / 30rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.51kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G75C GGM gear head K7G75C — ratio 1/75, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/75 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 5N·m(50kgf·cm)@50Hz / 4.92N·m(49.2kgf·cm)@60Hz | Output Speed: 20rpm@50Hz / 24rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.51kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G90C GGM gear head K7G90C — ratio 1/90, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/90 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 5N·m(50kgf·cm)@50Hz / 5N·m(50kgf·cm)@60Hz | Output Speed: 16rpm@50Hz / 20rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.51kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G100C GGM gear head K7G100C — ratio 1/100, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/100 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 5N·m(50kgf·cm)@50Hz / 5N·m(50kgf·cm)@60Hz | Output Speed: 15rpm@50Hz / 18rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.51kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G120C GGM gear head K7G120C — ratio 1/120, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/120 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 5N·m(50kgf·cm)@50Hz / 5N·m(50kgf·cm)@60Hz | Output Speed: 12.5rpm@50Hz / 15rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.51kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G150C GGM gear head K7G150C — ratio 1/150, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/150 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 5N·m(50kgf·cm)@50Hz / 5N·m(50kgf·cm)@60Hz | Output Speed: 10rpm@50Hz / 12rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.51kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G180C GGM gear head K7G180C — ratio 1/180, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/180 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 5N·m(50kgf·cm)@50Hz / 5N·m(50kgf·cm)@60Hz | Output Speed: 8.3rpm@50Hz / 10rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.51kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G200C GGM gear head K7G200C — ratio 1/200, Ball Bearing + Metal Bearing, for 15W motor GGM Ratio: 1/200 | Bearing: Ball Bearing + Metal Bearing (C) | Output Torque: 5N·m(50kgf·cm)@50Hz / 5N·m(50kgf·cm)@60Hz | Output Speed: 7.5rpm@50Hz / 9rpm@60Hz | Gearhead Length L: 42mm | Mounting Bolt: M5 P0.8 X 65 | Weight: 0.51kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft) | Type: Helical, low-noise
K7G10BX GGM decimal gear head K7G10BX — 1/10 intermediate reducer for 15W motor GGM Type: Decimal (intermediate) gear head 1/10 | Function: Inserted between motor and gear head; reduces speed to 1/10 | Permissible Torque: 5N·m (50kgf·cm) — not increased by decimal head | Use: For total ratios beyond 1/200 | Gearhead Length L: 30mm | Mounting Bolt: M5 P0.8 X 90 | Weight: 0.32kg | Frame: □70mm | Applicable Motor: K7□G (15W, pinion shaft)
