![[GGM] — KWC-3657-U1 Worm Geared Motor (DC 12V, 1/25–1/1500)](https://img.prosourcemro.com/2026/06/0609-10-1024x678.png)
DC
GGM
[GGM] — KWC-3657-U1 Worm Geared Motor (DC 12V, 1/25–1/1500)
Family ID: GGM-KWC-3657-U1
GGM KWC round-flange worm geared motor, KD3657U1 base, DC 12V. 19 gear ratios 1/25 to 1/1500, output torque 1.1–6 kgf·cm; ø12 output shaft, P.C.D ø46 flange mount.
19 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KWC-0025-KD3657U1 | KWC worm gearhead KD3657U1, 1/25, DC 12V | GGM | Gear Ratio: 1/25 · Output Speed: 200 rpm · Output Torque: 1.1 kgf·cm | ||
| KWC-0030-KD3657U1 | KWC worm gearhead KD3657U1, 1/30, DC 12V | GGM | Gear Ratio: 1/30 · Output Speed: 166 rpm · Output Torque: 1.3 kgf·cm | ||
| KWC-0050-KD3657U1 | KWC worm gearhead KD3657U1, 1/50, DC 12V | GGM | Gear Ratio: 1/50 · Output Speed: 100 rpm · Output Torque: 2.2 kgf·cm | ||
| KWC-0060-KD3657U1 | KWC worm gearhead KD3657U1, 1/60, DC 12V | GGM | Gear Ratio: 1/60 · Output Speed: 83 rpm · Output Torque: 2.3 kgf·cm | ||
| KWC-0075-KD3657U1 | KWC worm gearhead KD3657U1, 1/75, DC 12V | GGM | Gear Ratio: 1/75 · Output Speed: 66 rpm · Output Torque: 2.9 kgf·cm | ||
| KWC-0100-KD3657U1 | KWC worm gearhead KD3657U1, 1/100, DC 12V | GGM | Gear Ratio: 1/100 · Output Speed: 50 rpm · Output Torque: 3.9 kgf·cm | ||
| KWC-0125-KD3657U1 | KWC worm gearhead KD3657U1, 1/125, DC 12V | GGM | Gear Ratio: 1/125 · Output Speed: 40 rpm · Output Torque: 4.9 kgf·cm | ||
| KWC-0150-KD3657U1 | KWC worm gearhead KD3657U1, 1/150, DC 12V | GGM | Gear Ratio: 1/150 · Output Speed: 33 rpm · Output Torque: 5.8 kgf·cm | ||
| KWC-0200-KD3657U1 | KWC worm gearhead KD3657U1, 1/200, DC 12V | GGM | Gear Ratio: 1/200 · Output Speed: 25 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0250-KD3657U1 | KWC worm gearhead KD3657U1, 1/250, DC 12V | GGM | Gear Ratio: 1/250 · Output Speed: 20 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0300-KD3657U1 | KWC worm gearhead KD3657U1, 1/300, DC 12V | GGM | Gear Ratio: 1/300 · Output Speed: 16.6 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0375-KD3657U1 | KWC worm gearhead KD3657U1, 1/375, DC 12V | GGM | Gear Ratio: 1/375 · Output Speed: 13.3 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0500-KD3657U1 | KWC worm gearhead KD3657U1, 1/500, DC 12V | GGM | Gear Ratio: 1/500 · Output Speed: 10 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0600-KD3657U1 | KWC worm gearhead KD3657U1, 1/600, DC 12V | GGM | Gear Ratio: 1/600 · Output Speed: 8.3 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0750-KD3657U1 | KWC worm gearhead KD3657U1, 1/750, DC 12V | GGM | Gear Ratio: 1/750 · Output Speed: 6.6 rpm · Output Torque: 6 kgf·cm | ||
| KWC-0900-KD3657U1 | KWC worm gearhead KD3657U1, 1/900, DC 12V | GGM | Gear Ratio: 1/900 · Output Speed: 5.5 rpm · Output Torque: 6 kgf·cm | ||
| KWC-1050-KD3657U1 | KWC worm gearhead KD3657U1, 1/1050, DC 12V | GGM | Gear Ratio: 1/1050 · Output Speed: 4.7 rpm · Output Torque: 6 kgf·cm | ||
| KWC-1350-KD3657U1 | KWC worm gearhead KD3657U1, 1/1350, DC 12V | GGM | Gear Ratio: 1/1350 · Output Speed: 3.7 rpm · Output Torque: 6 kgf·cm | ||
| KWC-1500-KD3657U1 | KWC worm gearhead KD3657U1, 1/1500, DC 12V | GGM | Gear Ratio: 1/1500 · Output Speed: 3.3 rpm · Output Torque: 6 kgf·cm |
