Solid State Contactors
MITSUBISHI ELECTRIC
[Mitsubishi Electric] - US-K Three Pole Solid State Contactor (AC100-240V, 100A to 150A)
Family ID: MEL-US-K-3P
Mitsubishi Electric MS-T/N series US-K three pole solid state contactor for motor and heater loads at rated voltage AC100-240V, covering rated operational currents 100A to 150A under AC-1 class. The three pole type is supplied only as a three element type; the two element type is not manufactured. Semiconductor switching gives long life in high frequency switching duty with no switching noise and no wearing parts. Option units include the drive unit UA-DR1, the reversing unit UA-RE and the power control unit UA-PC. Three phase capacity figures assume two or three single pole units combined onto a three phase load. Derate the rated operational current above 40 degrees C ambient. JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| US-K100TE | US-K100TE solid state contactor, three pole type, 100A AC-1 | Mitsubishi Electric | Type: Solid state contactor for motor and heater loads · Main Circuit Configuration: 3 pole 3 element type · Rated Voltage: AC100-240V · Rated Operational Current AC-1 Class: 100A · Heater Capacity: 20kW at 1 phase 200V, 34.6kW at 3 phase 200V · Motor Capacity: 15kW at 3 phase 200V · Application Note: Three phase capacity figures assume two or three single pole units combined onto a three phase load · Ambient Derating: Derate the rated operational current above 40 degrees C ambient · Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard | ||
| US-K120TE | US-K120TE solid state contactor, three pole type, 120A AC-1 | Mitsubishi Electric | Type: Solid state contactor for motor and heater loads · Main Circuit Configuration: 3 pole 3 element type · Rated Voltage: AC100-240V · Rated Operational Current AC-1 Class: 120A · Heater Capacity: 24kW at 1 phase 200V, 41.5kW at 3 phase 200V · Motor Capacity: 15kW at 3 phase 200V · Application Note: Three phase capacity figures assume two or three single pole units combined onto a three phase load · Ambient Derating: Derate the rated operational current above 40 degrees C ambient · Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard | ||
| US-K150TE | US-K150TE solid state contactor, three pole type, 150A AC-1 | Mitsubishi Electric | Type: Solid state contactor for motor and heater loads · Main Circuit Configuration: 3 pole 3 element type · Rated Voltage: AC100-240V · Rated Operational Current AC-1 Class: 150A · Heater Capacity: 30kW at 1 phase 200V, 52kW at 3 phase 200V · Motor Capacity: 18.5kW at 3 phase 200V · Application Note: Three phase capacity figures assume two or three single pole units combined onto a three phase load · Ambient Derating: Derate the rated operational current above 40 degrees C ambient · Standards: JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard |
