Solid State Contactors
MITSUBISHI ELECTRIC
[Mitsubishi Electric] - US-KD8 DC Load Solid State Contactor (DC24-110V, 8A DC-1)
Family ID: MEL-US-KD8
Mitsubishi Electric MS-T/N series US-KD8 solid state contactor for DC loads, rated DC24-110V with rated operational current 8A under DC-1 class. It is the only DC load type in the US series. Semiconductor switching gives long life in high frequency switching duty with no switching noise and no wearing parts. Rail mounting is available on the standard product and the drive unit with output UA-SH8 can be fitted as an option. Derate the rated operational current above 40 degrees C ambient.
1 product code available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| US-KD8 | US-KD8 solid state contactor for DC loads, 8A DC-1 | Mitsubishi Electric | Type: Solid state contactor for DC loads · Rated Voltage: DC24-110V · Rated Operational Current DC-1 Class: 8A · Rail Mounting: Available on the standard product · Option Unit: UA-SH8 drive unit with output · Ambient Derating: Derate the rated operational current above 40 degrees C ambient |
