[Mitsubishi Electric] - US-N40 Solid State Contactor (AC100-480V, 40A AC-1)

Mitsubishi Electric MS-T/N series US-N40 solid state contactor for motor and heater loads, suited to high frequency switching on conveying lines and similar duty. Rated voltage AC100-480V with rated operational current 40A under AC-1 class. Heater capacity 8kW at 1 phase 200V, 13.8kW at 3 phase 200V and motor capacity 5.5kW at 3 phase 200V. Heater capacity 16kW at 1 phase 400V, 27.7kW at 3 phase 400V and motor capacity 11kW at 3 phase 400V. Semiconductor switching gives long life in high frequency switching duty with no switching noise, no wearing parts and clean operation, a front operation indicator shows the control input state, and a finger protection charged part cover to DIN and VDE requirements is fitted as standard. Available as a 3 pole 2 element type or, with the TE code, a 3 pole 3 element type, with the CX code adding a CAN terminal. Option units include the drive unit UA-DR1, the reversing unit UA-RE and the power control unit UA-PC. Derate the rated operational current above 40 degrees C ambient. JEM, IEC, UL, CSA, EC directive, TUV and CCC certified as standard.
