[GGM] — KWC-3640-T S1-T BLDC Worm Geared Motor (DC 12V, 1/25–1/1500)
Family ID: GGM-KWC-3640T-S1T
GGM KWC-3640-T BLDC round-flange worm geared motor, KB3640S1-T base, DC 12V, 6-lead PWM speed control with CW/CCW (default CCW), brake and 1FG feedback (6 pulses/rev), no-PCB control; GUN-type speed controller. 19 gear ratios 1/25 to 1/1500, output torque to 6 kgf·cm.
19 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KWC-0025-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/25, DC 12V | GGM | Gear Ratio: 1/25 · Output Speed: 180 rpm · Output Torque: 1.4 kgf·cm | ||
| KWC-0030-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/30, DC 12V | GGM | Gear Ratio: 1/30 · Output Speed: 150 rpm · Output Torque: 1.6 kgf·cm | ||
| KWC-0050-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/50, DC 12V | GGM | Gear Ratio: 1/50 · Output Speed: 90 rpm · Output Torque: 2.7 kgf·cm | ||
| KWC-0060-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/60, DC 12V | GGM | Gear Ratio: 1/60 · Output Speed: 75 rpm · Output Torque: 2.9 kgf·cm | ||
| KWC-0075-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/75, DC 12V | GGM | Gear Ratio: 1/75 · Output Speed: 60 rpm · Output Torque: 3.6 kgf·cm | ||
| KWC-0100-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/100, DC 12V | GGM | Gear Ratio: 1/100 · Output Speed: 45 rpm · Output Torque: 4.9 kgf·cm | ||
| KWC-0125-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/125, DC 12V | GGM | Gear Ratio: 1/125 · Output Speed: 36 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0150-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/150, DC 12V | GGM | Gear Ratio: 1/150 · Output Speed: 30 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0200-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/200, DC 12V | GGM | Gear Ratio: 1/200 · Output Speed: 22.5 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0250-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/250, DC 12V | GGM | Gear Ratio: 1/250 · Output Speed: 18 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0300-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/300, DC 12V | GGM | Gear Ratio: 1/300 · Output Speed: 15 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0375-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/375, DC 12V | GGM | Gear Ratio: 1/375 · Output Speed: 12 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0500-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/500, DC 12V | GGM | Gear Ratio: 1/500 · Output Speed: 9 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0600-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/600, DC 12V | GGM | Gear Ratio: 1/600 · Output Speed: 7.5 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0750-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/750, DC 12V | GGM | Gear Ratio: 1/750 · Output Speed: 6 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0900-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/900, DC 12V | GGM | Gear Ratio: 1/900 · Output Speed: 5 rpm · Output Torque: 6 kgf·cm | ||
| KWC-1050-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/1050, DC 12V | GGM | Gear Ratio: 1/1050 · Output Speed: 4.2 rpm · Output Torque: 6 kgf·cm | ||
| KWC-1350-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/1350, DC 12V | GGM | Gear Ratio: 1/1350 · Output Speed: 3.3 rpm · Output Torque: 6 kgf·cm | ||
| KWC-1500-KB3640S1-T | KWC-3640-T BLDC worm gearhead KB3640S1-T, 1/1500, DC 12V | GGM | Gear Ratio: 1/1500 · Output Speed: 3 rpm · Output Torque: 6 kgf·cm |
