![[GGM] — KGV-4266-T1 Geared DC Motor (DC 12V, 7000rpm base, 3 ratios 1/60-1/105)](https://img.prosourcemro.com/2026/06/0605-19-1024x938.png)
DC
GGM
[GGM] — KGV-4266-T1 Geared DC Motor (DC 12V, 7000rpm base, 3 ratios 1/60-1/105)
Family ID: GGM-KGV4266-T1
GGM KGV-4266-T1 geared DC motor, ø42 frame, DC 12V (7000 rpm base motor). 3 gear ratios 1/60-1/105, output torque up to 20 kgf·cm, ø8 output shaft, 6-M4 mounting. Output shaft rotates CW with motor (+) to (+). Stall 24 A / 3.8 kgf·cm.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KGV-0060-KD4266T1 | KGV-4266-T1 geared, 1/60, 98rpm, 18kgf·cm | GGM | Gear Ratio: 1/60 | Output Speed: 98 rpm | Output Torque: 18 kgf·cm | ||
| KGV-0090-KD4266T1 | KGV-4266-T1 geared, 1/90, 65rpm, 20kgf·cm | GGM | Gear Ratio: 1/90 | Output Speed: 65 rpm | Output Torque: 20 kgf·cm | ||
| KGV-0105-KD4266T1 | KGV-4266-T1 geared, 1/105, 56rpm, 20kgf·cm | GGM | Gear Ratio: 1/105 | Output Speed: 56 rpm | Output Torque: 20 kgf·cm |
